P2
PASSPORT 1000
Exit Device

Installation Instructions

Advertisement

Table of Contents
loading

Related Manuals for Sargent P2 PASSPORT 1000

Summary of Contents for Sargent P2 PASSPORT 1000

  • Page 1: Installation Instructions

    PASSPORT 1000 Exit Device Installation Instructions A8012F 03/14 Copyright © 2014, Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Sargent Manufacturing Company is prohibited.

  • Page 2: Table Of Contents

    à l’établissement d’une communication satisfaisante. Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and SARGENT Manufacturing makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an exist- ing fire rated opening, or specifying and installing a new fire-rated opening, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings.

  • Page 3: General Description

    NFC mobile access. Designed specifically for the campus market, the SARGENT Passport 1000 P2 WiFi exit device provides customized access control with magnetic swipe and optional contactless reader and/or keypad, as well as detailed audit capabilities.

  • Page 4: Parts Breakdown

    Passport 1000 P2 WiFi Exit Device Parts Breakdown P2 WiFi Lock with Magnetic Card Swipe With or Without Keypad ITEM No. PART No. DESCRIPTION 52-3583-[finish] Outside Escutcheon Assemby, mag stripe 52-3582-[finish] Outside Escutcheon Assemby, mag stripe and Keypad (shown) 52-4244-[finish] Outside Escutcheon Assembly, mag stripe, keypad and HID 125kHz Prox 52-4759-[finish] Outside Escutcheon Assemby, iCLASS, keypad, mag stripe, Prox, smart card (MIFARE, DESFIRE) 52-4777-[finish] Outside Escutcheon Assemby, iCLASS, mag stripe, Prox, smart card (MIFARE, DESFIRE) 52-4787-[finish] Outside Escutcheon Assemby, FeliCa, keypad, mag stripe, Prox...
  • Page 5 Passport 1000 P2 WiFi Exit Device Parts Breakdown (continued) Items Supplied with Exit Device 8877 and 8977 Series Exit Device Contents 8878 and 8978 Series Exit Device Contents • Outside escutcheon with magnetic swipe standard • Outside escutcheon with magnetic swipe standard with optional proximity reader and/or keypad with optional proximity reader and/or keypad •...
  • Page 6 Passport 1000 P2 WiFi Exit Device Parts Breakdown (continued) 8977/8978 x RT x Lever Design Passport 1000 Mortise Exit Device ITEM PART No. DESCRIPTION REQ’D Cylinder Assembly (Reference Catalog for Available Cylinders) Lever (Reference Catalog for Available Styles) 97-4107 Exit Trim (ET) With Cylinder 97-4108 Exit Trim (ET) Without Cylinder 52-4845...

  • Page 7: Rim Type 8877/8878 Exit Device Installation

    Passport 1000 P2 WiFi Exit Device Installation Instructions for 8877/8878 Rim Exit 1 Door Preparation Inside A. Verify Hand and Bevel of Door • Check hand of door. The exit device is non-handed and Left Hand Right Hand the trim is field reversible. Reverse Reverse •...
  • Page 8 Passport 1000 P2 WiFi Exit Device 2 Install Door Position Switch (DPS) Wood doors have 3/8” raceway to controller cutout and metal doors have 3/4” raceway to the controller cutout. Refer to template A7951. 1. Insert connector end of DPS through the raceway on the latch edge of the door (Fig.
  • Page 9 2. Secure the cylinder by through-bolting the cylinder through the exit chassis using (2) #12-24 x 1-7/8” connecting screws (see Fig. 5A). 3. Verify that the key retracts latchbolt. Position cylinder so that the SARGENT logo is right-side up. Correct Incorrect Fig. 5B Fig. 5A...
  • Page 10 Passport 1000 P2 WiFi Exit Device 6 Secure Exit Chassis To comply with UL certifications and for security: Fasten exit chassis to door using (4) #10 wood screws (for wood door) or (4) #10-24 machine screws (for metal door). Inside of Door (4) #10 Wood Screws or #10-24 Machine Screws (2) #12-24 x 1-7/8”...
  • Page 11 Passport 1000 P2 WiFi Exit Device 8 Install Chassis Cover Secure chassis cover to chassis using (4) #8-32 x 5/16” oval head machine screws (Fig. 8). Fig. 8 9 Install Wire Cover (Wood Doors Only) 1. Position the wire cover plate above the chassis cover and covering the wire channel.
  • Page 12 Passport 1000 P2 WiFi Exit Device 10 Install Outside Escutcheon (with Optional Gasket) Note: Gasket optional, for non-fire rated doors only. For non-fire rated door applications, an optional gasket (Part number 52-0782) may be used as a weather seal between the escutcheon and the outside door surface. Peel off adhesive backing and attach to (outside) escutcheon.
  • Page 13 Passport 1000 P2 WiFi Exit Device Installation of Connectors CAUTION - Do not touch or allow debris to enter connector contacts. Secure the following connectors to their respective terminals (Fig. 11A, B ): 9-24VDC Reader Power* A. Secure the 10-pin lock body assembly connector. (24-pin) *NOTE: Optional 2-pin external 12-24VDC power connector.
  • Page 14 Passport 1000 P2 WiFi Exit Device 12 Installing the Controller 1. Insert bottom tab of controller into slot on mounting plate (Fig. 12A, B). 2. Looking down from top of controller, ensure proper alignment of board-to-board connectors (Fig. 13B) while pivoting controller toward door until two tabs on top snap securely into place on mounting plate. CAUTION: To avoid possible damage to board-to-board connectors, care should be taken when securing controller to mounting plate.
  • Page 15 Passport 1000 P2 WiFi Exit Device 13 Install Battery Pack Before installing batteries for the first time: Remove pull tab from its position beneath the coin cell by pulling on tab in direction of arrows printed on tab (Fig. 13). a.
  • Page 16 Passport 1000 P2 WiFi Exit Device 16 Installation of Rail Assembly 1. Retrieve harness from end of rail. Note: Length of harness requires caution when handling to avoid damage. Harness should not be stretched or overextended. 2. Attach harness to female connector on chassis. 3.

  • Page 17: Mortise Type 8977/8978 Exit Device Installation

    Passport 1000 P2 WiFi Exit Device Installation Instructions for Mortise Type 8977/8978 Exit Device 1 Door Preparation Inside A. Verify Hand and Bevel of Door • Check hand of door. This exit device is handed and is not reversible. Left Hand Right Hand •...
  • Page 18 Passport 1000 P2 WiFi Exit Device 2 Install Door Position Switch (DPS) Wood doors have 3/8” raceway to controller cutout and metal doors have 3/4” raceway to the controller cutout. Inside of Door Refer to template A7951. 1. Insert connector end of DPS through the raceway on the latch edge of the door (Fig.6A).
  • Page 19 Passport 1000 P2 WiFi Exit Device 4 Mount Exit Device Chassis 1. Position exit chassis carefully, verifying the chassis lift lever engages the mortise lock (Fig. 4B). DO NOT PINCH THE WIRE HARNESS. 2. Secure the exit chassis by through bolting to the ET trim with (2) 1/4 -20 x 2-3/8” flat head machine screws.
  • Page 20 Outside of Door Cylinder should rest flush on ET Case. Note: SARGENT logo must be horizontal and on the top of the cylinder (Fig. 6B). 2. Secure the cylinder by tightening cylinder clamp screw located above the guardbolt.
  • Page 21 Passport 1000 P2 WiFi Exit Device 8 Install Wire Cover (Wood Doors Only) 1. Position the wire cover plate above the chassis cover and covering the wire channel. Mark hole positions. Note: Make sure stamped side of plate is against door. Inside of Door 2.
  • Page 22 Passport 1000 P2 WiFi Exit Device 10 Install Outside Escutcheon and Mounting Plate Assembly 1. Insert the mounting posts through holes as shown. Mounting Plate 2. On the inside of the door, position the mounting plate over the indicated holes (Fig. 10A). 3.
  • Page 23 Passport 1000 P2 WiFi Exit Device 11 Installing the Controller 1. Insert bottom tab of controller into slot on mounting plate (Fig. 11A, B). 2. Looking down from top of controller, ensure proper alignment of board-to-board connectors (Fig. 11B) while pivoting controller toward door until two tabs on top snap securely into place on mounting plate. CAUTION: To avoid possible damage to board-to-board connectors, care should be taken when securing controller to mounting plate.
  • Page 24 Passport 1000 P2 WiFi Exit Device 12 Install Battery Pack Before installing batteries for the first time: Remove pull tab from its position beneath the coin cell by pulling Inside of Door on tab in direction of arrows printed on tab (Fig. 12). a.

  • Page 25: Operational Check

    Passport 1000 P2 WiFi Exit Device 14 Installation of Rail Assembly 1. Retrieve harness from end of rail. Note: Harness has limited travel and can be damaged. 2. Attach harness to female connector on chassis. 3. Install rail and screws per exit device instructions. Note: This view shows rim exit device version.
  • Page 26 New Haven, CT 06511 USA 1-800-810-WIRE (9473) • www.sargentlock.com Founded in the early 1800s, SARGENT® is a market leader in locksets, cylinders, door closers, exit devices, electro-mechanical products and access control systems for new construction, renovation, and replacement applications. The company’s customer base includes commercial construction, institutional, and industrial markets.
