Mounting the Bracket and Baffl e Filter
1. Insert the charcoal filter bracket into back side of baffle fi
lter (side without handles). The (2) tabs on the bottom
of the bracket should be inserted into the baffle filter
first. Push the bracket towards the baffle filter to lock
bracket in place. There is a clip on top of the bracket
that will secure it to the baffle filter. (Fig. C) Repeat this
step for each bracket.
Installing the Charcoal Filter
1. Insert the charcoal filter into the bracket. Tab cut-out
side of the charcoal filter should be installed first then
push down on the filter to lock in place. (Fig. D)
Fig. C
Fig. D
5
clip
tab
tab
