A7861C
11/17
Copyright 2017, Sargent Manufacturing Company, an ASSA ABLOY Group company.
All rights reserved. Reproduction in whole or in part without the express written
permission of Sargent Manufacturing Company is prohibited.
v.G1.5
Profile Series
Dorm Lock
Installation Instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Profile Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sargent Profile Series

Summary of Contents for Sargent Profile Series

  • Page 1 Profile Series Dorm Lock Installation Instructions A7861C 11/17 Copyright 2017, Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Sargent Manufacturing Company is prohibited.

  • Page 2: Table Of Contents

    To comply with “Fire Listed” doors, the batteries must be replaced with alkaline batteries only. Do not install batteries if controller is powered by external power supply. Warning SARGENT Mfg. Co. locksets utilizing a door position switch (DPS) are not rated for, or intended for use in life safety applications.

  • Page 3: General Description

    Profile Series v.G1.5 Mortise Dorm Lock General Description The SARGENT Profile Series v.G1.5 Mortise Dorm Lock is designed to prevent residents from being locked out of their rooms. The resident presents a proximity card and/or pin code, which works as a toggle to unlock (overriding the deadbolt if thrown) or relock the outside lever.

  • Page 4: Parts Breakdown

    Pro le Series v.G1.5 Profile Series v.G1.5 Mortise Dorm Lock Parts Breakdown 18/19 18 19 17 20 27/28 800-810-WIRE (9473) • www.sargentlock.com • A7855B 1-800-810-WIRE • www.sargentlock.com • A7861C...
  • Page 5 Lever Handle Screw, B, J, L, P & W Lever 82-4188 Inside Escutcheon with Thumb Turn & Keypad/Prox or Prox Only Reference Profile Series catalog for available lever handles Controller (G1-TA, G1-TP) Reference Profile Series catalog for available lever handles 82-4189 Inside Escutcheon without Thumb Turn &...

  • Page 6: Installation Instructions

    Profile Series v.G1.5 Mortise Dorm Lock Installation Instructions Step #1 – Verify Hand and Bevel of Door A. Verify Hand and Bevel of Door Stand on outside/locked side of door when determining the door hand LHRB RHRB Left Hand Left Hand...
  • Page 7 Profile Series v.G1.5 Mortise Dorm Lock Step #2 – How to Change Hand of Lockbody A. Reverse Lock Hand Red surface of locking piece must face the outside/locked side of door. To rotate locking piece (Fig. 2A): 1. Position lock body with red surface of locking piece visible.
  • Page 8 Profile Series v.G1.5 Mortise Dorm Lock Step #3 – Install Lock Body 1. Insert lock body into mortised cutout by first feed- ing harness (6)-pin connector through cylinder hole on non-cylinder side followed by the two (2)-pin connectors (Fig. 3).
  • Page 9 Profile Series v.G1.5 Mortise Dorm Lock Step #5 – Install Weatherseal Gasket (Exterior Doors) 1. Carefully remove the backing from the gasket. 2. Apply gasket to escutcheon: • Starting in one place, press the adhesive side of the gasket firmly against the escutcheon.
  • Page 10 Profile Series v.G1.5 Mortise Dorm Lock Step #7 – Inside Escutcheon Wire Connections Images are shown without gasket. If gasket is necessary, refer to Step #5. Before the controller is attached to the door: Reader Ribbon 1. Attach the reader assembly...
  • Page 11 Profile Series v.G1.5 Mortise Dorm Lock Step #7 – Inside Escutcheon Wire Connections (Continued) Installation of Motor Harness and Inside Lever Monitor Switch LH/LHR Lock Configuration RH/RHR Lock Configuration - For LH/LHR lock: Connect lock's two-pin - For RH/RHR lock: Connect lock's two-pin connector with blue &...
  • Page 12 Profile Series v.G1.5 Mortise Dorm Lock Step #8 – Inside Lever Installation Inside of Door 1. Slide lever handle onto spindle until fully seated (Fig. 8). 2. Insert #8-32 x 1-1/4" screws through inside escutcheon and thread into outside escutcheon.

  • Page 13: Battery Cover

    Profile Series v.G1.5 Mortise Dorm Lock Outside of Door Step #10 – Attach Front Plate Attach front plate with (2) flat head screws. Front Plate (2) Flat Head Screws Fig. 10 Lock Body Screws Step #11 – Attach Battery Keeper and Cover 1.
  • Page 14 Profile Series v.G1.5 Mortise Dorm Lock Step #12 – Install and Remove Batteries* A. Install Batteries and Keeper 1. Place (6) “AA” batteries into the compartment, being careful to properly align polarity (Fig. 12A). 2. To install battery keeper, insert the tabs on the bottom of the keeper into the battery compartment slots and press the keeper tightly against batteries and inserting tabs into bottom slots.

  • Page 15: Rf Technology Lock

    Profile Series v.G1.5 Mortise Dorm Lock RF Technology Lock Installation for the RF Technology Lock for G1-TU, G1-TA, G1-TP is, for the most part, installed as described in Section 6. In addition: The antenna board must be carefully moved to access the upper through-bolt screw.

  • Page 16: Hardwire Wiring Options

    Profile Series v.G1.5 Mortise Dorm Lock Hardwiring Options Hardwiring options include one or a combination of Forced/Propped Door, Hard Power and/or Remote Unlock (REX). Refer to the examples on the following pages: 1. Forced/Propped Door Option (DM-). 2. Hard Power and Remote Unlock (91-).

  • Page 17: Battery Keeper

    Profile Series v.G1.5 Mortise Dorm Lock ElectroLynx Lock Wire Connections Door Position Switch (DPS) Install the SARGENT 3287 Door Status Switch according to instructions included in the kit. Wire the 3287 Door Status Switch to the ElectroLynx frame har- ness and to the door status wires: 1.

  • Page 18: Wire • Www.sargentlock.com • A7861C

    Profile Series v.G1.5 Mortise Dorm Lock Option #1 – Forced / Propped Door (DM-) Installation 1. ElectroLynx System Wiring Instructions (Fig. 1 and Fig. 2): ® a. Look for the mating part on ASSA ABLOY doors and frames. b. Plug in all connectors during product installation (Fig. 2).
  • Page 19 Profile Series v.G1.5 Mortise Dorm Lock Option #2 – Remote Power and Remote Unlock (91-) Installation 1. ElectroLynx System Wiring Instructions (Fig. 1 and Fig. 2): ® a. Look for the mating part on ASSA ABLOY doors and frames. b. Plug in all connectors during product installation (Fig. 2).
  • Page 20 Profile Series v.G1.5 Mortise Dorm Lock Option #3 – Hard Power/Remote Unlock (91-) Combined With Forced/Propped Door (DM-) Installation 1. ElectroLynx System Wiring Instructions (Fig. 1 and Fig. 2): ® a. Look for the mating part on ASSA ABLOY doors and frames.

  • Page 21: Operational Check

    Profile Series v.G1.5 Mortise Dorm Lock Operational Check For devices with cylinders, insert key into cylinder and rotate. Check to see if: 1. The key retracts the latch. Key should rotate freely. Key should extend and retract the deadbolt (if applicable).
  • Page 22 Copyright © 2017, Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Sargent Manufacturing Company is prohibited. ASSA ABLOY is the global leader in door opening solutions, dedicated to A7861C-11/17 satisfying end-user needs for security, safety and convenience.
