Ocean LED Marine LTD
Unit 1 Jacknell Road
Dodwells Bridge Industrial Estate
Hinckley,
Leicestershire LE10 3BS
United Kingdom
Tel: +44 (0) 1455 637505
Fax: +44 (0) 1455 238553
sales@oceanled.com
OceanLED USA
OceanLED USA LLC
778 South Military Trail
Deerfield Beach
Florida
Tel: +1 954.523.2250
Fax: +1 954.523.2249
sales@oceanledusa.com
© 2017 Ocean LED Marine LTD
All Rights Reserved
Specifications are subject to change
without notice.
Trademarks are the property of
Ocean LED Marine LTD
www.oceanled.com
OceanLED INSTALL GUIDE / SPORT / 170317 / v7.1
For full installation guide and
warranty information, go to
www.oceanled.com/Sport
or scan the QR code below:
Advertisement
Table of Contents
Related Manuals for Oceanled Marine LTD Sport Series
Summary of Contents for Oceanled Marine LTD Sport Series
- Page 1 Tel: +1 954.523.2250 Fax: +1 954.523.2249 sales@oceanledusa.com © 2017 Ocean LED Marine LTD All Rights Reserved Specifications are subject to change without notice. Trademarks are the property of Ocean LED Marine LTD www.oceanled.com OceanLED INSTALL GUIDE / SPORT / 170317 / v7.1...
- Page 2 Sport Series Quick Install Guide For full instructions visit www.oceanled.com/sport...
- Page 3 Be sure you follow the correct procedures for the hull you are preparing since all require different preparation methods. We will cover the most common type below. If in doubt please contact your local OceanLED representative or the boat manufacturer for assistance.
- Page 4 1. Preparing a fiberglass hull NOTE: For installation on Metal and Carbon Fibre hulls, please contact OceanLED for correct guidance on fitting. Tip: Always wear safety goggles and a dust mask. Drill a 3mm / 1/8” pilot hole square to mounting surface from inside the hull if possible.
- Page 5 TIP: It is critical to cover the entire body and circle the mounting screw hole so that there is a continuous and unbroken bead of sealant. Insert the light on to the hull, feeding the cable through first and seat into place.
- Page 6 When connecting light units, please note that all OceanLED lights will operate within a specific voltage range. OceanLED Sport models require a 12/24v DC supply. This supply should be a minimal 6A @ 12vDC or 3A @ 24v DC per light.
- Page 7 4. Finalize your OceanLED installation Test your lights Always test the lights BEFORE the boat goes back into the water. Failure to test prior to launch may require boat to re hauled out. At this final stage make sure all of the system is operational (see online manual). If you have any issues, please contact your local OceanLED representative.
- Page 8 12/24V DC Connection Diagram FUSE/BREAKER POWER SWITCH (NOT SUPPLIED) FUSE (NOT SUPPLIED) BLACK FUSE FUSE SPORT S3116s...
