Tadiran Telecom SIP-T19P Quick Installation Manual

Packaging Contents
The following items are included in your package. If you find anything missing,
contact your system administrator.
IP Phone Handset
Assembling the Phone
1. Attach and detach the stand, as shown below:
a) Attach the stand:
Wall Mount Method
b) Detach the stand:
SIP-T19P Quick Installation Guide
Quick Installation
Handset Cord Ethernet Cable
Guide & Quick
Reference Guide
Stand
Desk Mount Method
2. Connect the handset and optional headset, as shown below:
Note: The headset should be purchased separately.
3. Connect the network and power, as shown below:
You have two options for network and power connections. Your system administrator will
advise you on which one to use.
A
AC Power Option
B
PoE ( Power over
Ethernet ) Option
IEEE 802.3af compliant
PoE Hub/Switch
Note: PoE is only applicable to the SIP-T19P IP phone. If inline power (PoE) is provided, you don't need to
connect the power adapter. Make sure the Etherne cable and hub/switch are PoE compliant.
Startup
After the IP phone is connected to the network and supplied
with power, it automatically begins the initialization process.
After startup, the phone is ready for use. See your system
administrator for advanced configuration options.
PC Connection
(Optional)
Power Adapter
DC 5V
(Optional)
PC Connection
(Optional)
Welcome
Initializing... please wait
www.tadirantele.com
