If you're unsure of the correct COM port, click the Detect SMART Hardware button
under Automatic to initiate SMART Board detection. Your COM ports will be searched
for the presence of an attached SMART Board until the correct COM port is located.
The Ready Light on the Pen Tray will change from red to green, indicating the SMART
Board is now touch sensitive. Open the SMART Board tools to use any Pen Tray stylus
to write over projected applications.
Windows USB Adapter Cable Setup
Win
1 Connect the short DB9 end of the optional USB adapter cable to the 9-pin serial port
underneath the SMART Board (see the upper figure on page iv).
NOTE: To order a SMART USB adapter cable (part # USB-FRU), call SMART
Technologies Inc. at 1.888.42.SMART.
2 Connect the USB connector at the other end of this cable to the USB port on your
computer.
3 If you already have the appropriate USB driver installed on your system, the Ready
Light on the Pen Tray will turn red and you can proceed to install SMART Board
Software (step 4 on the next page).
If you don't have the appropriate driver installed, a Found New Hardware wizard will
appear to assist you in locating the driver for the newly connected USB Human
Interface Device (the SMART Board).
•
•
•
vi
Direct Windows to search for an appropriate driver by clicking the Next button.
Click Next again to direct Windows to search the driver database on your hard drive
for the appropriate driver.
NOTE: If Windows fails to find the correct driver, insert the Windows 98/2000/ME/XP
CD in your CD-ROM to install a USB HID (Human Interface Device) driver. USB HID
drivers are typically not included in a default installation. HID is a subclass of USB
devices. These drivers are needed for the SMART Board to work using a USB cable.
Click the Finish button after the driver search or driver installation is complete.
USB Port
Preface
