OceanLED Support
INSTALL MANUAL
Sport Series
S3116s Single Colour
S3124s Dual Colour
S3166s Multi Colour
Product kit includes: Light / Screws / Fuse Kit
OceanLED reserve the right to change this document without notice. Please refer to www.oceanled.com for latest documentation.
OceanLED INSTALL / Sport Series / 190617 / v7.2
Advertisement
Table of Contents
Related Manuals for Oceanled Sport Series
Summary of Contents for Oceanled Sport Series
- Page 1 S3124s Dual Colour S3166s Multi Colour Product kit includes: Light / Screws / Fuse Kit OceanLED reserve the right to change this document without notice. Please refer to www.oceanled.com for latest documentation. OceanLED INSTALL / Sport Series / 190617 / v7.2...
-
Page 2: Warranty Coverage
LED cannot be held responsible for any consequential costs incurred after installation. GENERAL OceanLED underwater lights are generally used for illuminating the water around a boat or yacht. Best placement for achieving the best results are described in “1.5 Finding the mounting location”. -
Page 3: Important Precautions
This equipment is designed to operate at voltages of less than 50v DC. WARNING • Before installing your OceanLED Light, read and follow all warning notices and instructions which are included. Failure to follow safety warnings and instructions can result in property damage, severe injury or even death. -
Page 4: Chapter 1: Overview
CHAPTER Chapter 1: Overview This handbook provides instructions to assist you in the installation and set up of the Sport Series lights from OceanLED. 1.1 Identifying your model S3116s Single Colour S3124s Dual Colour S3166s Multi Colour 1.2 DC power / fuse ratings The majority of installations will utilize onboard 12/24v DC power supply from a marine battery. - Page 5 Ideal mounting depth is 10 – 20 cm / 4 - 8". • Ideally mount your Sport Series lights at similar depth levels when using underwater to ensure matching colour consistency through the water. Deeper lights will look duller and possibly differ in colour to shallower mounted units.
-
Page 6: Chapter 2: Installation
• shoulder screws to secure your lights to the hull. OceanLED recommends dry fitting all products. When installing, be sure that the light fits the area and se- • cures to the hull using the appropriate hardware before applying any sealant. - Page 7 inside the hull, remove it with acetone before sanding. Place light fixture into position or use mounting template provided. Mark the screw hole position and pilot drill using correct sized drill bit for included screws. Always dry fit units before applying any sealant. 2.2 Installing the light fixture TIP: Use a suitable marine sealant such as 3M™...
- Page 8 Connecting lights to your DC power source OceanLED Sport models require a 12/24v DC supply. This supply should be a minimal 6A @ 12vDC or 3A @ 24v DC per light. It is recommended to connect the light to the DC power source using a two pole, screw type terminal block with a minimum voltage rating of 50V and a current rating of at least 6A.
- Page 9 Always test the lights BEFORE the boat goes back into the water. Failure to test prior to launch may require boat to re hauled out. At this final stage make sure all of the system is operational. See Chapter 3 Operation. If you have any issues, please contact your local OceanLED representative. Warning: Never install a new light and leave the boat in the water unchecked for several days.
-
Page 10: Chapter 3: Operation
CHAPTER THREE Chapter 3: Operation 3.1 - Single Colour Strobe To enter strobe mode, toggle the power on and off quickly twice, then back on. They should now strobe in a pseudo-random pattern. The lights can be reset from strobe mode after 20 seconds of use. Simply turn off then back on again. - Page 11 3.4 Sport Multi Colour control with DC switch operation: The Sport Multi Colour has three modes of operation, single colour mode, cycle / programing mode, and strobe mode: Single colour mode – this mode is entered when the light is first turned on. The light will be a single colour, either a default white, or a previously selected colour.
-
Page 12: Chapter 4: Maintenance And Troubleshooting
Sea growth can collect quickly on the light and this can reduce the performance in just a few weeks. To prevent the build-up of sea growth, all OceanLED lights have been coated with a specialized Tritonium coating which makes the surface of the lens a non-stick layer which helps ward off long term barnacle buildup. - Page 13 Check cable to make sure there is no damage to Light will require This is not covered by the the cable. (If cable is damaged, it must only be replacing. warranty. replaced by OceanLED, service agent or similar qualified person).
-
Page 14: Chapter 5: Appendix
CHAPTER FIVE Chapter 5: Appendix SUPPLY CABLE CONDUCTOR SIZE CHART CABLE CIRCUIT CURRENT LENGTH 2 AMP 4 AMP 6 AMP 8 AMP 10 AMP 12 AMP 14 AMP 16 AMP (FEET) 18 AWG 18 AWG 16 AWG 16 AWG 16 AWG 14 AWG 14 AWG 14 AWG... -
Page 15: Chapter 6: Warranty Statement
This warranty statement is for those products supplied to and sold from all territories internationally OceanLED stands by its products. In general terms, the company gives a full 2 year’s manufacturer’s warranty on all of its products from date of sale from OceanLED. -
Page 16: Limitation Of Liability
1.3.5 the defect arises due to a cause beyond the Company’s reasonable control, such as: act of God, explosion, flood, tempest, fire or accident, including without limitation lightning; war or threat of war, national emergency, sabotage, terrorism, insurrection, protest, riot, epidemic, civil disturbance or requisition; Acts, restrictions, regulations, by-laws, prohibitions or measures of any kind on the part of any governmental, parliamentary or local authority;... -
Page 17: Making A Claim
6.3.5 When you have made contact with the dealer please follow their instructions. 6.3.6 If you are unable to contact a dealer you may wish to contact OceanLED directly. To contact the Service Manager either call our UK office on +44 1455637505 or email sales@oceanled.com. - Page 18 6.4.7 If we are unable to find a problem with the part, we will inform you of the outcome. We can provide guidance to possible reasons for the fault. Unfortunately we are not liable for or can fix problems with equipment & installations that are not purchased from OceanLED. The returned product can be returned to you at your request.
- Page 19 NOTES __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________...
-
Page 20: For Technical Assistance
Please remove this page and keep for your files For technical assistance: Europe: service@oceanled.com The Americas: warranty@oceanledusa.com Warranty Serial Code(s): © 2017 Ocean LED Marine LTD Ocean LED Marine LTD Ocean LED USA LLC All Rights Reserved Unit 1 Jacknell Road...
