Danfoss ICAD 600A Installation Manual page 5

Parameter list - Valid from: (i58:11, i59:36) and onwards
The first parameter to be entered shall be: ¡26
Description ICAD
parameter
OD (Opening degree) -
Main Switch ¡01
Mode ¡02
AI signal ¡03
¡04
Speed
In Modulating Mode
Opening/closing speed
In ON/OFF Mode
Opening speed
Automatic calibration ¡05
AO signal ¡06
Failsafe ¡07
Fail safe supply ¡08
DI function ¡09
Password ¡10
Old Alarms ¡11
OD at power cut. ¡12
Inverse operation ¡13
In ON/OFF Mode ¡14
Closing speed
¡15
Manual set point
© Danfoss A/S (RC-MDP/MWA), 2014-10
Min Max Factory Stored Unit
Setting
0 100 %
1 2 1 -

1 2 1 -

1 4 2 -

1 100 50/ 100 -

0 2 0 -
0 2 2 -

1 4 1 -

0 1 0

1 2 1

0 199 0 -
A1 A99 - -
0 100 50

0 1 0

0 100 50/ 100 -

0 100 0
DKRCI.PI.HV0.K2.02 / 520H8962
Pass Comments
word
- ICM/ICMTS valve Opening Degree is displayed during normal operation.
Running display value (see ¡01, ¡05).
No Internal main switch
1: Normal operation
2: Manual operation. Valve Opening Degree will be flashing. With the down
arrow and the up arrow push buttons the OD can be entered manually.
No Operation mode
1: Modulating – ICM positioning according to Analog Input (see ¡03)
2: ON/OFF - operating the ICM valve like an ON/OFF solenoid valve
controlled via Digital Input. See also ¡09.
3: Neutralzone / 3 point control. Increase/Decrease Opening Degree by
Digital Input. See fig. 9
No Type of AI signal from external controller
1: 0-20 mA
2: 4-20 mA
3: 0-10 V
4: 2-10 V
No Speed can be decreased. Max. speed is 100 % - Not active in manual operation (¡01 =
2)
If ¡26= 1 - 3 then factory setting =100
If ¡26= 4 - 9 then factory setting =50
If ICM is opening and (¡04 < = 33) or ICM is closing and (¡14 < = 33)
=> Low is displayed.
If ICM is opening and (33 < If ¡04 < = 66) or ICM is closing and (33 < If ¡14 < = 66)
=> Med is displayed.
If ICM is opening and (¡04 > = 67) or ICM is closing and (¡14 > = 67)
=> High is displayed"
No Not active before ¡26 has been operated.
Always auto reset to 0.
CA will flash in the display during calibration,
if Enter push button has been activated for two seconds
0: No Calibration
1: Normal forced calibration - CA flashing slowly
2: Extended calibration – CA flashing rapidly"
No Type of A0 signal for ICV valve position
0: No signal
1: 0-20 mA
2: 4-20 mA
No Define condition at power cut and fail safe supply is installed.
1: Close valve
2: Open Valve
3: Maintain valve position
4: Go to OD given by ¡12"
Yes Fail safe supply connected and enable of A4 alarm:
0: No
1: Yes
No Define function when DI is ON (short circuited DI terminals) when ¡02 = 2
1: Open ICM valve (DI = OFF = > Close ICM valve)
2: Close ICM valve (DI = OFF = > Open ICM valve)
- Enter number to access password protected parameters: ¡26
Password = 11
No Old alarms will be listed with the latest shown first. Alarm list can be reset by means
of activating down arrow and up arrow at the same time for 2 seconds.
No Only active if ¡07 = 4
If fail safe supply is connected and power cut occurs, the ICM will go to the specified OD.
No When ¡02 = 1
0: Increasing Analog Input signal => Increasing ICM Opening Degree
1: Increasing Analog Input signal => Decreasing ICM Opening Degree
When ¡02 = 3
0: DI1 = ON, DI2 = OFF => Increasing ICM Opening Degree.
DI1 = OFF, DI2 = ON => Decreasing ICM Opening Degree
DI1 = DI2 = OFF => ICAD/ICM maintain current position
DI1 = DI2 = ON => ICAD/ICM maintain current position
1: DI1 = ON, DI2 = OFF => Decreasing ICM Opening Degree
DI1 = OFF, DI2 = ON => Increasing ICM Opening Degree
DI1 = DI2 = OFF => ICAD/ICM maintain current position
DI1 = DI2 = ON => ICAD/ICM maintain current position
See ¡04.
No
If ¡26= 1 - 3 then factory settin qg = 100
If ¡26= 4 - 9 then factory setting = 50
When ¡01= 2, ¡15 determine the start up value.
No
to be continued....
