Displaying Software Versions

1. Tap Settings .
2. Tap [About].
3. Swipe the list of software versions up to display the complete list.
4. Tap [Continue].

Troubleshooting

This section is intended to help you solve problems that you might encounter when using the 3M Clean-Trace
Luminometer. Contact 3M or your local 3M distributor for more information.
Problem Probable Cause
Battery Low Battery needs to be charged
message
Diagnostic Check
Failed Message
Incorrect Swab
Detected
No Display a. Instrument in Sleep mode
b. Battery fully discharged
c. Instrument malfunction
No Swab
Detected
Results Lower a. Sample / reagent problem
than Expected
b. Instrument malfunction
Rocker Cap Open Rocker cap was open while you
message attempted to start the reading process
Swab Left in
Chamber
Swab Not
Recognized
The Luminometer
was dropped
The Luminometer
might have
experienced a
mechanical shock
Test Cancelled Luminometer tilted during test
measurement
Solution
Turn the 3M Clean-Trace Luminometer off. DO NOT do
testing if a BATTERY LOW warning is displayed. Connect
the charging cable to the 3M Clean-Trace Luminometer
and to the power mains.
Tap [Try Again] to repeat the Diagnostic Check. If the
Diagnostic Check fails again, contact 3M or your local
distributor.
Insert a 3M Clean-Trace Test.
a. Press the up arrow button on the control panel for
3 seconds
b. Recharge the battery.
c. Contact 3M or your local distributor.
Insert a 3M Clean-Trace Test.
a. Check with a new 3M Clean-Trace Test and known
positive samples such as a 3M™ Clean-Trace™
Surface Positive Control or 3M™ Clean-Trace™ Water
Positive Control.
b. Contact 3M or your local distributor.
Close the rocker cap after you insert a 3M Clean-Trace Test
and before you start the reading process.
To prevent leakage into the chamber, if a 3M Clean-Trace
Test is left in the chamber for more than 30 seconds
following the completion of a measurement, this message
along with an audible tone reminds you to remove the test
from the chamber after the measurement is complete.
Insert a 3M Clean-Trace Test.
Turn power off and wait for 5 minutes. Restart the
Luminometer. If there is no error message, the
Luminometer is OK to use.
Turn power off and wait for 5 minutes. Restart the
Luminometer. If there is no error message, the
Luminometer is OK to use.
The test was cancelled. Please hold the Luminometer firmly
and pointed at most 68 degrees from vertical.
