Oceanled Sport Series Quick Install Manual

Hide thumbs Also See for Sport Series:
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

Ocean LED Marine LTD
Unit 1 Jacknell Road
Dodwells Bridge Industrial Estate
Hinckley,
Leicestershire LE10 3BS
United Kingdom
Tel: +44 (0) 1455 637505
Fax: +44 (0) 1455 238553
sales@oceanled.com
OceanLED USA
OceanLED USA LLC
778 South Military Trail
Deerfield Beach
Florida
Tel: +1 954.523.2250
Fax: +1 954.523.2249
sales@oceanledusa.com
© 2023 Ocean LED Marine LTD
All Rights Reserved
Specifications are subject to change
without notice.
Trademarks are the property of
Ocean LED Marine LTD
www.oceanled.com
OceanLED Quick INSTALL GUIDE / SPORT / 270623 / v8.0
For full installation guide and
warranty information, go to
www.oceanled.com/sport
or scan the QR code below:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Sport Series and is the answer not in the manual?

Questions and answers

Related Manuals for Oceanled Sport Series

Summary of Contents for Oceanled Sport Series

  • Page 1 Fax: +1 954.523.2249 sales@oceanledusa.com © 2023 Ocean LED Marine LTD All Rights Reserved Specifications are subject to change without notice. Trademarks are the property of Ocean LED Marine LTD www.oceanled.com OceanLED Quick INSTALL GUIDE / SPORT / 270623 / v8.0...
  • Page 2 Sport Series Quick Install Guide For full instructions visit www.oceanled.com/sport...
  • Page 3 WARNING: Do not use any un-authorised cleaning products to remove excess paint or antifoul off the front face of the light unit. OceanLED recommends using Isopro- pyl Alcohol (IPA) only. OceanLED does not recommend that bottom paint or any type of anti-fouling agent is applied to the light body, as damage may occur due to chemical incompatibility.
  • Page 4 1. Preparing a fiberglass hull NOTE: For installation on Metal and Carbon Fibre hulls, the optional Isolating Kit must be used, please refer to instructions supplied with the kit. Always wear safety goggles and a dust mask. Drill a 3mm / 1/8” pilot hole square to mounting surface from inside the hull if possible.
  • Page 5 When applying sealant to light fixture, be careful to protect the lens from any abrasive surface/floor so as not to remove the protective Tritonium coating Insert the light on to the hull, feeding the cable through first, and then seat into place.
  • Page 6 When connecting light units, please note that all OceanLED lights will operate within a specific voltage range. OceanLED Sport models require a 12/24V DC supply. This supply should be a minimum of 6A @ 12V DC or 3A @ 24V DC per light.
  • Page 7 4. Finalize your OceanLED installation Test your lights Always test the lights BEFORE the boat goes back into the water for a max. of 5 minutes. Failure to test prior to launch may require boat to re hauled out. Warning: When installing a new light on a boat, always check for leaks immediately after placing it in the water.
  • Page 8 IN LINE FUSE 12/24V DC 12/24V BLACK IN LINE FUSE IN LINE FUSE SPORT CABLE 12/24V DC (Non DMX) SPORT Series Black LIGHTS DC Switch Mode – join BLACK, BROWN & YELLOW wires SPORT CABLE Brown 12/24V DC DMX COLOURS Yellow...
