OceanLED
This installation manual covers the following products:
XD16
Dock Light
XD16
OceanLED reserve the right to change this document without notice. Please refer to www.oceanled.com for latest documentation.
OceanLED INSTALLATION MANUAL / DOCK / 120416 / v6.2
OceanLED Marine
Product Support
DOCK LIGHT
INSTALLATION
MANUAL
Advertisement
Table of Contents
Related Manuals for Oceanled XD16
Summary of Contents for Oceanled XD16
- Page 1 INSTALLATION MANUAL OceanLED This installation manual covers the following products: XD16 Dock Light XD16 OceanLED reserve the right to change this document without notice. Please refer to www.oceanled.com for latest documentation. OceanLED INSTALLATION MANUAL / DOCK / 120416 / v6.2...
- Page 2 Always test the lights prior to installation. Failure to do this may result in additional installation time and could invalidate the warranty. GENERAL OceanLED underwater dock lights are generally used for illuminating the waters around marinas and waterways. Best placement for achieving the best results are described in selecting the right location. WARNING!
-
Page 3: Important Safety Precautions
WARNING: The OceanLED XD16 light fixtures are low voltage DC (vDC) products and cannot be used with low voltage AC (vAC) transformers. Use of low voltage AC (vAC) transformers mat cause injury and will damage the product invalidating the warranty. -
Page 4: Chapter 1: Overview
Chapter 1: Overview CHAPTER This handbook provides instructions to assist you in the installation and set up of the XD16 underwater dock light from OceanLED. XD16 Power supplies Only 24vDC Power Supplies are to be used with this product. When choosing a power supply, allow at least 15% reserve for voltage fluctuations due to variables beyond your control such as ambient temperature and supply voltage fluctuations to ensure your lights are always receiving the proper voltage and to ensure the power supply is not "overworked"... - Page 5 Considerations • Design - Your new OceanLED Dock Light(s) have a directional light beam that allows you to engineer a beautiful look around your property. Consider even spacing, boat traffic, tidal fluctuations, storms, seasons, and the overall desired effect when designing your installation.
-
Page 6: Wire Sizing
Your docklights come with 33 feet (10 meters) of cable as standard. Please refer to the chart below in the event that you have a wire run in excess of 50 feet (15 meters). CAUTION: OceanLED recommends running Dock Lights on 24vDC only. OceanLED INSTALLATION MANUAL / DOCK / 120416 / v6.2... -
Page 7: Chapter 2: Installation
National Electrical Code and all applicable local codes and ordinances. CAUTION: When connecting light units (fig. 3), please note that all OceanLED lights will operate to within a specific voltage range. Please check the electrical information supplied (Page 6) to check cable gauge, fuse recommendations, breaker size etc. - Page 8 8.0 Amps 192.5 W 221.4 W When connecting multiple lights to one power source the OceanLED 4-way junction box is recommended as this provides four independent separately fused outputs for each light. Power Cable selection It is important to select the correct size cable for the supply to the dock lights. The required cable gauge depends on the current draw and the length of the cable run from the power source to the light(s).
-
Page 9: Chapter 3: Operation, Maintenance, Repair, & Parts
Sea growth can collect quickly on the light and this can reduce the performance in just a few weeks. To prevent the build- up of sea growth, all OceanLED lights have been coated with a specialized Tritonium coating which makes the surface of the glass lens a non-stick layer which helps ward off long term barnacle buildup. - Page 10 Light will require replacing. This is not covered by the there is no damage to the warranty. cable. (If cable is damaged, it must only be replaced by OceanLED, service agent or similar qualified person). OceanLED INSTALLATION MANUAL / DOCK / 120416 / v6.2...
-
Page 11: Diagnostic Leds
(e.g. discharged battery) or voltage drops caused by poor connections or incorrect wire gauge. Flashing Internal fault detected with temperature sensor – if this issue persists contact your dealer. OceanLED INSTALLATION MANUAL / DOCK / 120416 / v6.2... -
Page 12: Chapter 4: Warranty
This warranty statement is for those products supplied to and sold from all territories internationally OceanLED stands by its products. In general terms, the company gives a full 2 year’s manufacturer’s warranty on all of its products from date of sale from OceanLED. -
Page 13: Limitation Of Liability
2.4. Subject to the above Condition 2.3: 2.4.1 the Company’s total liability in contract, (including without limitation negligence or breach of statutory duty), misrepresentation, restitution or otherwise, arising in connection with the OceanLED INSTALLATION MANUAL / DOCK / 120416 / v6.2... -
Page 14: Applicable Law
In order to proactively discourage this activity by Internet resellers of our product, OceanLED will not honor the warranty of products purchased via the grey market through internet resellers. The following notice will be added to OceanLED’s warranty cards, website and all internet sellers will be required to post the same notice. - Page 15 6.3.5 When you have made contact with the dealer please follow their instructions. 6.3.6 If you are unable to contact a dealer you may wish to contact OceanLED directly. To contact the Service Manager either call our UK office on +44 1455637505 or email sales@oceanled.com.
- Page 16 6.4.7 If we are unable to find a problem with the part, we will inform you of the outcome. We can provide guidance to possible reasons for the fault. Unfortunately we are not liable for or can fix problems with equipment & installations that are not purchased from OceanLED. The returned product can be returned to you at your request.
- Page 17 __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ OceanLED INSTALLATION MANUAL / DOCK / 120416 / v6.2...
- Page 18 __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ OceanLED INSTALLATION MANUAL / DOCK / 120416 / v6.2...
- Page 19 __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ OceanLED INSTALLATION MANUAL / DOCK / 120416 / v6.2...
- Page 20 Trademarks are the property of United States United Kingdom Ocean LED Marine LTD Tel: +44 (0) 1455 637505 Tel: +1 954.523.2250 Fax: +44 (0) 1455 238553 Fax: +1 954.523.2249 www.oceanled.com service@oceanledusa.com service@oceanledusa.com OceanLED INSTALLATION MANUAL / DOCK / 120416 / v6.2...
