off Which means that the fiber optic connector is operating in
half-duplex mode. Flashing green indicates for collision.
FDX/HDX Switch
FDX: The UTP port operate in full-duplex mode ;
!
HDX: The UTP port operate in haf-duplex mode;
!
Notice: You must reset the converter when you achieve the
configuration.
Installation Guide
TR-965DA's
SC fiber connector works at 1550nm on transferring
data and at 1310nm on receiving data in one single-mode
fiber.
TR-965DB's
SC fiber connector, inversely, works at 1310nm
on transferring data and at 1550nm on receiving data in a fiber. So
the
TR-965DA and the TR-965DB must use as partnership
together.
Configuration
In order to achieve the aim of effectively expanding a Fast
Ethernet network, You can use the converter for the example :
5
Table of Contents
Introduction...............................................................................2
Features....................................................................................2
Network Cable Supported..........................................................3
Package Contents.....................................................................3
Appearance Indication...............................................................4
Installation Guide......................................................................5
Appendix
Specifications...........................................................7
1
Position two converters back to back between the following end
devices.
Twisted-pair
Single fiber
Twisted-pair
Device A
TR-965DA
TR-965DB
Device B
10/100Base-TX
100Base-FX
10/100Base-TX
interface
interface
interface
Installation Procedure
1.
Converter to 10/100Base-TX Device (hub or switch)
Connection
Make sure that the length of twisted pair cable (Category-5)
!
between 10/100Base-TX device and converter is no longer
than 100 meters.
Connect one end of twisted pair cable to RJ45 jack on the
!
converter and the other end of the cable to the RJ45 jack on
the 10/100Base-TX device.
2.
Converter to Converter or 100Base-FX Device Connection
Connect one (SC) end of a fiber cable to the SC connector on
the converter and the other end of the cable to the SC
6
Introduction
The TR-965DA/TR-965DB are 10/100Mbps Fast Ethernet
converter. The converter mediates between a 10/100Base-TX
segment and a 100Base-FX segment.It is primarily designed for
large, more high speed/bandwidth demanding workgroups that
require expansion of the Fast Ethernet network.
FDX
HDX
9V~
50Hz
0.8A
UTP
AC power connector
SC fiber connetor
RJ45 connetor
Features
Complies with IEEE802.3u 10Base-T, 100Base-TX and
!
100Base-FX standard.
Provide one SC fiber connector and one UTP connector.
!
The SC fiber connector can transfer and receive data on
!
one single-mode fiber.
Provide switch configuration of half/full duplex transfer
!
mode for FX port.
Extend fiber distance up to 20-60km for single-mode fiber.
!
2
connector on the other converter or 100Base-FX device.
3.
Turn on the power
Appendix Specifications
Standard:
IEEE 802.3/IEEE 802.3u
Connector:
1 SC fiber optic; 1 RJ45 jack
Max. Distance:
Twisted Pair(Cat5):100m
Single-mode Fiber Optic: 20km
Power:
external power adapter supply, AC 9V~ 0.8A
O
O
O
O
Temperature:
Operation: 0 C~40 C (32 F~104 F)
O
O
O
O
Storage: -40 C~70 C (-40 F~158 F)
Humidity:
10%-90% (non-condensing)
Dimensions
4.84x2.64x0.94 in.
123mmx67mmx24 mm
(
LxWxH
):
(
)
7
Easy-to-view LED indicators provide status to monitor
!
network activity easily.
External power adapter supply.
!
Network Cable Supported
The connectors and network cables supported by the converter
are listed in the following:
UTP: Cat 5 Twisted-Pair
Fiber SC: 1300nm 62.5/125 Single-mode Fiber
Type
Connetor Transmission Distance Transmission Media
TR-965DA-20
RJ45--SC
20km
Single-mode Fiber,Cat-5
TR-965DA-40
RJ45--SC
40km
Single-mode Fiber,Cat-5
TR-965DA-60
RJ45--SC
60km
Single-mode Fiber,Cat-5
TR-965DB-20
RJ45--SC
20km
Single-mode Fiber,Cat-5
TR-965DB-40
RJ45--SC
40km
Single-mode Fiber,Cat-5
TR-965DB-60
RJ45--SC
60km
Single-mode Fiber,Cat-5
Package Contents
Before start using the products, make sure that what you have is
what you ordered.
The Converter includes:
One Converter
!
3
User's Guide
TR-965DA
TR-965DB
10/100Mbps Fast Ethernet Converter
Rev 1.0
71030498
One AC adapter
!
This User's Guide
!
Appearance Indication
LED Indicators
This converter has LED indicators which can provide a real-time
report. When you take a look at these indicators, you will know
what's happening on your network.
Power(green) Lights when the adapter is properly plugged
!
in.
TX_SPD(green) Lights when the UTP ports is connected to
!
100Base-Tx device.
TX_LINK/ACT(green) Steady green indicates that a valid
!
link exists. Flashing green indicates that the converter is
receiving data or transmitting data from the RJ45 connector.
FX_LINK/ACT(green) Steady green indicates that a valid
!
link exists. Flashing green indicates that the converter is
receiving data or transmitting data from the Fiber Optic
connector.
FX_FDX/COL(green) Steady green indicates that the fiber
!
optic connector is operating in full-duplex mode. The light is
4
