Summary of Contents for Westermo ADSL-350
- Page 1 User Guide 6623-2231 ADSL-350 Industrial ADSL Router www.westermo.com...
-
Page 2: Legal Information
Under no circumstances shall Westermo be responsible for any loss of data or income or any special, incidental, and consequential or indirect damages howsoever caused. -
Page 3: Before Installation
Do not use or store the unit in dusty, dirty areas, connectors as well as other mechanical part may be damaged. If the unit is not working properly, contact the place of purchase, nearest Westermo dis- tributor office or Westermo Tech support. -
Page 4: Agency Approvals And Standards Compliance
Agency approvals and standards compliance Type Approval / Compliance EN 55024, EN 55024 A1, EN 55024 A2, Electromagnetic compatibility – Immunity IT equipment EN 55022, EN 55022 A1, Information technology equipment. Radio disturbance characteristics. Limits and methods of measurement Safety EN 60950-1, IT equipment 6623-2231... -
Page 5: Declaration Of Conformity
Declaration of Conformity, ADSL-350 Westermo Teleindustri AB Declaration of conformity The manufacturer Westermo Teleindustri AB SE-640 40 Stora Sundby, Sweden Herewith declares that the product(s) Type of product Model Art no ADSL router / ADSL 350 3623-0301 Modem is in conformity with the following EC directive(s). -
Page 6: Type Tests And Environmental Conditions
Type tests and environmental conditions Phenomena Test Description Test levels EN 61000-4-2 Enclosure contact ± 4 kV (crit A) Enclosure air ± 8 kV (crit A) RF field AM modulated IEC 61000-4-3 Enclosure 10 V/m (crit A) (80 – 2700 MHz) Fast transient EN 61000-4-4 Signal ports... -
Page 7: Dimensional Drawing
ADSL-standards and has support for long lines. Most devices today comes equipped with an Ethernet port for communications, therefore the ADSL-350 has a built-in two port Ethernet switch. For legacy connectivity the unit also features one RS-232-port to provide multiple connection possibilities for both new and legacy replacement installations. -
Page 8: Interface Specifications
Interface specifications Power Rated voltage 12 – 48 VDC Operating voltage 10 – 60 VDC Rated current (max) 520 mA @ 12 VDC Start-up current (max) 5500 mA @ 12 VDC Rated frequency RS-232 Electrical specification EIA RS-232 Data rate 300 bit/s –... - Page 9 Data rate 30 Mbit Downlink, 3 Mbit Uplink Protocol LLC/VC-MUX encap Ethernet, PPPoA, PPPoE, IPoA Connection RJ-11 Shielded cable Not required, except when installed in Railway applications as signalling and telecommunications apparatus and located close to rails.* Number of ports Standard Annex ITU-T G.992.1 (ADSL)
-
Page 10: Power Connector
Connections Factory default reset switch ADSL-350 (for details, see page 11) Ethernet TX Connections Led indicators (RJ-45 connector) LAN1-2 (for details, see next page) Position Direction Description In/Out In/Out TD– In/Out – Not Connected Protective – Not Connected Earth In/Out RD–... -
Page 11: Led Indicators
SIG LED, this is normal behavior during boot-up and does not indicate a fault. Configuring a VPN connection in the ADSL-350 and activating the service will cause the STS LED to be lit GREEN but FLASH RED every third (3) second to indicate that no peer is connected on the VPN. -
Page 12: Factory Default Reset Switch
Factory Default Reset Switch The reset switch is used to restore the configuration of the ADSL-350 to the factory default settings (for details about the default settings see the Getting started section). The switch is accessed through a small hole, adjacent to the PWR and STS LEDs, labeled C on the front of the unit. - Page 13 Protocols and Functionality Ethernet Technologies IEEE 802.3 for 10BaseT IEEE 802.3u for 100BaseTX Layer-2 QoS IEEE 802.1p Class of Service ADSL Technologies ITU-T G.992.1 ADSL (Annex A (non overlap)) ITU-T G.992.2 ADSL Lite (Annex A (non overlap)) ITU-T G.992.3 ADSL2 (Annex A, I, L, M (non overlap)) ITU-T G.992.5 ADSL2+ (Annex A, I, M (non overlap)) RFC2684 Bridged LLC and Bridged VC-MUX ATM encap.
-
Page 14: Getting Started
Power Supply The ADSL-350 requires a DC power source in the voltage range of 10 to 60 VDC. The unit is designed to self protect from permanent damage if the voltage exceeds 60 VDC or if reverse polarity is applied. The router may need to be returned for service if this occurs. - Page 15 After step 3 an authorization box will popup which asks for a username and a password. Please type in the following Username admin Password westermo Step 5 – Welcome screen You have now successfully logged into the unit and reached the Status-page that lists the current status of the unit and the services.
- Page 16 Sometimes you also get the information in your “start-package” from the provider. If you are unable to find these settings, please do not hesitate to contact Westermo Support, see the last page for details in your country, or have a look on the Westermo website.
- Page 17 Step 8 – Configure the ADSL connection – part 1 Using your specific provider details you may need to change the VPI, and VCI settings on this first screen. When you have verified that the settings match, please click on Next. Step 9 –...
- Page 18 Complete the required fields for your connection and then click on Submit. The ADSL-350 will then reconfigure the ADSL settings of the unit and set up the connection. You can follow the process by either looking at the SIG and DSL LEDs on the physical unit, or look at the ADSL Status page by clicking on the top level menu Status, followed by the ADSL sub-menu.
-
Page 19: Changing The Default Password
After clicking on the pen, a new page will be shown where the password of both the admin and guest* user. Unless the ADSL-350 should use a Radius server to centrally authenticate the login, the Radius configuration details can be ignored. -
Page 20: Changing The Lan Ip Address
IP address that the unit requires and, if needed, also update the Netmask, then click on Update. The ADSL-350 will then display a page with a link to the new IP address and then change its IP, no reboot is required. - Page 21 Network Address Translation and firewalling to protect clients on the local network. In order to configure any LAN clients to use the ADSL-350 as their gateway the follow- ing to methods can be used; If the clients have a DHCP address allocated by the ADSL-350, they will have learned the necessary settings.
- Page 22 DDNS name, or using a fixed IP address from a PC on the Internet. Since the ADSL-350 is cyber secured by a firewall by default, the user must first allow traffic from the Internet trying to access the web-interface / webserver of the ADSL-350 to pass through.
- Page 23 IP address of the ADSL-350 to communicate with devices attached to the LAN, or Serial, side of the unit. In our example an HMI is connected to the LAN port of the ADSL-350, and has been configured with the ADSL-350 as its default gateway;...
- Page 24 Internet to the ADSL-350 on a specific port to be forwarded to the HMI. For the purpose of this example the incoming port that the PC will be using is 12345.
- Page 25 Mounting This unit should be mounted on 35 mm DIN-rail, which is horizontally mounted inside an apparatus cabinet or similar. Snap on mounting, see figure. Mounting the ADSL-350 with integrated DIN-clip: Cooling 10mm 10mm The router should be mounted in a...
- Page 26 Tel: +86 21 6145 0400 • Fax: +86 21 6145 0499 FR-91160 Champlan sales.cn@westermo.com • www.cn.westermo.com Tel: +33 1 69 10 21 00 • Fax: +33 1 69 10 21 01 infos@westermo.fr • www.westermo.fr Westermo Teleindustri AB have distributors in several countries, contact us for further information.
