Capturing Entire Files With Print Capture - Smart Technologies SMART BOARD User Manual

Tip
If you've captured a
screen or window into
Notebook, you can
make it a selectable
object by selecting
Retrieve Background
from the Tools menu.
Then press the Select
tool and press once on
the screen or window
to select it.
56
To capture a selected screen area:
1 Press the Area Selection button in the Screen Capture toolbar.
The cursor changes to a camera icon.
2 Move the camera cursor to the area of the screen you want to capture.
3 Press and drag to outline the exact area you want captured.
The captured portion of the screen will appear in the top-left corner of a new Notebook
page.
To capture a window:
1 Go to the window you want to capture.
2 Press the Window button in the center of the Screen Capture toolbar.
3 Move the camera cursor to the window you want to capture.
The window will appear as a hatched area.
4 Press once to select the window.
The window will appear on a new page in the current Notebook file.
NOTE: If you accidentally capture a window or screen over existing material on the
current page, you can easily restore the original material. Select the newly captured
image by pressing once on it, activate the Cut command, create a new page and then
select the Paste command. The captured image will appear on the new page and the
previous page will be restored to its original state.
To capture a screen:
1 Go to the screen you want to capture.
2 Press the Screen button in the Screen Capture toolbar.
The entire captured screen will appear on a new page in the current Notebook file.

Capturing Entire Files with Print Capture

Print Capture allows you to print entire multi-page files from other Windows applications to
the end of the current Notebook file. All the pages of the imported file can be immediately
viewed − one printed page per Notebook page.
During Notebook installation, a print driver called the SMART Notebook Print Capture driver
will be installed on your system. This print driver functions like any other printer, except that
its output is captured in SMART Notebook rather than on paper. Therefore, any application
that supports printing can be the file source for this function. You can configure the SMART
Notebook Print Capture driver output properties as you would any other printer.
NOTE: You can only activate Print Capture from the source application. Although this feature
was previously available from within Notebook, it is not available any longer.
To import files via the Notebook Print Capture driver:
1 Activate SMART Notebook and open the Notebook file (.nbk extension) that will
receive the file.
2 Switch to the source application of the file you want to import.
3 Open the file you want to print to the Notebook file.
SMART Board User's Guide
