PARTS LIST

ITEM QTY REFERENCE
Additional Demo Board Circuit Components
1 0 C5, C8, C9, C16, C17, C18 (Opt)
2 0 C19 (Opt)
3 0 C21, C22, C28, CC2
4 0 C23
5 0 C24, C25, C26, C27 (Opt)
6 0 D3, D4 (Opt)
7 0 D5, D6 (Opt)
8 0 D7 (Opt)
9 0 L2, L3 (Opt)
10 0 M5, M6, M7, M8, M12 (Opt)
11 0 M9, M10, M11 (Opt)
12 0 R2, R23, R24, R26-R32
13 1 R7
14 0 R8, R9, R25
15 3 R12, R14, R22
16 2 R13, R21
17 1 R34
Hardware: For Demo Board Only
1 4 E1, E2, E19, E20
2 13 E3, E5, E6, E7, E8, E9, E10, E11, E12,
E13, E14, E21, E22
3 5 E4, E15, E16, E17, E24
4 0 E18 (Opt)
5 0 E23 (Opt)
6 4 MH1-MH4
DEMO MANUAL DC2123B
PART DESCRIPTION
CAP., 1210
OPTIONAL
CAP., 0603
OPTIONAL
OPTIONAL
SCHOTTKY DIODE, SMB
DIODE, SOD-123
DIODE, SOD-523
OPTIONAL
OPTIONAL
OPTIONAL
RES., 0603 OPTIONAL
RES., CHIP 0Ω 1206
Res., 0402 OPTIONAL
RES., CHIP 0Ω 0402
RES., CHIP 0Ω 0603
RES., CHIP 1.37k 0.06W 1% 0603
CONNECTOR, BANANA JACK
TURRET, TESTPOINT
TURRET, TESTPOINT
OPTIONAL
OPTIONAL
STANDOFF, NYLON 0.50"
MANUFACTURER/PART NUMBER
YAGEO, RC1206FR-070RL
VISHAY CRCW04020000Z0ED
VISHAY CRCW06030000Z0EA
PANASONIC ERJ-3EKF1371V
KEYSTONE 575-4
MILL MAX 2308-2-00-80-00-00-07-0
MILL MAX 2501-2-00-80-00-00-07-0
KEYSTONE, 8833 (SNAP-ON)
dc2123bfa
7
