- Page 1 PASSPORT 1000 Cylindrical Lock Installation Instructions A8013H 04/16 Copyright 2015, Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Sargent Manufacturing Company is prohibited.
-
Page 3: Table Of Contents
(p.i.r.e.) ne dépasse pas l’intensité nécessaire à l’établissement d’une communication satisfaisante. Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and SARGENT Manufac- turing makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings. -
Page 4: General Description
Passport 1000 P2 WiFi Cylindrical Lock General Description An ANSI/BHMA Grade 1 lock using WiFi technology, the Passport 1000 P2 cylindrical lock provides a cost-effective, future-proof solution for campuses. Featuring multiCLASS SE Technology from HID Global , it provides simultaneous support for multiple ®... -
Page 5: Parts Breakdown
Passport 1000 P2 WiFi Cylindrical Lock Parts Breakdown P2 WiFi Lock with Magnetic Card Swipe With or Without Keypad ITEM No. PART No. DESCRIPTION 52-3583-[finish] Outside Escutcheon Assemby, mag stripe 52-3582-[finish] Outside Escutcheon Assemby, mag stripe and Keypad (shown) 52-4244-[finish]... - Page 6 Passport 1000 P2 WiFi Cylindrical Lock Parts Breakdown (Continued) 10 Line Series Cylindrical Lock *Adapter Plate/Spacer (10-0847) only shipped with orders that specify 1-3/8” doors. ITEM PART No. DESCRIPTION REQ’D Outside Lever (Reference Catalog for Available Styles) 10-0043 Lever Retainer Key (In Screw Pack 10-2052)
-
Page 7: Installation Instructions
Passport 1000 P2 WiFi Cylindrical Lock Installation Instructions Door Preparation A. Verify Hand and Bevel of Door Stand on outside of locked door when determining door hand. Left Hand (LH) Left Hand Right Hand (RH) Right Hand Hinges Left. Reverse Bevel Hinges Right. - Page 8 Passport 1000 P2 WiFi Cylindrical Lock 2 Install Strike Centerline of Latch Install strike in the door frame (Fig.2). Front and Strike (2) #8-32 x 3/4” Screws Fig. 2 3 Install Latchbolt 1. Install latch with beveled bolt facing strike.
- Page 9 Passport 1000 P2 WiFi Cylindrical Lock 4 Install Door Position Switch (DPS) 1. Insert connector end of DPS harness through raceway on latch edge of door. Note: Use collar in METAL door only. 2. Push DPS firmly into place by hand.
- Page 10 Passport 1000 P2 WiFi Cylindrical Lock 5 Lock Presets and Adjustments (If Required) A. Lock Preset ▪ Lock body holes – 12 and 6 o’clock (Fig. 5A). ▪ Door thickness – 1-3/4” thick. Refer to Spacer Bushing adjustments below for other door conditions (Fig.
- Page 11 Passport 1000 P2 WiFi Cylindrical Lock 6 Install Lock IMPORTANT: If lock is being installed as a retrofit; (replacing an existing P2 product), remove the DPS wires and connector (Fig. 6A) by simply severing the wires as indicated (see arrow).
- Page 12 Passport 1000 P2 WiFi Cylindrical Lock 8 Assemble Inside Trim 1. Verify spacer bushing is inserted horizontally and aligned with lever (Fig. 8). 2. Place rose (scalp) over shaft of lock body against DPS (Door Position Switch) surface of door; hand-tighten, turning clockwise.
- Page 13 Passport 1000 P2 WiFi Cylindrical Lock 10 Install Outside Escutcheon with (Optional) Gasket Note: Gasket optional, for non-fire rated doors only. For non-fire rated door applications, an optional gasket Outside of Door (Part number 52-0782) may be used as a weather seal between the escutcheon and the outside door surface.
- Page 14 Passport 1000 P2 WiFi Cylindrical Lock Installation of Connectors CAUTION - Do not touch or allow debris to enter connector contacts. Secure the following connectors to their respective terminals (Fig. 12): A. Secure the 4-pin DPS connector. B. Secure the 10-pin lock body assembly connector.
- Page 15 Passport 1000 P2 WiFi Cylindrical Lock 13 Install Inside Module Component Assembly 1. Insert top tabs of controller into slots on mounting plate (Fig. 13). 2. Ensure proper alignment of board-to-board connectors while pivoting bottom of controller toward door until tab on bottom snaps securely into place on mounting plate.
- Page 16 Passport 1000 P2 WiFi Cylindrical Lock 14 Battery Installation 1. Place (6) “AA” batteries into the compartment being careful to align polarity (- & +) properly. 2. After batteries are properly installed, there is a slight delay followed by a amber LED flash; the lock motor Inside of Door will cycle.
-
Page 17: Operational Check
Passport 1000 P2 WiFi Cylindrical Lock Operational Check IMPORTANT: Be sure to test functions prior to closing door. In all cases, perform the following checks: 1. Ensure that inside lever retracts latch. • For units with cylinders, the following checks apply: Insert key into cylinder and rotate: a. - Page 18 NOTES...
- Page 20 New Haven, CT 06511 USA 800-810-WIRE (9473) • www.sargentlock.com Founded in the early 1800s, SARGENT® is a market leader in locksets, cylinders, door closers, exit devices, electro-mechanical products and access control systems for new construction, renovation, and replacement applications. The company’s customer base includes commercial construction, institutional, and industrial markets.
