BIO RAD Experion DNA 12K analysis kits Quick Manual

Storage Conditions
Product Storage
DNA 12K chips Room temperature
DNA 12K reagents 4 o C (protected from light)
Essential Practices
Always wear gloves when handling reagents and chips
n
Handle chips by the edges; do not touch the glass
n
Remove chip from packaging only immediately before use
n
Avoid sources of dust and contaminants when preparing
n
samples and loading the chip. Foreign particles in reagents,
samples, and the wells of the chip can interfere with results
Deep-clean the electrodes if contamination is suspected or
n
if a chip was left in the instrument overnight
Use of colored or coated (for example, siliconized
n
polypropylene) tubes when preparing kit reagents or samples
is not recommended; such tubes may cause artifacts during
the separation
Refer to the instruction manual (Bulletin 10006453) for
n
more details
Bio-Rad
Laboratories, Inc.
Web site www.bio-rad.com USA 800 424 6723 Australia 61 2 9914 2800 Austria 01 877 89 01 Belgium 09 385 55 11 Brazil 55 31 3689 6600
Life Science
Canada 905 364 3435 China 86 20 8732 2339 Czech Republic 420 241 430 532 Denmark 44 52 10 00 Finland 09 804 22 00 France 01 47 95 69 65
Group
Germany 089 31 884 0 Greece 30 210 777 4396 Hong Kong 852 2789 3300 Hungary 36 1 459 6100 India 91 124 4029300 Israel 03 963 6050
Italy 39 02 216091 Japan 03 6361 7000 Korea 82 2 3473 4460 Mexico 52 555 488 7670 The Netherlands 0318 540666 New Zealand 0508 805 500
Norway 23 38 41 30 Poland 48 22 331 99 99 Portugal 351 21 472 7700 Russia 7 495 721 14 04 Singapore 65 6415 3188 South Africa 27 861 246 723
Spain 34 91 590 5200 Sweden 08 555 12700 Switzerland 061 717 95 55 Taiwan 886 2 2578 7189 United Kingdom 020 8328 2000
10006455 Rev B US/EG
Ordering Information
Catalog # Description
700-7001 Experion System, 100–240 V, for RNA and DNA analyses,
includes electrophoresis station, priming station, vortex
station, software, USB2 cable
700-7108 Experion DNA 12K Analysis Kit for 10 Chips, includes
10 DNA chips, 1 cleaning chip, 650 µl DNA 12K gel, 40 µl
DNA 12K stain, 20 µl DNA 12K ladder, 750 µl DNA 12K loading
buffer, 3 spin filters
700-7163 Experion DNA Chips, 10, for DNA 1K and 12K analyses,
plus 1 cleaning chip
700-7165 Experion DNA 12K Reagents and Supplies for 10 Chips,
includes 650 µl DNA 12K gel, 40 µl DNA 12K stain, 20 µl DNA
12K ladder, 750 µl DNA 12K loading buffer, 3 spin filters
700-7253 Experion DEPC-Treated Water, 100 ml
700-7262 Experion DNA 12K Ladder, 20 µl
700-7251 Experion Cleaning Chips, 10
700-7254 Experion Spin Filters, 10
700-7264 Cleaning Swabs, lint-free, for Experion system electrode
deep cleaning, 25
700-7252 Experion Electrode Cleaner, 250 ml
732-6300 PCR Kleen Spin Columns, 25
732-6223 Micro Bio-Spin 30 Columns, includes 25 columns in
Tris buffer, 50 collection tubes
LabChip and the LabChip logo are trademarks of Caliper Life
Sciences, Inc. Bio-Rad Laboratories, Inc. is licensed by Caliper Life
Sciences, Inc. to sell products using the LabChip technology for
research use only. These products are licensed under U.S. Patent
Nos. 5,863,753, 5,658,751, 5,436,134, and 5,582,977, and pending patent
applications, and related foreign patents, for internal research and development
use only in detecting, quantitating, and sizing macromolecules, in combination
with microfluidics, where internal research and development use expressly
excludes the use of this product for providing medical, diagnostic, or any other
testing, analysis, or screening services, or providing clinical information or
clinical analysis, in any event in return for compensation by an unrelated party.
09-0125 0210 Sig 1109
DNA 1K = C3
12K = C1
LOT# JM27UP02 LOT# JJ29UK01 LOT# KA31UK01 LOT# JJ05UK02
EXP APR/25/08 EXP MAR/31/08 EXP MAY/01/08 EXP DEC/05/07
Experion DNA 12K Analysis Kit
™
Quick Guide
DNA 12K Ladder
350
300
250
200
150
100
50
0
30 40 50 60 70 80 90
Time, sec
100
