Service and Repair Manual
Manifolds
7-2

Secondary Function Manifold Components

The secondary function manifold is located under the manifold inspection cover.
Index
Description
No.
1 DO3 valve, 3 position 4 way
2 Pressure reducing/relief valve,
400 psi / 27.5 bar
3 Pressure reducing/relief valve,
350 psi / 24.8 bar
4 Check valve, 5 psi / 0.35 bar
5 Solenoid valve, 2 position 3 way
6 Solenoid valve, 2 position 3 way
42
Schematic
Item
SVD1 Steer left/right
PR2 Differential lock-up circuit
PR1 Parking brake circuit
CV1 Steering circuit
SV1 Differential lock up select
SV2 Rear lock up select
GTH-636
Function
25-30 ft-lbs / 34-41 Nm
19-21 ft-lbs / 25.8-28.6
Part No. 1287209GT
April 2018
Torque
60 in-lbs / 6.8 Nm
50 ft-lbs / 68 Nm
20 ft-lbs / 27.1 Nm
19-21 ft-lbs /
25.8-28.6 Nm
Nm
