LETHAL ENFORCERS II GUN FIGHTERS TM is a trademark of KONAMI (America) Inc.
1994 KONAMI (America) Inc. All rights reserved.
Service & Parts #
708-215-5100
George Limonez Ext. 122 or 123
Catherine Hilario Ext. 123
INSTRUCTION MANUAL
Konami lndosfry Co., Ltd.
of

Advertisement

loading
Need help?

Need help?

Do you have a question about the Lethal Enforcers II Gun Fighters and is the answer not in the manual?

Questions and answers

Summary of Contents for Konami Lethal Enforcers II Gun Fighters

  • Page 1 LETHAL ENFORCERS II GUN FIGHTERS TM is a trademark of KONAMI (America) Inc. 1994 KONAMI (America) Inc. All rights reserved. Service & Parts # 708-215-5100 George Limonez Ext. 122 or 123 Catherine Hilario Ext. 123 INSTRUCTION MANUAL Konami lndosfry Co., Ltd.
  • Page 2 LETHAL ENFORCERS II GUN FIGHTERS has the capability of two different play settings. ARCADE VERSION 1 or 2 people may play at the same time. The players must use their skill to advance to higher stages. STREET VERSION 1 or 2 people may play at the same time.
  • Page 3 LETHAL ENFORCERS i! PARTS LIST GUN FlGHTERS Part # Description Gun Fighters AC Harness 191010 Gun Fighters DC Harness 191011 312003 Gun Fighters PCB Gun Fighters Control Panel Overlay 312100 Gun Fighters Upper Bezel Decal 312104 Gun Fighters Lower Bezel Decal 312105 Gun Fighters Marquee 312200...
  • Page 4 LETHAL ENFORCERS ii WIRING HARNESS GUN FIGHTERS Solder Side BLACK BLACK BLACK BLACK ORANGE ORANGE BROWN/YELLOW COIN COUNTER COIN COUNTER GREEN/VIOLET VIDEO GREEN WHITE/GREEN RED/WHITE WHITE VIDEO SYNC VIDEO BLUE BLUE/WHITE VIDEO GROUND BLACK TEST SWITCH GRAY/WHITE WHITE/VIOLET BLUE/VIOLET RED/GREEN BLACK BLACK BLACK...
  • Page 5: Technical Information

    TECHNICAL INFORMATiON GUN FIGHTERS Required power capacity GND-Vcc 5V 4A or more GND-( + 12V) *See the Wiring Diagram. output R (red) analog, positive G (green) analog, positive SYNC. H-V complexed, negative The monitor should be horizontal and face up installed. There is no sound volume knob on the PCB.
  • Page 6 TECHNICAL INFORMATIOhi (cont.) GUN FIGHTERS (STARTING NO STAGE SELECTION TYPE GAME) 1 or 2 players can play at the same time. Second player can join in at any time. Deposit coins and press START button. (STARTING STAGE SELECTION TYPE GAME) Deposit coins and press START button, and the stage select screen will appear.
  • Page 7 TECHNICAL INFORMATION (cont.) GUN FIGHTERS MAIN MENU GUN CHECK SCREEN CHECK COLOR CHECK MASK ROM CHECK DIP SWITCH SETTINGS SOUND OPTIONS GAME OPTIONS COIN OPTIONS GAME MODE GUN TRIGGER=DO CHECK . I/O CHECK Check both START buttons and Triggers to see “ON” when switched on. Press player 1 and 2 START buttons at the same time to return to MAIN MENU.
  • Page 8: Game Options

    LETHAL ENFORCERS II TECHNICAL INFORMATION (cont.) GUN FIGHTERS SOUND OPTIONS SOUND IN ATTRACT MODE=ALL THE TIME Select out of “ALL THE TIME,” “COMPLETE OFF,” “ONCE EVERY 4 CYCLES” SOUND VOLUME=13 Sound volume from 0 to 30 SOUND SCALE CHECK Music scale sounds All the settings return to default FACTORY SETTINGS SAVE AND EXIT...
  • Page 9: Coin Options

    LETHAL ENFORCERS II TECHNICAL INFORMATION (cont.) GUN FIGHTERS (9) COIN OPTIONS COIN OPTIONS FREE PLAY COIN MECHANISM COMMON 1 COIN 1 CREDIT COIN SLOT1 (sw2) 1 COIN 1 CREDIT COIN SLOT2 YES 1 “NO” or “YES 1” to “YES 4.” (You can set the play fee PREMIUM START for starting higher than the play fee for continuation) 2 CREDITS TO START...
  • Page 10 TOP ON/OFF SWITCH COLOR MONITOR 110 G 0 *NOTE COLOR CHANGE *NOTE COLOR CHANGE POWER SUPPLY...
  • Page 25 LETHAL ENFORCERS II MO,-HER PCB LAyoUT GUN FIGHTERS...
  • Page 27 C O L O R M O N I T O R GX312 G U N SENSOR G U N 2 P Note: (2) SURGE KILLER DIODES FOR COIN COUNTER INSTALLED ON THE PCS OUTPUTS AT THE SAME TIME. (-) m GNO. O N N E C T S P E A K E R SPEAKER (-).
  • Page 28 II SU33UOdN3 lWHl.31...
  • Page 29 THIS EQUIPMENT COMPLIES WITH THE REQUIREMENTS IN PART 15 OF FCC RULES FOR A CLASS A COMPUTING DEVICE. OPERATION OF THIS EQUIP- MENT IN A RESIDENTIAL AREA MAY CAUSE UNACCEPTABLE INTERFERENCE TO RADIO AND TV RECEPTION REQUIRING THE OPERATOR TO TAKE WHATEVER STEPS ARE NECESSARY TO CORRECT THE INTERFERENCE.
