Foscam FI9821EP Quick Installation Manual

Quick Installation Guide
Indoor HD PoE IP Camera with P2P
Model:FI9821EP
Black White
V4.1
EE200414
Foscam Digital Technologies
www.foscam.us www.foscam.ca www.foscam.co.uk
www.foscamgroup.com www.foscam.com
Package Contents 1
Power Adapter Ethernet Cable
IP Camera Resource CD
Quick Installation Guide
Indoor HD PoE IP Camera with P2P
Model:FI9821EP
Black White
Mounting Bracket Quick Installation Guide Security Warning Card
Security Warning
Foscam cameras require good security practices to
safeguard your privacy. You can help protect your camera
by changing the default username and/or password.
You should update your camera regularly at
http://www.foscam.us/firmware.html. Make sure your
camera has the latest firmware installed for your specific
camera model.
3
Access the IP Camera
in LAN
1. Enable the DHCP feature of your router (Enabled by default
normally), then open the IP Camera Tool program. It should
display the camera's IP address in your LAN (Local Area
Network).
2. Double click the camera listed here, and your default
browser will open up to the camera's login page. When log
in for the first time, you will need to download and install
the add-on. We will use Internet Explorer as an example. For
Google Chrome, Apple Safari, or Mozilla Firefox, please refer
to the User Manual.
Note：
Doesn't support 64-bit browser.
Hardware Introduction
Physical Description
Mounting Port
Reset Button
Speaker
LENS
Infrared LED
Microphone
LAN DC 5V
AUDIO
SD Input
IN
OU T
Power
Output
Micro SD Card Slot
Network light
Power light
Click Install
3. After installing the add-on, refresh the browser and click Login.
Default username is admin with
no password.
Main stream offers the highest
quality video while Sub stream
offers less quality, but also less
delay when viewing.
Hardware Connection
WPS o AUDIO
SD
OUT IN
WPS
1. Connect the camera to the LAN network (Router or Switch) via
network cable.
2. Connect the power adapter to the camera.
4. When you log in for the first time, it will request that you modify
the default username and/or password. Input the New username,
New password, and Confirm the password click Modify to
,
complete the modification. You will now use the new username
and password to login to the camera in the future.
Input the New username,
New password and
Confirm the password.
2

Software Installation

1. Insert the CD into the CD drive of your computer.
2. Go to the folder "IP Camera Search Tool" and find the folder
"For Windows OS"or "For Mac OS". Copy and paste the IP camera
tool file to your computer, or drag it onto your desktop.
Shortcut icon for Windows OS Shortcut icon for Mac OS
Notes:
If your computer ( Windows OS ) supports autorun function ,
you can find the corresponding file in the opened control panel.
If your computer doesn't have CD drive, you can download
the IP camera tool from our website for free.
5. After log in, you will see live video on the interface.
Notes:
After log in for the first time, it will go to "Setup Wizard"
automatically. Please set the basic parameters, such as the
camera name, camera time and more.
If you forget your username or password, you can press
and hold the reset button on the bottom of the camera using
a pin for 5 seconds. This resets the camera to factory defaults.
If you want to access your camera over the Internet,
please continue with the setup by following the Remote
Access steps below.
