Page 1: Installation Instructions
PASSPORT 1000 Cylindrical Lock Installation Instructions A8033G 04/16 Copyright 2016, Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Sargent Manufacturing Company is prohibited. -
Page 2: Table Of Contents
(p.i.r.e.) ne dépasse pas l’intensité nécessaire à l’établissement d’une communication satisfaisante. Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and SARGENT Manufac- turing makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an existing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings. -
Page 3: General Description
Passport 1000 P1 PoE Cylindrical Lock General Description An ANSI/BHMA Grade 1 lock utilizing Power over Ethernet (PoE) technology, the Passport 1000 P1 provides a cost-effective, future-proof solution for campuses. Featuring multiCLASS SE Technology ® from HID Global , it provides simultaneous support for multiple credentials and offers an easy migration ®... -
Page 4: Installation Wiring
Passport 1000 P1 PoE Cylindrical Lock Installation Wiring Overview SARGENT Passport Series PoE P1 Typical Application Network Cable Surface Mount RJ45 Network Switch (802.3af) LMT: Lock Management Tool A. PoE frame harness assembly B. PoE data hinge from McKinney C. PoE door harness* from McKinney D. - Page 5 Passport 1000 P1 PoE Cylindrical Lock Installation Wiring (Continued) Supplied by CI Certified Integrator (CI) supplies and terminates Supplied by End User the B-Splice connector and the PoE Switch male RJ45 connector from harness to end user provided facility cable B-Splice Patch Cable Crimp Connector...
- Page 6 Passport 1000 P1 PoE Cylindrical Lock Installation Wiring (Continued) Frame Harness Installation Components and wire harness supplied by McKinney. Suggested installation: Supplied by CI Cut end / ceiling-side PoE harness: B-Splice Crimp Connector TIA/EIA 568-B Standard Wiring Wire Pair Number White/Orange Orange RJ45-M...
- Page 7 Passport 1000 P1 PoE Cylindrical Lock Hinge Installation Order of installation may vary. Refer to appropriate sections for instructions. Hinge-side harness connectors: • 4-pin male Molex connector • 6-pin male Molex connector with ground wire Lock-side harness connectors: • Ring terminal •...
- Page 8 Passport 1000 P1 PoE Cylindrical Lock DPS (Door Position Switch) Installation 1. Prep door according to proper template (Fig. D1). 2. Insert connector end of DPS through the raceway on the latch edge of the door (Fig. D2). Note: Only use collar when installing in a metal door. 3.
-
Page 9: Parts Breakdown
Passport 1000 P1 PoE Cylindrical Lock Parts Breakdown P1 PoE Lock with Magnetic Card Swipe With or Without Keypad ITEM No. PART No. DESCRIPTION 52-3583-[finish] Outside Escutcheon Assemby, mag stripe 52-3582-[finish] Outside Escutcheon Assemby, mag stripe and Keypad (shown) 52-4244-[finish] Outside Escutcheon Assemby, Mag Swipe, Keypad, and HID 125 kHz Prox 52-4759-[finish] Outside Escutcheon Assemby, iCLASS, keypad, mag stripe, Prox, smart card (MIFARE, DESFIRE) - Page 10 Passport 1000 P1 PoE Cylindrical Lock Parts Breakdown (Continued) 10 Line Series Cylindrical Lock *Adapter Plate/Spacer (10-0847) is only shipped with orders that specify 1-3/8” doors. ITEM PART No. DESCRIPTION REQ’D Outside Lever (Reference Catalog for Available Styles) 10-0043 Lever Retainer Key (In Screw Pack 10-2052) Cylinder Assembly (Reference Catalog for Available Cylinders) Rose (Reference Catalog for Avalable Styles) 10-0792...
-
Page 11: Installation Instructions
Passport 1000 P1 PoE Cylindrical Lock Installation Instructions Door Preparation A. Verify Hand and Bevel of Door Left Hand Left Hand Right Hand Right Hand Hinges Left. Reverse Bevel Hinges Right. Reverse Bevel Open Inward. Hinges Left. Open Inward. Hinges Right. “LH”... - Page 12 Passport 1000 P1 PoE Cylindrical Lock 2 Install Strike Install strike in the door frame (Fig.2). Fig. 2 3 Install Latch Bolt 1. Install latch with beveled bolt facing strike. 2. Attach with two screws. Harness (Cat 5e) DO NOT tighten completely at this time. Outside of Door IMPORTANT: Latch bevel must match door bevel and deadlocking latch must stop on strike when door is closed.
- Page 13 Passport 1000 P1 PoE Cylindrical Lock 4 Lock Presets and Adjustments A. Lock Preset • Lockbody holes – 12 and 6 o’clock (Fig. 5A). • Door thickness – 1-3/4” thick. Refer to adjustments be- low for other door conditions (Fig. 4B). B.
- Page 14 Passport 1000 P1 PoE Cylindrical Lock 5 Install Lock Body IMPORTANT: If lock is being installed as a retrofit; (replacing an existing P1 product), remove the DPS wires and connector (Fig. 5A) by simply severing the wires as indicated* (see arrow). Harness (Cat 5e) If this is a new lock being installed for the first...
- Page 15 Passport 1000 P1 PoE Cylindrical Lock 7 Assemble Inside Trim 1. Verify spacer bushing is inserted horizontally and aligned with lever (Fig. 7). 2. Place rose (scalp) over shaft of lock body against DPS (Door Position Switch) surface of door; hand-tighten, turning clockwise. PoE Harness from Hinge 3.
- Page 16 Passport 1000 P1 PoE Cylindrical Lock 9 Install Gasket (Optional) and Install Outside Escutcheon Note: Gasket optional, for non-fire rated doors only. Outside of Door For non-fire rated door applications, an optional gasket (Part number 52-0782) may be used as a weather seal between the escutcheon and the outside door surface.
- Page 17 Passport 1000 P1 PoE Cylindrical Lock Installation of Connectors CAUTION - Do not touch or allow debris to enter connector contacts. Secure the following connectors to their respective terminals (Fig. 11A): A. Secure the 4-pin DPS connector. B. Secure the 10-pin lock body assembly connector. IMPORTANT: Do not run wires through bottom hole in plate (Fig.
- Page 18 Passport 1000 P1 PoE Cylindrical Lock 12 Installation of Inside Module Component Assembly 1. Insert top tabs of controller into slots on mounting plate (Fig. 12A). 2. Ensure proper alignment of board-to-board connectors while pivoting bottom of controller toward door until tab on bottom snaps securely into place on mounting plate.
-
Page 19: Operational Check
Passport 1000 P1 PoE Cylindrical Lock 13 Installation of Inside Escutcheon 1. Position inside escutcheon (Fig. 13). 2. Insert screws, top and bottom, and tighten securely. DO NOT OVERTIGHTEN. Note: All wires should be placed inside to avoid pinching. 3. Straighten escutcheon and tighten securely. (2) #8-32 x 1/2”... - Page 20 Copyright © 2016, Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Sargent Manufacturing Company is prohibited. ASSA ABLOY is the global leader in door opening solutions, dedicated to satisfying end-user needs for security, safety and convenience.
