  • Page 1 Operator’s Manual Serial number range GTH 4013 EX From s/n: 19272 to s/n: 20200 GTH 4514 EX From s/n: 20011 to s/n: 20143 From s/n: 19608 GTH 4017 EX to s/n: 19450 With Maintenance Information Second Edition Second Printing Part No.

  • Page 2: Table Of Contents

    Operator’s Manual Second Edition - Second Printing Contents Important Read, understand and obey these safety rules Introduction ..........Page and operating instructions before operating the Machine Identification ......Page machine. Only trained and qualified personnel Symbols Used On The Machine ..Page shall be authorized to operate the machine. Labels And Plates Applied On The This manual shall be kept with the machine at Machine ..........Page...

  • Page 3: Introduction

    Second Edition - Second Printing Operator’s Manual Introduction Symbols Safety alert symbol: used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death DANGER Red: indicates a hazardous situation which, if not avoided, will result in death or serious injury.
  • Page 4 Operator’s Manual Second Edition - Second Printing Intentionally blank page GTH-4013EX - GTH-4514EX - GTH-4017EX Part No. 57.0009.0454 Courtesy of Crane.Market...

  • Page 5: Machine Identification

    Second Edition - Second Printing Operator’s Manual Machine Identification ISO 3287: 1999 Powered industrial trucks - Symbols Check that the operator handbook refers to the for operator controls. delivered machine. ISO 3449:1992 Earth-moving machinery - Falling- MODEL AND TYPE object protective structures - Laboratory tests and performance Handler with telescopic boom: requirements.
  • Page 6 Operator’s Manual Second Edition - Second Printing Machine Identification CE MARKING Road traffic data plate This machine fulfils the safety requirements of The road traffic data plate is installed on the front the Machinery Directive.The conformity has been right side of the chassis (only on machines destined certified and the placing of the CE marking on the for the Italian market).

  • Page 7: Symbols Used On The Machine

    Second Edition - Second Printing Operator’s Manual Symbols Used On The Machine Fuel Level Parking Brake Battery Charge Brake pressure Fog lamp Low Engine Oil Hydraulic Oil Filter Turn Signals High Beam L o w H y d r a u l i c O i l Pressure Clogged Level...
  • Page 8 Operator’s Manual Second Edition - Second Printing Symbols Used On The Machine HAZARD PICTORIAL DESCRIPTIONS Electrocution Falling Object Maintain required No people under Fall Hazard Hazard Hazard clearance. load. Explosion/Burn Allow system to No riders. No smoking. No Burn Hazard Hazard cool.

  • Page 9: Labels And Plates Applied On The Machine

    Second Edition - Second Printing Operator’s Manual Labels And Plates Applied On The Machine Part No. 57.0009.0454 GTH-4013EX - GTH-4514EX - GTH-4017EX Courtesy of Crane.Market...
  • Page 10 Operator’s Manual Second Edition - Second Printing Labels And Plates Applied On The Machine Use the pictures on these pages to verify that all decals are legible and in place. Use the pictures on these pages to verify that all decals are legible and in place. The following chart shows quantities and description too.
  • Page 11 Label - Use limits close to electric power 09.4618.0921 lines 09.4618.0921 09.4618.0933 Crush Hazard 09.4618.0933 09.4618.0922 Crush Hazard 09.4618.0922 09.4618.0243 09.4618.0241 Cosmetic - GENIE Logo in WHITE 09.4618.0242 Part No. 57.0009.0454 GTH-4013EX - GTH-4514EX - GTH-4017EX Courtesy of Crane.Market...
  • Page 12 Operator’s Manual Second Edition - Second Printing Labels And Plates Applied On The Machine Ref. Decal Code Description 09.4618.0815 Cosmetic - Genie GTH-4514 EX GTH-4514 EX 09.4618.0816 09.4618.0817 Cosmetic - Genie GTH-4017 EX GTH-4017 EX 09.4618.0818 09.4618.0813 GTH-4013 EX Cosmetic - Genie GTH-4013 EX 09.4618.0814...
  • Page 13 BOOM HOSES BOOM SECTIONS NEED 09.4618.0171 TO BE EXTENDED EQUALLY OTHERWISE noticed, proceed with re-sequencing as RE-SEQUENCING WILL BE REQUIRED. indicated in the operator’s manual. SEE OPERATORS MANUAL FOR MORE DETAILS. ONLY FOR GTH 4013 EX 09.4618.0171 Ref. Circuit Ref. Circuit Ref. Circuit...
  • Page 14 Operator’s Manual Second Edition - Second Printing Labels and plates applied on the machine Ref. Decal Code Description ROPS-FOPS cab type-approval plate. This plate 09.4616.0100 shows the type-approval data of the driving cab according to ROPS - FOPS regulations. TEREX FT srl - ON N STR E - 06019 M ERT E PG - T Tel.

  • Page 15: Safety Precautions

    Second Edition - Second Printing Operator’s Manual Safety Precautions SAFETY DEVICES DAMAGED MACHINE HAZARDS • Do not use a damaged or defective machine. • Do a thorough pre-operation inspection of the machine and test all functions before each work shift. Tag and remove from service a damaged or defective machine.
  • Page 16 Operator’s Manual Second Edition - Second Printing Safety Precautions GENERAL REMARKS Not observing the instructions Most accidents occurring while working, repairing or and safety rules in this manual maintaining machines, are caused by not complying may result in death or serious with the basic safety precautions.
  • Page 17 Second Edition - Second Printing Operator’s Manual Safety Precautions REQUISITES OF THE PERSONNEL IN CHARGE Requisites of the SERVICEMEN Requisites of the MACHINE OPERATORS The personnel charged with the machine maintenance The operators who use the machine regularly or shall be qualified, specialised in the maintenance occasionally (i.e.
  • Page 18 Operator’s Manual Second Edition - Second Printing Safety Precautions OTHER DANGERS Hazards on the JOBSITE WORKING CLOTHES Always take into account the features of the job site During work, but especially when maintaining or where you are going to work: repairing the machine, operators must wear suitable protective clothing: •...
  • Page 19 Second Edition - Second Printing Operator’s Manual Safety precautions OPERATION or MAINTENANCE hazards Before any operation, following precautions should WARNING be taken: • First of all, make sure that the maintenance interventions have been carried out with care Make sure the machine (wheels and stabilisers) according to the established schedule.
  • Page 20 Operator’s Manual Second Edition - Second Printing Safety precautions • Do not lubricate, clean or adjust moving parts. • When entering/leaving the cab or other raised parts, always face the machine; never turn the • Do not carry out operations manually when back.
  • Page 21 Second Edition - Second Printing Operator’s Manual Safety precautions • When working, do not give instructions or signs • Do not operate the machine in dangerous to several people at the same time. Instructions environments or in places with flammable or and signs must be given by one person only.
  • Page 22 Operator’s Manual Second Edition - Second Printing Intentionally blank page GTH-4013EX - GTH-4514EX - GTH-4017EX Part No. 57.0009.0454 Courtesy of Crane.Market...

  • Page 23: Description Of The Main Components

    Second Edition - Second Printing Operator’s Manual Description Of The Main Components Boom 2. Chassis Forks Attachment holding frame Outrigger 6. Driving cab according to ROPS-FOPS provisions Front axle 8. Fuel tank 9. Access step Rear axle Engine Part No. 57.0009.0454 GTH-4013EX - GTH-4514EX - GTH-4017EX Courtesy of Crane.Market...
  • Page 24 Operator’s Manual Second Edition - Second Printing Intentionally blank page GTH-4013EX - GTH-4514EX - GTH-4017EX Part No. 57.0009.0454 Courtesy of Crane.Market...

  • Page 25: Controls And Instruments

    Second Edition - Second Printing Operator’s Manual Controls and Instruments ERROR Instruments Dashboard Fresh Air Flap Inclinometer Forward/Reverse Gear Selector Multipurpose Control Lever Steering Column Angle Adjustment Parking Brake Lever Turn Signals - Windscreen Washer - Horn - Lights Gas Pedal Auxiliary Drive Controls Service Brake Pedal Cab Heater Control Cock...
  • Page 26 Operator’s Manual Second Edition - Second Printing Controls and Instruments 26.1 GT H -4 0 1 3 EX RPM x 100 ERROR Ignition Switch Chassis Levelling Switch Transmission Warning Light Mechanical Gear Switch Outriggers Switches Emergency Pump Switch ( ONLY Auxiliary Hydraulic Circuit Switch with MAN-PLATFORM) (OPTIONAL)
  • Page 27 Second Edition - Second Printing Operator’s Manual Controls and Instruments 27 _ Ignition Switch 2 _ Forward/Reverse Gear Selector Four-position switch: Three-position switch with lock in neutral position: No circuit under voltage, key can be removed Neutral position; no gear engaged and engine is stopped.
  • Page 28 Operator’s Manual Second Edition - Second Printing Controls and Instruments 4 _ Turn Signals - Windscreen Wiper - Horn - Lights Lights function: Horn function: To switch the handler lights, lever can be set to three When sliding the lever along its axis, horn switches different positions along its horizontal axis: on, independently from other pre-set functions.
  • Page 29 Second Edition - Second Printing Operator’s Manual Controls and Instruments Brakes Safety and Emergency Devices 14 _ Service Brake Pedal 33 _ Hazard Warning Lights Switch Gradually step on the brake pedal to decelerate Fitted with on-off position, it switches and stop the machine.
  • Page 30 Operator’s Manual Second Edition - Second Printing Controls and Instruments 28 _ Mechanical Gear Switch Steering Mode Selection 26 _ Steering Mode Selector Pushbutton with green glass cap, it is used to engage 1st or 2nd gear. Push the button to select Three-position switch for the selection of the steering the required speed: each pressure corresponds to mode:...
  • Page 31 Second Edition - Second Printing Operator’s Manual Controls and Instruments Auxiliary drive controls 22 _ Auxiliary Hidraulic Circuit (OPTIONAL) 31 _ Cab Heater Fan switch Three-position switch: Two-position switch. The pressure of this button causes the switching of the hydraulic circuit for 0 OFF the movement of the attachments equipped with 1 Low speed...
  • Page 32 Operator’s Manual Second Edition - Second Printing Controls and Instruments Warning Lights and Instruments (ref. 9) 36.1 34.1 RPM x 100 GTH-4013 EX 35.1 40 51 GTH-4514 EX GTH-4017 EX 34.1 35.1 36.1 GTH-4013EX - GTH-4514EX - GTH-4017EX Part No. 57.0009.0454 Courtesy of Crane.Market...
  • Page 33 Second Edition - Second Printing Operator’s Manual Controls and Instruments DESCRIPTIONS 34 _ Engine coolant temperature indicator 43 _ Warning light - high beam This indicates the engine coolant temperature. If the Warning light that signals when high beam is ON. finger is in the red zone and the warning light 34.1 comes on, you must stop the machine and find and 44 _ Warning light - turn signals...
  • Page 34 Operator’s Manual Second Edition - Second Printing Controls and Instruments CONTROL LEVER Handlers are equipped with a multipurpose electro-   proportional lever which allows operating all machine movements. When shifted to one of the four directions (right/left, forwards/backwards) it controls the boom lifting/ lowering and the forward/back pitching .of the attachment frame.
  • Page 35 Second Edition - Second Printing Operator’s Manual Controls and Instruments Function selection The lever is enabled to carry out the following motions: • Boom lowering/lifting shift the control lever to A or B • Boom extraction/retraction press button 2 and shift to A or B without moving the control lever •...
  • Page 36 Operator’s Manual Second Edition - Second Printing Controls and Instruments Lifting/lowering the boom DANGER Before operating the boom, make sure that nobody is within the working range of the machine. To lift or lower the boom: • Smoothly shift the lever to position B to lift the boom or to position A to lower it.
  • Page 37 Second Edition - Second Printing Operator’s Manual Controls and Instruments Extending/retracting the boom DANGER Before operating the boom, make sure that nobody is within the working range of the machine. To extend or retract the telescopic elements of the boom: ...
  • Page 38 Operator’s Manual Second Edition - Second Printing Controls and Instruments Pitching the attachment holding frame forward/back DANGER Before operating the boom, make sure that nobody is within the working range of the machine. To tilt forward/back the attachment holding frame: •...
  • Page 39 Second Edition - Second Printing Operator’s Manual Controls and Instruments Quick-coupling the attachments DANGER Before operating the boom, make sure that nobody is within the working range of the machine. To lock/unlock the attachments:  • Press the button 1 •...
  • Page 40 Operator’s Manual Second Edition - Second Printing Controls and Instruments Outrigger movements Chassis Levelling Function DANGER Before lowering the outriggers, make sure Check that the machine is level on inclinometer that nobody is within the working range of the 10. The water level must be right in the middle machine.
  • Page 41 Second Edition - Second Printing Operator’s Manual Controls and Instruments Manual Controls In case of a malfunction of the control lever, it is WARNING possible to use the emergency manual controls of the main valve. The main valve has four control levers that operate For the use of the emergency controls, observe the following functions: the following sequence:...
  • Page 42 Operator’s Manual Second Edition - Second Printing Intentionally blank page GTH-4013EX - GTH-4514EX - GTH-4017EX Part No. 57.0009.0454 Courtesy of Crane.Market...

  • Page 43: Inspections

    Second Edition - Second Printing Operator’s Manual Inspections Pre-operation Inspection Fundamentals It is the responsibility of the operator to perform a pre-operation inspection and routine maintenance. The pre-operation inspection is a visual inspection Make sure: performed by the operator prior to each work shift. The inspection is designed to discover if anything You learn and practice the principles of safe is apparently wrong with a machine before the...
  • Page 44 Operator’s Manual Second Edition - Second Printing Inspections PRE-OPERATION INSPECTION • Make sure the operator’s manual is intact, legible * Make sure that all structural and other critical and placed inside the machine. components are present and the relevant • Make sure all decals are present and legible.
  • Page 45 Second Edition - Second Printing Operator’s Manual Inspections FUNCTION TESTS FUNDAMENTALS Test the Control Lever 7 Using the control lever, momentarily raise and The function tests are designed to discover lower the boom, tilt the forks up and tilt the any malfunctions before the machine is put into forks down.
  • Page 46 Operator’s Manual Second Edition - Second Printing Inspections Test the Road Lights Test the Transmission and Brakes 29 Verify that all lights are functional. 18 Be sure the boom is fully lowered and retracted. 19 Step on the service brake pedal. 20 Move the transmission control lever to forward.

  • Page 47: Operating Instructions

    Second Edition - Second Printing Operator’s Manual Operating Instructions This chapter describes some techniques and provides instructions for a safe use of the machine WARNING fitted with standard forks. Before using different attachments, thoroughly read the chapter “Optional attachments”. For a safe use of the machine, always check the weight of the loads going to be handled.
  • Page 48 Operator’s Manual Second Edition - Second Printing Operating Instructions ENTERING THE MACHINE ENTERING THE CAB To unlock the door latched in open position: CAUTION  • Press button 4 to unlock   the door from the catch Always make sure that your hands and shoe soles are clean and dry before getting into the driving •...
  • Page 49 Second Edition - Second Printing Operator’s Manual Operating Instructions ADJUSTING THE SEAT Position the seat so you can comfotarbly reach all the controls. The handler seat is fitted with devices which let you adjust the seat springing, height and distance from the controls, the backrest angle and the armrest height.
  • Page 50 Operator’s Manual Second Edition - Second Printing Operating Instructions ADJUSTING THE REAR VIEW MIRRORS ADJUSTING THE STEERING COLUMN The machine is fitted with two rear view mirrors: Both steering column and dashboard can be set to • Rear view mirror 55 is located on a special a different angle.
  • Page 51 Second Edition - Second Printing Operator’s Manual Operating Instructions STARTING THE ENGINE JUMP-STARTING THE ENGINE • Set the forward/back speed lever to neutral position. NOTICE • To start the engine, rotate the ignition switch to position , and release when the engine starts. Do not start the engine using a quick charge If the engine does not start within 20 seconds, booster to avoid any damage to the electronic...
  • Page 52 Operator’s Manual Second Edition - Second Printing Operating Instructions LOW TEMPERATURE STARTING In case of cold starting, use an oil with a SAE viscosity adequate to the ambient temperature. Please refer to the engine use and maintenance manual. The machine is supplied with oil SAE 15W/40. •...
  • Page 53 Second Edition - Second Printing Operator’s Manual Operating Instructions STARTING THE MACHINE ■ USE OF THE MAN-PLATFORM When the engine reaches the running temperature, For the use of the man-platform, proceed as ensure all parts are in transfer position and the gearbox follows: lever is in neutral.
  • Page 54 Operator’s Manual Second Edition - Second Printing Operating Instructions STOPPING AND PARKING THE MACHINE When possible, stop the machine on a dry, level and solid ground. Then: • Bring the machine to a smooth stop by easing up the gas pedal and stepping down on the brake pedal.
  • Page 55 Second Edition - Second Printing Operator’s Manual Operating Instructions USING THE LOAD CHARTS The load charts 1 indicates the maximum permissible WARNING load in relation to the boom extension and the type of attachment used. To operate under safe conditions, always refer to these charts.
  • Page 56 Operator’s Manual Second Edition - Second Printing Operating Instructions LOAD LIMITER On the front top strut of the cab, there is limiter 7 which warns the operator of the variation of stability of the machine and blocks any manoeuvre before the same reaches a critical condition.
  • Page 57 Second Edition - Second Printing Operator’s Manual Operating Instructions HANDLING LOADS Alarm codes and resetting Adjusting the forks The limiter has diagnostic facilities to aid in the With FEM forks (OPTIONAL) identification of failures of the transducers, breakages Forks shall be spaced to suit the load going to be of the cables or defects of the electronic system.
  • Page 58 Operator’s Manual Second Edition - Second Printing Operating Instructions WORKING PHASES When forks are correctly spaced, the handler is • Carefully withdraw the forks by operating the ready to use. boom retraction control and, if necessary, raise Work can be subdivided into three different phases: or lower the boom as forks come out.
  • Page 59 Second Edition - Second Printing Operator’s Manual Operating Instructions CHANGING THE ATTACHMENT CAU T I ON WARNING Use only attachments directly manufactured or After substitution, visually check the attachment recommended by Terexlift and detailed in the is correctly coupled to the boom, before operating ”Optional Attachments”...
  • Page 60 Operator’s Manual Second Edition - Second Printing Operating Instructions ROAD OR SITE TRANSFER Version with HYDRAULIC LOCKING When travelling on public roads, strictly obey the To change an attachment, operate as follows: local or national road traffic regulations. • Drive to the place where you will release the Besides, take into account the following general mounted attachment (when possible, a solid and precautions:...

  • Page 61: Transporting The Machine

    Second Edition - Second Printing Operator’s Manual Transporting The Machine MOVING A DISABLED MACHINE Setting the gear lever in neutral Tow the machine only when no alternative is possible, since this operation may result in serious damage to NOTICE the transmission. When possible, repair the machine on site.
  • Page 62 Operator’s Manual Second Edition - Second Printing Transporting The Machine LIFTING THE MACHINE TRANSPORTING THE MACHINE ON OTHER VEHICLES When the machine shall be lifted, use only means To transport the machine on another vehicle, follow having a suitable capacity. The characteristic data the steps below: are detailed in the relevant chapter of this manual and on the identification plate.
  • Page 63 Second Edition - Second Printing Operator’s Manual Transporting The Machine PARKING AND STORAGE Machine storage Short inactivity In case of extended inactivity of the machine, follow Always park the machine in a safe way after a working the above precautions. Additionally: day, a shift and at night.
  • Page 64 Operator’s Manual Second Edition - Second Printing Transporting The Machine CLEANING AND WASHING THE MACHINE MACHINE DISPOSAL Clean the machine in accordance with the following instructions: PROT ECT T H E • Remove any oil or grease traces with a dry EN V I RON M EN T solvent or a volatile mineral alcohol •...

  • Page 65: Maintenance

    Second Edition - Second Printing Operator’s Manual Maintenance INTRODUCTION Observe and obey: The operator can only perform t h e r o u t i n e m a i n t e n a n c e A thorough and regular maintenance keeps the operations envisaged in this machine in a safe and efficient working condition.
  • Page 66 Operator’s Manual Second Edition - Second Printing Maintenance LUBRICANTS - HEALTH AND SAFETY PRECAUTIONS Health First aid A prolonged skin contact with oil can cause irritation. Eyes : In case of accidental contact with Use rubber gloves and protective goggles. After the eyes, wash with fresh water.
  • Page 67 Second Edition - Second Printing Operator’s Manual Maintenance ORDINARY MAINTENANCE Every 10 working hours or daily A wrong or neglected maintenance can result in Check the engine oil level. possible risks for both operator and bystanders. Clean the air suction filter. Make sure maintenance and lubrication are carried Check the engine coolant level.
  • Page 68 Operator’s Manual Second Edition - Second Printing Maintenance Check the clamping of the cableheads to the Every 500 working hours or yearly battery terminals. Jobs to be done in addition to those above Check the air suction hose between engine and Change the engine oil and renew the fuel filter.
  • Page 69 Second Edition - Second Printing Operator’s Manual Maintenance OIL CHANGE SCHEDULE Operating Service Oil type hours * interval * SHELL RIMULA 15W-40 Oil level check daily (API CH-4/CG-4/CF-4/CF; Engine First change ACEA E3; MB228.3) Subsequent changes yearly TRACTORENAULT THFI 208 Axles and Oil level check monthly...
  • Page 70 Operator’s Manual Second Edition - Second Printing Maintenance MAINTENANCE INTERVENTIONS CAU T I ON WARNING High pressure lines must be replaced by qualified personnel only. All maintenance interventions must be carried Any foreign matters entering the closed circuit out with engine stopped, parking brake engaged, may result in a sudden deterioration of the transmission.
  • Page 71 Second Edition - Second Printing Operator’s Manual Maintenance ACCESS TO THE ENGINE COMPARTMENT CAUTION For any operation within the engine compartment, open the protection bonnet. The bonnet is equipped with pneumatic shock T a k e a l l p r e c a u t i o n s w h e n absorbers which unburdens and hold the bonnet in approaching the engine compartment.
  • Page 72 Operator’s Manual Second Edition - Second Printing Maintenance ENGINE AIR FILTER (FOR GTH-4013 EX) NOTICE The inner element should be replaced every two Clean the engine air filter and replace the elements, times the outer element is replaced. when necessary. Never wash the cartridge with water or Cleaning and changing the external solvents.
  • Page 73 Second Edition - Second Printing Operator’s Manual Maintenance ENGINE AIR FILTER NOTICE (FOR GTH-4017 EX GTH-4514 EX) The inner element should be replaced every two times the outer element is replaced. Clean the engine air filter and replace the elements, Daily remove any dust collected in the filter by when necessary.
  • Page 74 Operator’s Manual Second Edition - Second Printing Maintenance ENGINE COOLING SYSTEM  GTH-4514 EX CAUTION GTH-4017 EX When the coolant is hot, the cooling system is under pressure. With warm engine, loosen the radiator plug slowly and carefully, without removing it, to drain the pressure. Use protection gloves and keep your face at a safe distance.
  • Page 75 Second Edition - Second Printing Operator’s Manual Maintenance CHANGING THE HYDRAULIC OIL CHECKING THE OIL LEVEL IN THE TANK CAUTION To change the hydraulic oil, proceed as follows: 1 Stop the machine on a level ground and make Fine jets of hydraulic oil under pressure can sure the parking brake is engaged.
  • Page 76 Operator’s Manual Second Edition - Second Printing Maintenance ■ CHANGING THE CANISTERS OF THE OIL FILTER IN THE INJECTION LINE FOR GTH-4514 EX & GTH-4017 EX ■ ■ Transmission oil filter Auxiliary circuits oil filter To change the hydraulic oil filter of the transmission, To change the hydraulic oil filter cartridge of the proceed as follows: service circuits, proceed as follows:...
  • Page 77 Second Edition - Second Printing Operator’s Manual Maintenance CHANGING THE OIL FILTER CARTRIDGE FOR GTH-4013 EX To change the hydraulic oil filter element, proceed as follows: 1 Stop the machine on a level ground and engage the parking brake. 2 Place a container of suitable size under the filter to collect any oil leaks.
  • Page 78 Operator’s Manual Second Edition - Second Printing Maintenance CAB AIR FILTER Every six months clean the air filter in the cab. Replace the cartridge if the filtering cloth is damged. Cleaning and changing the cartridge: - Shut the engine down and engage the parking brake.
  • Page 79 Second Edition - Second Printing Operator’s Manual Maintenance OIL LEVEL IN THE (front/rear) WHEEL OIL LEVEL IN THE DIFFERENTIAL GEARS REDUCTION GEARS To check the oil level in the front and rear differential gears: • Stop the machine on a level ground and engage the parking brake.
  • Page 80 Operator’s Manual Second Edition - Second Printing Maintenance OIL LEVEL IN THE POWER DIVIDER GEARBOX To check the oil level in the power diver gearbox:  Filling plug • Stop the machine on a level ground and make  Drain plug sure the parking brake is engaged.
  • Page 81 Second Edition - Second Printing Operator’s Manual Maintenance GREASING CAU T I ON CAU T I ON Before injecting grease into the greasers, Use only PTFE INTERFLON FIN GREASE LS 2 thoroughly clean them to avoid that mud, dust to lubricate the sliding parts of the telescopic or other matters can mix with the lubricant and section.
  • Page 82 Operator’s Manual Second Edition - Second Printing Maintenance TYRES AND WHEELS On new machines, and when a wheel has been disassembled or replaced, check the nut torque of the wheels every 2 hours until they stay correct. Torque: 400 N/m. Always use tyres having the dimensions indicated Over-inflated tyres can burst.
  • Page 83 Second Edition - Second Printing Operator’s Manual Maintenance SHAFTING ALIGNMENT During operation, the alignment of the front and rear axles of the machine can be subject to variations. This can depend on an oil blow-by from the steering control circuit, or on a steering of both axles when front and rear wheels are not perfectly aligned.
  • Page 84 Operator’s Manual Second Edition - Second Printing Maintenance ADJUSTING THE SLIDING PADS OF THE BOOM SECTIONS  Any boom section is fitted with adjustable pads  located on the four sides of the profile. These pads are secured to both fixed and mobile part of every section.
  • Page 85 Second Edition - Second Printing Operator’s Manual Maintenance RE-SEQUENCING THE TELESCOPIC BOOM TENSIONING THE BOOM CHAINS (Only for GTH-4013 EX) (Only for GTH-4514 EX and GTH-4017 EX) If, during normal operation, a change in the boom extended lengths of 150 mm or more is noticed when To tighten the boom chains, follow the instructions the boom is retracted, proceed as follows: below:...
  • Page 86 Operator’s Manual Second Edition - Second Printing Maintenance CHECKING THE SAFETY DEVICES LOAD LIMITING SYSTEM. Checking the LOAD LIMITING SYSTEM It consists of a load cell fitted to the rear axle and (at every use) a display installed in the driving place. This device enables the operator to check the stability variation When power is turned on, the DLE load limiting system through a bar with 8 LED’s (4 green, 2 yellow and...
  • Page 87 Second Edition - Second Printing Operator’s Manual Maintenance EMERGENCY STOP PUSHBUTTON on the LIMIT SWITCHES on the OUTRIGGERS dashboard, to the right of the steering wheel. When the outriggers are lowered to the ground: the overload warning system changes the Pressing down this button stops the engine of meter scale the machine.
  • Page 88 Operator’s Manual Second Edition - Second Printing Maintenance BLOCK VALVES fitted to all CYLINDERS DANGER All machine’s cylinders are equipped with block valves: Always use the lock ring of the lift cylinder (see Compensation cylinder • picture below), when carrying out maintenance Lifting cylinder on the lift cylinder block valve or, in general, •...
  • Page 89 Second Edition - Second Printing Operator’s Manual Maintenance Checking the block valves (every 3 months) To remove the block valves or the cylinders Lower the boom to the ground in a firm way since The piloted blocking valves allow to held the load in the removal of the block valve or the cylinder can position in case of burst of a flexible hose.
  • Page 90 Operator’s Manual Second Edition - Second Printing Maintenance SAFETY SWITCHES: L Low boom sensor: switch installed at the back of the boom. M High boom sensor: switch installed at the back of the boom. N Extended boom sensor: switch installed at the back of the boom.
  • Page 91 Second Edition - Second Printing Operator’s Manual Maintenance C H E C K I N G T H E S T A T E T H E STRUCTURE Checking the MACHINE START CONTROL (at Five years or 6000 hours after the fi rst placing into every use) operation of the machine (whichever occurs fi...
  • Page 92 Operator’s Manual Second Edition - Second Printing Maintenance ELECTRICAL SYSTEM WARNING WARNING All maintenance interventions must be carried Battery electrolyte contains sulphuric acid. It • out with engine stopped, parking brake engaged, can burn you if it touches your skin and eyes. working attachments on the ground and gearbox Always wear goggles and protective gloves, lever in neutral.
  • Page 93 Second Edition - Second Printing Operator’s Manual Maintenance FUSES AND RELAYS Relays The electrical system is protected by fuses placed in Ref. Circuit the driving cab, on the left. Before replacing a blown HIGH BEAM fuse with a new one having the same amperage, find out and rectify the fault.
  • Page 94 Operator’s Manual Second Edition - Second Printing Maintenance FUSES AND RELAYS Relays The electrical system is protected by fuses placed in Ref. Circuit the driving cab, on the left. Before replacing a blown HIGH BEAM fuse with a new one having the same amperage, find out and rectify the fault.
  • Page 95 Second Edition - Second Printing Operator’s Manual Maintenance Engine compartment fuses and relays NOTICE Amp. Ref. Circuit F1G Starter Enabling Switch • Do not use fuses having a higher amperage F2G Engine Ignition Key than that recommended, since they can F3G Cabin Fuses Board damage the electric system seriously.
  • Page 96 Operator’s Manual Second Edition - Second Printing Maintenance REFUELLING REFUELLING Part Product Capacity (litres) Diesel engine Engine oil Engine cooling system Water+antifreeze Fuel tank Diesel fuel Hydraulic system tank Hydraulic oil Gearbox Differential gears Wheel reduction gears 0.75 PRODUCT SPECIFICATIONS Engine oil Use the oil recommended by the Diesel engine Manufacturer (see the relevant handbook delivered with the machine).
  • Page 97 Second Edition - Second Printing Operator’s Manual Maintenance Fuel Grease Refuel through cap A. Use only Diesel fuel with For the machine greasing, use: less than 0.5% sulphur content, according to Lithium-based the specifications of the diesel engine operation When greasing by Vanguard LIKO handbook.
  • Page 98 Operator’s Manual Second Edition - Second Printing Intentionally blank page GTH-4013EX - GTH-4514EX - GTH-4017EX Part No. 57.0009.0454 Courtesy of Crane.Market...

  • Page 99: Faults And Troubleshooting

    Second Edition - First Printing Operator’s Manual Faults and Troubleshooting FAULTS AND TROUBLESHOOTING WARNING This chapter represents a practical guide for the operator for fixing the most common failures and, at the same time, detecting those interventions that must be carried out by qualified technical engineers. Any repair work, maintenance or troubleshooting If you are unsure about anything, do not carry out must be carried out with machine stopped, boom...
  • Page 100 Operator’s Manual Second Edition - First Printing Faults and Troubleshooting PROBLEM CAUSES SOLUTIONS • Stop and restart the machine to RESET the system. If the error message is still 1 E2PROM error shown, address to the TEREXLIFT service centre to re-calibrate the machine. •...
  • Page 101 Second Edition - First Printing Operator’s Manual Faults and Troubleshooting PROBLEM CAUSES SOLUTIONS • Stop and restart the machine. If the error A Data error in RAM message is still shown, address to the TEREXLIFT service centre. ERROR MESSAGES • An input is not read.
  • Page 102 Operator’s Manual Second Edition - First Printing Faults and Troubleshooting TRANSMISSION PROBLEMS DIAGNOSTICS By interpreting the series of blinks of the transmission indicator light 20 (see paragraph Controls and ERROR Instruments), it is possible to identify the problems occurred in electric components. Each sequence is a number where long blinks mean tens and short blinks mean units Short shimmering before code transmission...
  • Page 103 Second Edition - First Printing Operator’s Manual Faults and Troubleshooting TORQUE WRENCH SETTINGS D x p Pre-loading (N) Torque wrench setting (Nm) 10.9 12.9 10.9 12.9 M 4 x 0,7 1970 3930 5530 6640 M 5 x 0,8 3180 6360 8950 10700 10,1...
  • Page 104 Operator’s Manual Second Edition - First Printing Intentionally blank page GTH-4013EX - GTH-4514EX - GTH-4017EX Part No. 57.0009.0454 Courtesy of Crane.Market...

  • Page 105: Optional Attachments

    Second Edition - First Printing Operator’s Manual Optional Attachments INTRODUCTION This section provides information on the optional interchangeable attachments, especially manufac- tured for the handlers. Use only genuine attachments, described in this section, after having read their features thoroughly and understood their use. To install and remove the attachments, follow the instructions supplied in the “Operating Instructions”...
  • Page 106 Operator’s Manual Second Edition - First Printing Optional Attachments 800 LITRES SHOVEL CAU T I ON (code 59.0202.0000 for GTH-4013EX) (code 59.0200.7000 for GTH-4017EX) (code 59.0200.4000 for GTH-4514EX) Attachment suitable for moving loose material. Do not use for digging operations. Application Quick coupling attachment for moving soil, sand, debris, cereals, etc.
  • Page 107 Second Edition - First Printing Operator’s Manual Optional Attachments 500 LT MIXING BUCKET (code 59.0401.0000) Application Quick coupling attachment for mixing and distributing concrete. Safety Strictly obey the general safety precautions given in section “Safety”. Operation To load/unload the material, operate the rotation lever of the attachment holding plate.
  • Page 108 Operator’s Manual Second Edition - First Printing Optional Attachments 500 LITRES CONCRETE SKIP (code 59.0400.0000 _ Manual Version) Application Attachment coupled to the standard forks of the (code 59.0400.1000 _ Hydraulic Version) handler and fixed by means of the special chains with shackle provided.
  • Page 109 Second Edition - First Printing Operator’s Manual Optional Attachments 800 LITRES CONCRETE SKIP (code 59.0400.2000 _ Manual Version) Application Attachment coupled to the standard forks of the (code 59.0400.3000 _ Hydraulic Version) handler and fixed by means of the special chains with shackle provided.
  • Page 110 Operator’s Manual Second Edition - First Printing Optional Attachments FORKS WITH HYDRAULIC SIDE-SHIFT (code 59.0601.2000) Application Quick-coupling fitted attachment for handling palletised loads with possibility of shifting the load to the side by ± 100 mm. Safety Strictly obey the general safety precautions given in section “Safety”.
  • Page 111 Second Edition - First Printing Operator’s Manual Optional Attachments 4000 KG FIXED HOOK ON PLATE (code 59.0700.4000) Application Quick-coupling fitted attachment for lifting loads by means of special slings. Safety Strictly obey the general safety precautions given in section “Safety”. Do not oscillate the load.
  • Page 112 Operator’s Manual Second Edition - First Printing Optional Attachments 900 KG EXTENSION JIB (code 59.0802.0000 _ Mechanical Version) Application Quick-coupling fitted attachment for maintenance (code 59.0801.9000 _ Hydraulic Version interventions at high working heights. for GTH-4013EX and GTH-4514EX) (code 59.0802.2000 _ Hydraulic Version Safety for GTH-4017EX) Strictly obey the general safety precautions given...
  • Page 113 Second Edition - First Printing Operator’s Manual Optional Attachments 2000 KG EXTENSION JIB (code 59.0802.3001 _ Mechanical Version) Application Quick-coupling fitted attachment for maintenance interventions at high working heights. Safety Strictly obey the general safety precautions given in section “Safety”. Never lift wrongly slung loads.
  • Page 114 Operator’s Manual Second Edition - First Printing Optional Attachments 3000 KG HYDRAULIC WINCH (code 59.0901.4000 for GTH-4013EX Application and GTH-4514EX) Quick-coupling fitted attachment for lifting loads by means of special slings. (code 59.0901.5000 for GTH-4017EX) Safety Strictly obey the general safety precautions given in section “Safety”.
  • Page 115 Second Edition - First Printing Operator’s Manual Optional Attachments BASKET FOR BRICKS (code 59.0400.7000) Application Attachment used to handle construction manufactured products, to be fixed to the standard forks of the handler and locked in position with the chains with shackles supplied.
  • Page 116 Operator’s Manual Second Edition - First Printing Intentionally blank page GTH-4013EX - GTH-4514EX - GTH-4017EX Part No. 57.0009.0454 Courtesy of Crane.Market...

  • Page 117: Specifications

    Second Edition - First Printing Operator’s Manual Specifications GTH-4514 EX GTH 4017 EX GTH 4013 EX MAIN DIMENSIONS A Overall height ............mm 2560 2610 2400 B Height to the steering wheel ........mm 1600 1650 1600 C Overall width ............mm 2450...
  • Page 118 Operator’s Manual Second Edition - First Printing Specifications GTH-4514 EX GTH-4017 EX GTH-4013 EX PAYLOAD AND REACH • Lifting height (max) with outriggers ....mm 13710 16720 13000 • Lifting height (max) without outriggers ..mm 13560 16590 12810 • Reach at maximum height ......mm 1900 •...

  • Page 119: Load Charts

    Second Edition - First Printing Operator’s Manual Load Charts LOAD CHART WITH FORKS GTH 4017 EX ON STAB GTH-4017 EX 09.4618.0876 Part No. 57.0009.0454 GTH-4013EX - GTH-4514EX - GTH-4017EX Courtesy of Crane.Market...
  • Page 120 Operator’s Manual Second Edition - First Printing Load Charts LOAD CHART WITH FORKS GTH 4017 EX ON TYRES GTH-4017 EX 09.4618.0877 GTH-4013EX - GTH-4514EX - GTH-4017EX Part No. 57.0009.0454 Courtesy of Crane.Market...
  • Page 121 Second Edition - First Printing Operator’s Manual Load Charts LOAD CHART WITH HOOK GTH 4017 SX ON TYRES GTH-4017 EX 09.4618.0878 Part No. 57.0009.0454 GTH-4013EX - GTH-4514EX - GTH-4017EX Courtesy of Crane.Market...
  • Page 122 Operator’s Manual Second Edition - First Printing Load Charts LOAD CHART WITH HOOK GTH 4017 EX ON OUTRIGGERS GTH-4017 EX 09.4618.0879 GTH-4013EX - GTH-4514EX - GTH-4017EX Part No. 57.0009.0454 Courtesy of Crane.Market...
  • Page 123 Second Edition - First Printing Operator’s Manual Load Charts LOAD CHART WITH WINCH GTH 4017 EX ON TYRES GTH-4017 EX 09.4618.0880 Part No. 57.0009.0454 GTH-4013EX - GTH-4514EX - GTH-4017EX Courtesy of Crane.Market...
  • Page 124 Operator’s Manual Second Edition - First Printing Load Charts LOAD CHART WITH WINCH GTH 4017 EX ON OUTRIGGERS GTH-4017 EX 09.4618.0881 GTH-4013EX - GTH-4514EX - GTH-4017EX Part No. 57.0009.0454 Courtesy of Crane.Market...
  • Page 125 Second Edition - First Printing Operator’s Manual Load Charts LOAD CHART WITH 900 KG JIB GTH 4017 EX ON WHEEL GTH-4017 EX 09.4618.0882 Part No. 57.0009.0454 GTH-4013EX - GTH-4514EX - GTH-4017EX Courtesy of Crane.Market...
  • Page 126 Operator’s Manual Second Edition - First Printing Load Charts LOAD CHART WITH 900 KG JIB GTH 4017 EX ON OUTRIGGERS GTH-4017 EX 09.4618.0883 GTH-4013EX - GTH-4514EX - GTH-4017EX Part No. 57.0009.0454 Courtesy of Crane.Market...
  • Page 127 Second Edition - First Printing Operator’s Manual Load Charts LOAD CHART WITH SHOVEL GTH 4017 EX ON WHEEL GTH-4017 EX 09.4618.0884 Part No. 57.0009.0454 GTH-4013EX - GTH-4514EX - GTH-4017EX Courtesy of Crane.Market...
  • Page 128 Operator’s Manual Second Edition - First Printing Load Charts LOAD CHART WITH SHOVEL GTH 4017 EX ON OUTRIGGERS GTH-4017 EX 09.4618.0885 GTH-4013EX - GTH-4514EX - GTH-4017EX Part No. 57.0009.0454 Courtesy of Crane.Market...
  • Page 129 Second Edition - First Printing Operator’s Manual Load Charts LOAD CHART WITH 2P/500 REM 4400 MAN-PLATFORM GTH 4017 EX 2P/500 4400 GTH-4017 EX 09.4618.0873 Part No. 57.0009.0454 GTH-4013EX - GTH-4514EX - GTH-4017EX Courtesy of Crane.Market...
  • Page 130 Operator’s Manual Second Edition - First Printing Load Charts LOAD CHART WITH 2P/300 F MAN-PLATFORM GTH 4017 EX 300 F GTH-4017 EX 09.4618.0874 GTH-4013EX - GTH-4514EX - GTH-4017EX Part No. 57.0009.0454 Courtesy of Crane.Market...
  • Page 131 Second Edition - First Printing Operator’s Manual Load Charts LOAD CHART WITH 2P/1000 REM 5500 MAN-PLATFORM GTH 4017 EX 2P/1000 5500 GTH-4017 EX 09.4618.0875 Part No. 57.0009.0454 GTH-4013EX - GTH-4514EX - GTH-4017EX Courtesy of Crane.Market...
  • Page 132 Operator’s Manual Second Edition - First Printing Load Charts LOAD CHART WITH FORK GTH 4013 EX ON OUTRIGGERS GTH-4013 EX - SX 09.4618.0867 GTH-4013EX - GTH-4514EX - GTH-4017EX Part No. 57.0009.0454 Courtesy of Crane.Market...
  • Page 133 Second Edition - First Printing Operator’s Manual Load Charts LOAD CHART WITH HOOK GTH 4013 EX ON WHEEL GTH-4013 EX - SX 09.4618.0868 Part No. 57.0009.0454 GTH-4013EX - GTH-4514EX - GTH-4017EX Courtesy of Crane.Market...
  • Page 134 Operator’s Manual Second Edition - First Printing Load Charts LOAD CHART WITH HOOK GTH 4013 EX ON OUTRIGGERS GTH-4013 EX - SX 09.4618.0869 GTH-4013EX - GTH-4514EX - GTH-4017EX Part No. 57.0009.0454 Courtesy of Crane.Market...
  • Page 135 Second Edition - First Printing Operator’s Manual Load Charts LOAD CHART WITH 900 KG JIB GTH 4013 EX ON WHEEL GTH-4013 EX - SX 09.4618.0886 Part No. 57.0009.0454 GTH-4013EX - GTH-4514EX - GTH-4017EX Courtesy of Crane.Market...
  • Page 136 Operator’s Manual Second Edition - First Printing Load Charts LOAD CHART WITH 900 KG JIB GTH 4013 EX ON OUTRIGGERS GTH-4013 EX - SX 09.4618.0887 GTH-4013EX - GTH-4514EX - GTH-4017EX Part No. 57.0009.0454 Courtesy of Crane.Market...
  • Page 137 Second Edition - First Printing Operator’s Manual Load Charts LOAD CHART WITH WINCH GTH 4013 EX ON OUTRIGGERS GTH-4013 EX - SX 09.4618.0888 Part No. 57.0009.0454 GTH-4013EX - GTH-4514EX - GTH-4017EX Courtesy of Crane.Market...
  • Page 138 Operator’s Manual Second Edition - First Printing Load Charts LOAD CHART WITH WINCH GTH 4013 EX ON WHEEL GTH-4013 EX - SX 09.4618.0889 GTH-4013EX - GTH-4514EX - GTH-4017EX Part No. 57.0009.0454 Courtesy of Crane.Market...
  • Page 139 Second Edition - First Printing Operator’s Manual Load Charts LOAD CHART WITH SHOVEL GTH 4013 EX ON WHEEL GTH-4013 EX - SX 09.4618.0892 Part No. 57.0009.0454 GTH-4013EX - GTH-4514EX - GTH-4017EX Courtesy of Crane.Market...
  • Page 140 Operator’s Manual Second Edition - First Printing Load Charts LOAD CHART WITH SHOVEL GTH 4013 EX ON OUTRIGGERS GTH-4013 EX - SX 09.4618.0893 GTH-4013EX - GTH-4514EX - GTH-4017EX Part No. 57.0009.0454 Courtesy of Crane.Market...
  • Page 141 Second Edition - First Printing Operator’s Manual Load Charts LOAD CHART WITH 2P/300 F MAN-PLATFORM GTH 4013 EX 300 F GTH-4013 EX 09.4618.0890 Part No. 57.0009.0454 GTH-4013EX - GTH-4514EX - GTH-4017EX Courtesy of Crane.Market...
  • Page 142 Operator’s Manual Second Edition - First Printing Load Charts LOAD CHART WITH 2P/500 REM 4400 MAN-PLATFORM GTH 4013 EX 2P/500 4400 GTH-4013 EX 09.4618.0891 GTH-4013EX - GTH-4514EX - GTH-4017EX Part No. 57.0009.0454 Courtesy of Crane.Market...
  • Page 143 Second Edition - First Printing Operator’s Manual Load Charts LOAD CHART WITH FROKS GTH 4514 EX ON OUTRIGGERS GTH-4514 EX 09.4618.0898 Part No. 57.0009.0454 GTH-4013EX - GTH-4514EX - GTH-4017EX Courtesy of Crane.Market...
  • Page 144 Operator’s Manual Second Edition - First Printing Load Charts LOAD CHART WITH FORKS GTH 4514 EX ON TYRES GTH-4514 EX 09.4618.0897 GTH-4013EX - GTH-4514EX - GTH-4017EX Part No. 57.0009.0454 Courtesy of Crane.Market...
  • Page 145 Second Edition - First Printing Operator’s Manual Load Charts LOAD CHART WITH HOOK GTH 4514 EX ON TYRES GTH-4514 EX 09.4618.0899 Part No. 57.0009.0454 GTH-4013EX - GTH-4514EX - GTH-4017EX Courtesy of Crane.Market...
  • Page 146 Operator’s Manual Second Edition - First Printing Load Charts LOAD CHART WITH HOOK GTH 4514 EX ON OUTRIGGERS GTH-4514 EX 09.4618.0900 GTH-4013EX - GTH-4514EX - GTH-4017EX Part No. 57.0009.0454 Courtesy of Crane.Market...
  • Page 147 Second Edition - First Printing Operator’s Manual Load Charts LOAD CHART WITH WINCH GTH 4514 EX ON TYRES GTH-4514 EX 09.4618.0901 Part No. 57.0009.0454 GTH-4013EX - GTH-4514EX - GTH-4017EX Courtesy of Crane.Market...
  • Page 148 Operator’s Manual Second Edition - First Printing Load Charts LOAD CHART WITH WINCH GTH 4514 EX ON OUTRIGGERS GTH-4514 EX 09.4618.0902 GTH-4013EX - GTH-4514EX - GTH-4017EX Part No. 57.0009.0454 Courtesy of Crane.Market...
  • Page 149 Second Edition - First Printing Operator’s Manual Load Charts LOAD CHART WITH 900 KG JIB GTH 4514 EX ON TYRES GTH-4514 EX 09.4618.0903 Part No. 57.0009.0454 GTH-4013EX - GTH-4514EX - GTH-4017EX Courtesy of Crane.Market...
  • Page 150 Operator’s Manual Second Edition - First Printing Load Charts LOAD CHART WITH 900 KG JIB GTH 4514 EX ON OUTRIGGERS GTH-4514 EX 09.4618.0904 GTH-4013EX - GTH-4514EX - GTH-4017EX Part No. 57.0009.0454 Courtesy of Crane.Market...
  • Page 151 Second Edition - First Printing Operator’s Manual Load Charts LOAD CHART WITH SHOVEL GTH 4514 EX ON TYRES GTH-4514 EX 09.4618.0905 Part No. 57.0009.0454 GTH-4013EX - GTH-4514EX - GTH-4017EX Courtesy of Crane.Market...
  • Page 152 Operator’s Manual Second Edition - First Printing Load Charts LOAD CHART WITH SHOVEL GTH 4514 EX ON OUTRIGGERS GTH-4514 EX 09.4618.0906 GTH-4013EX - GTH-4514EX - GTH-4017EX Part No. 57.0009.0454 Courtesy of Crane.Market...
  • Page 153 Second Edition - First Printing Operator’s Manual Load Charts LOAD CHART WITH 2P/500 REM 4400 MAN-PLATFORM GTH 4514 EX 2P/500 4400 GTH-4514 EX 09.4618.0894 Part No. 57.0009.0454 GTH-4013EX - GTH-4514EX - GTH-4017EX Courtesy of Crane.Market...
  • Page 154 Operator’s Manual Second Edition - First Printing Load Charts LOAD CHART WITH 2P/300 F MAN-PLATFORM GTH 4514 EX 300 F GTH-4514 EX 09.4618.0895 GTH-4013EX - GTH-4514EX - GTH-4017EX Part No. 57.0009.0454 Courtesy of Crane.Market...
  • Page 155 Second Edition - First Printing Operator’s Manual Load Charts LOAD CHART WITH 2P/1000 REM 5500 MAN-PLATFORM GTH 4514 EX 2P/1000 5500 GTH-4514 EX 09.4618.0896 Part No. 57.0009.0454 GTH-4013EX - GTH-4514EX - GTH-4017EX Courtesy of Crane.Market...
  • Page 156 Operator’s Manual Second Edition - First Printing Intentionally blank page GTH-4013EX - GTH-4514EX - GTH-4017EX Part No. 57.0009.0454 Courtesy of Crane.Market...

  • Page 157: Diagrams And Schemes

    Second Edition - First Printing Operator’s Manual Diagrams and Schemes WIRING DIAGRAM FOR GTH-4514 EX & GTH-4017 EX 1/10 Part No. 57.0009.0454 GTH-4013EX - GTH-4514EX - GTH-4017EX Courtesy of Crane.Market...
  • Page 158 Operator’s Manual Second Edition - First Printing Diagrams and Schemes WIRING DIAGRAM FOR GTH-4514 EX & GTH-4017 EX 2/10 GTH-4013EX - GTH-4514EX - GTH-4017EX Part No. 57.0009.0454 Courtesy of Crane.Market...
  • Page 159 Second Edition - First Printing Operator’s Manual Diagrams and Schemes WIRING DIAGRAM FOR GTH-4514 EX & GTH-4017 EX 3/10 Part No. 57.0009.0454 GTH-4013EX - GTH-4514EX - GTH-4017EX Courtesy of Crane.Market...
  • Page 160 Operator’s Manual Second Edition - First Printing Diagrams and Schemes WIRING DIAGRAM FOR GTH-4514 EX & GTH-4017 EX 4/10 GTH-4013EX - GTH-4514EX - GTH-4017EX Part No. 57.0009.0454 Courtesy of Crane.Market...
  • Page 161 Second Edition - First Printing Operator’s Manual Diagrams and Schemes WIRING DIAGRAM FOR GTH-4514 EX & GTH-4017 EX 5/10 Part No. 57.0009.0454 GTH-4013EX - GTH-4514EX - GTH-4017EX Courtesy of Crane.Market...
  • Page 162 Operator’s Manual Second Edition - First Printing Diagrams and Schemes WIRING DIAGRAM FOR GTH-4514 EX & GTH-4017 EX 6/10 GTH-4013EX - GTH-4514EX - GTH-4017EX Part No. 57.0009.0454 Courtesy of Crane.Market...
  • Page 163 Second Edition - First Printing Operator’s Manual Diagrams and Schemes WIRING DIAGRAM FOR GTH-4514 EX & GTH-4017 EX 7/10 Part No. 57.0009.0454 GTH-4013EX - GTH-4514EX - GTH-4017EX Courtesy of Crane.Market...
  • Page 164 Operator’s Manual Second Edition - First Printing Diagrams and Schemes WIRING DIAGRAM FOR GTH-4514 EX & GTH-4017 EX 8/10 GTH-4013EX - GTH-4514EX - GTH-4017EX Part No. 57.0009.0454 Courtesy of Crane.Market...
  • Page 165 Second Edition - First Printing Operator’s Manual Diagrams and Schemes WIRING DIAGRAM FOR GTH-4514 EX & GTH-4017 EX 9/10 Part No. 57.0009.0454 GTH-4013EX - GTH-4514EX - GTH-4017EX Courtesy of Crane.Market...
  • Page 166 Operator’s Manual Second Edition - First Printing Diagrams and Schemes WIRING DIAGRAM FOR GTH-4514 EX & GTH-4017 EX 10/10 GTH-4013EX - GTH-4514EX - GTH-4017EX Part No. 57.0009.0454 Courtesy of Crane.Market...
  • Page 167 Second Edition - First Printing Operator’s Manual Diagrams and Schemes WIRING DIAGRAM FOR GTH-4013 EX 1/10 Part No. 57.0009.0454 GTH-4013EX - GTH-4514EX - GTH-4017EX Courtesy of Crane.Market...
  • Page 168 Operator’s Manual Second Edition - First Printing Diagrams and Schemes WIRING DIAGRAM FOR GTH-4013 EX 2/10 GTH-4013EX - GTH-4514EX - GTH-4017EX Part No. 57.0009.0454 Courtesy of Crane.Market...
  • Page 169 Second Edition - First Printing Operator’s Manual Diagrams and Schemes WIRING DIAGRAM FOR GTH-4013 EX 3/10 Part No. 57.0009.0454 GTH-4013EX - GTH-4514EX - GTH-4017EX Courtesy of Crane.Market...
  • Page 170 Operator’s Manual Second Edition - First Printing Diagrams and Schemes WIRING DIAGRAM FOR GTH-4013 EX 4/10 GTH-4013EX - GTH-4514EX - GTH-4017EX Part No. 57.0009.0454 Courtesy of Crane.Market...
  • Page 171 Second Edition - First Printing Operator’s Manual Diagrams and Schemes WIRING DIAGRAM FOR GTH-4013 EX 5/10 Part No. 57.0009.0454 GTH-4013EX - GTH-4514EX - GTH-4017EX Courtesy of Crane.Market...
  • Page 172 Operator’s Manual Second Edition - First Printing Diagrams and Schemes WIRING DIAGRAM FOR GTH-4013 EX 6/10 GTH-4013EX - GTH-4514EX - GTH-4017EX Part No. 57.0009.0454 Courtesy of Crane.Market...
  • Page 173 Second Edition - First Printing Operator’s Manual Diagrams and Schemes WIRING DIAGRAM FOR GTH-4013 EX 7/10 Part No. 57.0009.0454 GTH-4013EX - GTH-4514EX - GTH-4017EX Courtesy of Crane.Market...
  • Page 174 Operator’s Manual Second Edition - First Printing Diagrams and Schemes WIRING DIAGRAM FOR GTH-4013 EX 8/10 GTH-4013EX - GTH-4514EX - GTH-4017EX Part No. 57.0009.0454 Courtesy of Crane.Market...
  • Page 175 Second Edition - First Printing Operator’s Manual Diagrams and Schemes WIRING DIAGRAM FOR GTH-4013 EX 9/10 Part No. 57.0009.0454 GTH-4013EX - GTH-4514EX - GTH-4017EX Courtesy of Crane.Market...
  • Page 176 Operator’s Manual Second Edition - First Printing Diagrams and Schemes WIRING DIAGRAM FOR GTH-4013 EX 10/10 GTH-4013EX - GTH-4514EX - GTH-4017EX Part No. 57.0009.0454 Courtesy of Crane.Market...
  • Page 177 capacity: Parking brake handle capacity: Double overcenter safety valve 0.5 Litri Stabilizers/chassis levelling 1.5 Litri selector valve Pressure piloting ratio: 4.2 1 precharge precharge switch cracking pressure: 350 bar main valve pressure pressure activating 50 bar pressure 35 bar Double overcenter safety valve piloting ratio: 4.2 1 Chassis levelling cylinders Quick coupling...
  • Page 178 capacity: 0.5 Litri Stabilizers/chassis levelling precharge main valve Double overcenter safety valve pressure Double overcenter safety valve piloting ratio: 4.2 1 50 bar piloting ratio: 4.2 1 Double overcenter safety valve cracking pressure: 350 bar cracking pressure: 350 bar piloting ratio: 4.2 1 Quick coupling cracking pressure: 350 bar Chassis levelling cylinders...

  • Page 179: Warranty

    Second Edition - First Printing Operator’s Manual Warranty LIMITED PRODUCT WARRANTY Genie Industries (“Seller”) warrants its new expressly limited to, at Seller’s sole option, repairing equipment manufactured and sold worldwide, to be or replacing, with new or remanufactured parts or components, any part, which appears to Seller...
  • Page 180 Operator’s Manual Second Edition - First Printing Warranty I T E M S N O T C O V E R E D B Y S E L L E R WARRANTY Seller reserves the right to inspect the installation of the product and review maintenance procedures The following items are not covered under the seller to determine if the failure was due to improper...
  • Page 181 Second Edition - First Printing Operator’s Manual Warranty Secondary Failures : should the owner or No action by any party shall operate to extend or operator continue to operate a machine after revive this limited warranty without the prior written It has been noted that a failure has occurred, consent of seller.
  • Page 182 Operator’s Manual Second Edition - First Printing Intentionally blank page GTH-4013EX - GTH-4514EX - GTH-4017EX Part No. 57.0009.0454 Courtesy of Crane.Market...
  • Page 183 Second Edition - First Printing Operator’s Manual WARRANTY - HANDING OVER CERTIFICATE Model Serial Number Delivery date Dealer’s stamp and signature ___________________ ___________________ ___________________ We hereby acknowledge that we received the machine in perfect condition, as well as the Operator’s Manual. DATAS OF THE OWNER: Note ___________________________...
  • Page 184 Courtesy of Crane.Market...

This manual is also suitable for:

Gth 4514 exGth 4017 ex

Table of Contents
