Smart Technologies SMART BOARD User Manual page 11

4
Turn on your Macintosh.
NOTE: The Ready Light on the Pen Tray will turn red when you turn on your
Macintosh. This indicates it is receiving power from your keyboard port or external
power supply.
5 Insert the SMART Board Software CD into your CD-ROM drive. The CD will
automatically launch the installation program. Follow the on-screen instructions.
Immediately following SMART Board Software installation, you'll notice the Ready Light
on the Pen Tray turns from red to green. This indicates that the SMART Board is now
fully touch sensitive.
6 Press on the SMART Board icon in the menu bar and select Control Panel from the
drop-down menu.
7 In the Boards tab, press the Select button under Serial Ports.
The Pick a Port dialog will appear.
8 If you know the port to which the SMART Board is connected, select it from the Port
List and press the OK button.
or
If you're unsure of the correct port, press the Auto Detect button to initiate SMART
Board detection. Your ports will be searched for the presence of an attached SMART
Board until the correct port is located.
The Ready Light in the Pen Tray will change from red to green, indicating the SMART
Board is now touch sensitive.
9 Press the Orient button to perform a brief orientation procedure to more accurately
map the location of each Board contact (see page 7 for more information).
Ready Light
Preface
ix
