DEMO MANUAL DC2453A

parts List

ITEM QTY REFERENCE
Required Circuit Components
1 2 C1, C3
2 1 C6
3 4 C9, C17 ,C28, C36
4 4 C10, C16, C29, C35
5 4 C25, C26, C45, C46
6 1 R1
7 1 R2
8 1 R3
9 1 R4
10 1 R11
11 1 R12
12 1 R28
13 1 U1
Additional Demo Board Circuit Components
1 2 C4, C5
2 1 C2
3 6 C7, C21, C22, C31, C41, C42
4 4 C8, C18, C27, C37
5 8 C11, C12, C14, C15, C30, C33, C34, C38
6 2 C13, C32
7 4 R7, R8, R15, R16
8 4 R19, R20, R21, R22
9 8 R23, R24, R25, R26, R27, R29, R30, R31 RES, 100k, 5%, 1/10W, 0603
10 16 R9, R10, R17, R18, R32-R35, R37-R40,
R42-R45
11 3 R36, R41, R46
Hardware
1 16 E1, E3-E17
2 2 J1, J2
3 8 JP1-JP8
4 8 XJP1-XJP8
5 4 STAND-OFFS
6
PART DESCRIPTION
CAP , CER, 22μF, 25V, X5R, 20%, 1206
CAP , X5R, 1μF, 16V 10%, 0603
CAP , CER, 47μF, 6.3V, X5R, 20%,1210
CAP , CER, 47μF, 6.3V, X5R, 20%, 1206
CAP , CER, 0.10μF, 50V, X7R, 10%, 0603
RES, 10k, 1%, 1/10W, 0603
RES, 1Ω, 5%, 1/10W, 0603
RES, 13.3k, 1%, 1/10W, 0603
RES, 40.2k, 1%, 1/10W, 0603
RES, 19.1k, 1%, 1/10W, 0603
RES, 60.4k, 1%, 1/10W, 0603
RES, 0805, 0Ω 5% 1/16W
LTM4643EV, BGA-15X9-5.01
CAP , CER, 22μF, 25V, X5R, 20%, 1206
CAP , POSCAP , 33μF, 25V, 7343
CAP , 0603
CAP , POSCAP , 7343
CAP , CER, 1206
CAP , CER, 100pF, 25V, X7R, 10%, 0603
RES, 0Ω, 1%, 1/10W, 0603
RES, 150k, 5%, 1/10W, 0603
RES, 0603,OPT
RES, 0 OHM, 2512,OPT
TESTPOINT, TURRET 0.094"
JACK, BANANA
HEADER, 0.079" SINGLE ROW, 3-PIN
SHUNT, 0.079" CENTER
STAND-OFF , NYLON 0.375" TALL (SNAP ON)
MANUFACTURER/PART NUMBER
MURATA, GRM31CR61E226ME15L
AVX, 0603YD105KAT2A
AVX, 12106D476MAT2A
TAIYO YUDEN, JMK316ABJ476MLHT
TDK, C1608X7R1H104K
VISHAY, CRCW060310K0FKED
VISHAY,CRCW06031R00JNEA
VISHAY CRCW060313K3FKEA
VISHAY CRCW060340K2FKEA
VISHAY CRCW060319K1FKEA
VISHAY CRCW060360K4FKEA
VISHAY, CRCW08050000Z0EA
LINEAR TECH. CORP . LTM4643EV#PBF
MURATA, GRM31CR61E226ME15L
PANASONIC, 25TQC33MYF
OPTION
OPTION
OPTION
AVX 06033C101KAT2A
VISHAY, CRCW06030000Z0ED
VISHAY CRCW0603150KJNEA
VISHAY CRCW0603100KJNEA
OPT
OPT
MILL MAX 2501-2-00-80-00-00-07-0
KEYSTONE 575-4
SULLINS, NRPN031PAEN-RC
SAMTEC, 2SN-BK-G
KEYSTONE, 8832
