A7809B
10/12
Copyright © 2012, Sargent Manufacturing Company, an ASSA ABLOY Group company.
All rights reserved. Reproduction in whole or in part without the express written
permission of Sargent Manufacturing Company is prohibited.
PG
PASSPORT 1000
Exit Device
Installation Instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Passport 1000 PG and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Sargent Passport 1000 PG

  • Page 1 PASSPORT 1000 Exit Device Installation Instructions A7809B 10/12 Copyright © 2012, Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Sargent Manufacturing Company is prohibited.
  • Page 2: Table Of Contents

    Observe precautions for handling electrostatic sensitive devices. SARGENT Mfg. Co. Passport 1000 locksets utilizing a door position switch (DPS) are not rated for, or intended for use in life safety applications.
  • Page 3: General Description

    Passport 1000 PG Exit Device General Description Designed specifically for the campus market, the SARGENT Passport 1000 PG Rim/Mortise Exit Device (powered by PERSONA) provides offline card/PIN access control, as well as detailed audit capabilities. The PG stand alone unit is available with both keypad and magstripe card technology, or •...
  • Page 4: Part Breakdown

    Passport 1000 PG Exit Device PG Standalone With Card Insert and/or Keypad ITEM PART No. DESCRIPTION 52-0757 Lens (Cliplite) 52-0736 Outside Passport Escutcheon (With Keypad) 52-0737 Outside Passport Escutcheon (Without Keypad) 52-3593 Slim Style Keypad Assembly (KP-PG Only) 52-0760 Light Pipe (Cliplite)
  • Page 5 Passport 1000 PG Exit Device Parts Breakdown (Continued) 8877/8878 x ET x Lever Design Passport 1000 Rim Exit Device ITEM PART No. DESCRIPTION REQ’D – Cylinder Assembly (Reference Catalog for Available Cylinders) – Lever (Reference Catalog for Available Styles) 97-3562...
  • Page 6 Passport 1000 PG Exit Device Parts Breakdown (Continued) 8977/8978 x ET x Lever Design Passport 1000 Mortise Exit Device ITEM PART No. DESCRIPTION REQ’D – Cylinder Assembly (Reference Catalog for Available Cylinders) – Lever (Reference Catalog for Available Styles) 97-3558...
  • Page 7 Passport 1000 PG Exit Device Installation Instructions for 8977/8978 Rim Exit IMPORTANT: BEFORE STARTING • This device is non-handed. • Door should be fitted and hung. • Verify box label for size of exit device, function and hand. 1 – Exit Hardware & Door Preparation If using a mullion, install in frame.
  • Page 8: Rim Type 8877/8878 Exit Device Installation

    Passport 1000 PG Exit Device Rim Installation Instructions (Continued) 2 – Installation of Exit Trim (ET), Exit Chassis and Cylinder A. Outside Trim Outside of door 1. For exterior applications, “ET” gasket (52-0263) should be used to seal between “ET” escutcheon and outside door surface.
  • Page 9 Passport 1000 PG Exit Device Rim Installation Instructions (Continued) Outside of door 2 – Installation of Exit Trim (ET), Exit Chassis and Cylinder (continued) C. Cylinder Installation Note: For devices without cylinder, go to Step 2D. 1. Insert cylinder into “ET” control.
  • Page 10 Passport 1000 PG Exit Device Rim Installation Instructions (Continued) Inside of door 3 - Chassis Cover Instructions Secure chassis cover to chassis using (4) #8-32 x 5/16” oval head machine screws. Chassis Cover (4) #8-32 x 5/8” oval head machine screws Fig.
  • Page 11 Passport 1000 PG Exit Device Rim Installation Instructions (Continued) 5B – Installation of Outside Escutcheon & Mounting Plate Assembly 1. Insert the mounting posts through holes as shown (Fig. 5B1). 2. On the inside of the door, position the mounting plate over the indicated holes.
  • Page 12 Passport 1000 PG Exit Device Rim Installation Instructions (Continued) Modular component 6A – Installation of Inside Component Assembly 1. Insert bottom of component assembly first (Fig. 6A). 2. Clip top of component assembly to mounting plate verifying both tabs attached securely.
  • Page 13 Passport 1000 PG Exit Device Rim Installation Instructions (Continued) 7 - Battery/Battery Pack Installation Battery pack 1. Place (6) “AA” batteries into the compartment being careful to align polarity (- & +) according to case markings. PERSONA PG controller DIP 2.
  • Page 14: Mortise Type 8977/8978 Exit Device Installation

    Passport 1000 PG Exit Device Installation Instructions for Mortise Type Exit Device 8977/8978 Inside IMPORTANT BEFORE STARTING: • This device is non-handed. • Door should be fitted and hung. • Verify box label for size of exit device, function and hand.
  • Page 15 Passport 1000 PG Exit Device Mortise Installation Instructions (Continued) 2 – Installation of Outside Exit Trim (ET), Exit Chassis and Cylinder Outside of A. Outside Trim door 1. Slide mortise lock into door and securely fasten with (2) flat head screws.
  • Page 16 Passport 1000 PG Exit Device Mortise Installation Instructions (Continued) 2 – Installation of Outside Trim, Exit Chassis and Cylinder (Continued) B. Exit Chassis (Continued): Fasten exit chassis to door using (4) #10 wood screws or #10-24 machine screws (Fig. 2B3).
  • Page 17 Passport 1000 PG Exit Device Mortise Installation Instructions (Continued) 3 – Chassis Cover Instructions Inside of door Secure chassis cover to chassis using (4) #8 - 32 x 5/16” oval head machine screws. Chassis cover (4) #8 - 32 x 5/16”...
  • Page 18 Passport 1000 PG Exit Device Mortise Installation Instructions (Continued) Outside of door 5A – Installation of Outside Escutcheon with Weatherseal Passport gasket Gasket (optional) Outside Note: For non-fire rated door applications, an optional gasket may be used Passport as a weatherseal between the escutcheon and the outside door surface.
  • Page 19 Passport 1000 PG Exit Device Mortise Installation Instructions (Continued) Modular component 6A – Installation of Inside Component Assembly 1. Insert bottom of component assembly first (Fig. 6A). 2. Clip top of component assembly to mounting plate verifying both tabs attached securely.
  • Page 20: Setting Up The Persona Locklink™ & Contact Card

    Passport 1000 PG Exit Device Mortise Installation Instructions (Continued) 7 - Battery/Battery Pack Installation and DIP Switch Verification 1. Place (6) “AA” batteries into the compartment, being careful to properly align polarity (- & +) . 2. Insert battery pack and click into place making sure polarity terminals on the battery pack are oriented upward as in Fig.
  • Page 21 Passport 1000 PG Exit Device Setting up the Locklink™ and Contact Card for First Use* *NOTE: The following steps in this section are only performed one time. Once Bluetooth pairing is complete, these steps do not need to be repeated to program locks (Section 8 ”Lockset Programming”).
  • Page 22 Passport 1000 PG Exit Device 4. The Pocket PC will enable Bluetooth and begin discovery. If you receive a warning, "No Devices Found," then check again to see the blue light flashing on the contact card and tap ‘Retry’ .
  • Page 23: Lockset Programming

    Passport 1000 PG Exit Device Lockset Programming 1. Tap then tap to launch the LockLink program. Choose Menu and then ‘Setup’. 2. Pick the COM port noted in Step 6. Check the box ‘Use Bluetooth’ and click ‘Apply’. Start the PERSONA LockLink™ software: 1.
  • Page 24 Passport 1000 PG Exit Device Lockset Programming Instructions (Continued) Upload Full Program After locks are installed, they must have program files copied into them before they can receive and interpret data. In many ways, the program files act as the locks’ operating system by interpreting the lock data to control each lock’s behavior.
  • Page 25 Passport 1000 PG Exit Device Lockset Programming Instructions (Continued) 6. Reinsert Contact Card a second time to initialize the program. Note: You should hear the motor run briefly. 7. Program initializes and directs you to remove the Contact Card. 8. Follow the on-screen directions and reinsert the Contact Card a third time.
  • Page 26 Passport 1000 PG Exit Device Lockset Programming Instructions (Continued) 9. Remove the Contact Card. 10. To exit and return to the program screen, tap the button. 11. After programming the new lockset, verify operation by performing the Operational Check (refer to Section 9).
  • Page 27: Operational Check

    Passport 1000 PG Exit Device Operational Check IMPORTANT: Be sure to test functions prior to closing door. In all cases, perform the following checks: 1. Ensure that inside lever retracts latch (and deadbolt for deadbolt functions). • For devices with cylinders, the following checks apply: Insert key into cylinder and rotate: a.
  • Page 28 New Haven, CT 06511 USA PERSONA Technical Support: 800-481-8464 • www.personacampus.com Founded in the early 1800s, SARGENT® is a market leader in locksets, cylinders, door closers, exit devices, electro-mechanical products and access control systems for new construction, renovation, and replacement applications.
