Service and Repair Manual
Deutz TD 2.9 L4 Engine Fault Codes
SPN = Suspect Parameter Number
FMI = Failure Mode Identifier
SPN FMI Description
23612 12 Internal ECU monitoring detection
reported error
23612 12 Internal software error ECU
23612 14 Softwarereset CPU SWReset_0
23612 14 Softwarereset CPU SWReset_1
23612 14 Softwarereset CPU SWReset_2
23613 0 Maximum positive deviation of rail
pressure exceeded (RailMeUn0)
23613 0 Maximum positive deviation of rail
pressure in metering unit exceeded
(RailMeUn1)
23613 0 Railsystem leakage detected
(RailMeUn10)
23613 0 Maximum negative deviation of rail
pressure in metering unit exceeded
(RailMeUn2)
23613 0 Negative deviation of rail pressure
second stage (RailMeUn22)
23613 0 Maximum rail pressure exceeded
(RailMeUn4)
23613 1 Minimum rail pressure exceeded
(RailMeUn3)
23613 2 Setpoint of metering unit in overrun
mode not plausible
23615 3 Metering unit (Fuel-System); short
circuit to battery highside
62
SPN FMI Description
23615 3 Metering unit (Fuel-System); short
circuit to battery low side
23615 4 Metering unit (Fuel-System); short
circuit to ground high side
23615 4 Metering Unit (Fuel-System); short
circuit to ground low side
23615 5 Metering unit (Fuel-System); open load
23615 12 Metering unit (Fuel-System);
powerstage over temperature
23619 2 Physical range check high for exhaust
gas temperature upstrem (SCR-CAT)
23698 11 Shut off request from supervisory
monitoring function
23717 12 Timeout Error of CAN-Transmit-Frame
AmbCon; Weather environments
23718 3 SCR mainrelay; short circuit to battery
(only CV56B)
23718 4 SCR mainrelay; short circuit to ground
(only CV56B)
23718 5 SCR mainrelay; open load (only
CV56B)
23718 12 SCR mainrelay; powerstage over
temperature (only CV56B)
23766 9 Timeout Error of CAN-Receive-Frame
Active TSC1AE
23767 9 Timeout Error of CAN-Receive-Frame
Passive TSC1AE
GTH-636
April 2018
Part No. 1287209GT
