- Page 1 RUN AND GUNTM is a trademark of KONAMI (America) Inc. 1993 KONAMI (America) Inc. All rights reserved. Service %I Parts # George Limonez Ext. 122 or 123 INSTRUCTION MANUAL (America) Inc. is a trademark of Konami lndostry Co., Ltd. N o . 2 4 7 4 0 0...
- Page 2 RUN AND GUN PARTS LIST Part # Description Description Part # 35406 247003 Run &Gun PCB P o w e r S u p p l y 247010 40530 DC Harness Monitor 30502 247011 AC Harness Control Panel Hinge 30254...
-
Page 3: Technical Information
TECHNICAL INFORMATION Required power capacity GND-Vcc 5V 4A or more GND-( + 12V) *See the Wiring Diagrams There is no sound volume knob on the PCB. Sound level should be adjusted in the Manual Test Mode. Handle with care. This PCB should be used in the exclusive cabinet. PLAYING INSTRUCTION This game’s play time is 1 quarter per credit. -
Page 4: Control Panel Information
CONTROL PANEL INFORMATION Player moves with the joystick. The buttons have different uses depending on whether you are on offense or defense. On offense, button A is for shoot or rebound. Button B is for pass to teammate. Button C (only for 1 play) is to choose the teammate to pass to. - Page 5 RUN AND GUN TECHNICAL INFORMATION (cont.) (4) EXPLANATION OF THE ITEMS The following screen below will appear. Select item to be modified with Player JOYSTICK up/down and move JOYSTICK right/left to modify setting. Factory settings are shown in green, and modified results in red.
-
Page 6: Coin Options
RUN AND GUN TECHNICAL INFORMATION (cont.) 6. COIN OPTIONS When you select this item, the following screen will appear. The specifications are for COMMON coin slot (DIP SW2 off) and for INDEPENDENT coin slot (DIP SW2 on). COIN OPTIONS INDEPENDENT Indication for INDEPENDENT setting. - Page 7 RUN AND GUN SUB HARNESS FOR 3 & 4 PLAYERS Violet/White White/Red White/Yellow White/Black White/Blue 3P Down White/Brown 3P Shoot/Jump White/Orange 3P Pass/Steal White CONTROLS 3P Select White/Green 3P Start Empty Empty Empty Empty Black Ground Blue Coin 4 Empty...
- Page 8 RUN AND GUN WIRING HARNESS BLACK BLACK BLACK BLACK USED USED ORANGE ORANGE *KEY *KEY COIN COUNTER GREEN/VIOLET WHITE/GREEN RED/WHITE WHITE VIDEO BLUE BLUE/WHITE BLACK YELLOW WHITE/VIOLET BLUE/VIOLET RED/YELLOW RED/GREEN BLUE/YELLOW ORANGE/WHITE 2 P D O W N 1 W 1 19 1 lP.DOWN...
- Page 9 RUN AND GUN A.C. WIRING HARNESS Flourescent Bulb Color Monitor Color Monitor *Note Color Change Black Green White Power Supply...
- Page 11 N O T E...
- Page 22 THIS EQUIPMENT COMPLIES WITH THE REQUIREMENTS IN PART 15 OF FCC RULES FOR A CLASS A COMPUTING DEVICE. OPERATION OF THIS EQUIP- MENT IN A RESIDENTIAL AREA MAY CAUSE UNACCEPTABLE INTERFERENCE TO RADIO AND TV RECEPTION REQUIRING THE OPERATOR TO TAKE WHATEVER STEPS ARE NECESSARY TO CORRECT THE INTERFERENCE.
