Fluke T6-600 Quick Reference Manual

Quick Reference Guide
T6-600/T6-1000
Electrical Tester
with FieldSense Technology
»
See "Safety Information".
Go to www.fluke.com to register your product and find more information, or
download this Quick Reference Guide in other languages.
Fork Opening 17.8 mm
1
6
2
3
4
HOLD
5
AUTO
SELECT
7
T6-1000
ELECTRICAL TESTER
PN 4897598 September 2017 Rev. 2, 11/17
© 2017 Fluke Corporation. All rights reserved.
Specifications are subject to change without notification.
Overview
1 Wire Position
1 Wire Only
2
Finger Guard
For safe operation, hold the
Tester behind the finger guard.
3
Display
Model T6-1000 Model T6-600
4 X Hazardous Voltage ≥30 V
5
Function Selection/On/Off
Auto Off
15 min
6
FieldSense Ground Contact
7
Test Probes/Storage Dock
Symbols
W
WARNING. RISK OF DANGER. Test with fork and FieldSense ground contact.
»
Consult user documentation. Test with fork and ground probe.
Y
Hazardous voltage ≥30 V. Test with probes.
FieldSense Measurement: Fluke voltage/current
Battery full charge.
sensing technique.
J
Battery low. Replace. Good earth ground connection.
J
Back light No earth ground connection.
Specifications
Model T6-1000 Model T6-600
Requires
Function Range Range
Test Leads
FieldSense
No 1000 V 600 V
Voltage ac
FieldSense
No 200.0 A 200.0 A
Current ac
FieldSense
No 45 Hz to 66 Hz
frequency (Hz)
Voltage ac Yes 1000 V 600 V
Voltage dc Yes 1000 V 600 V
Yes 2000 Ω 2000 Ω
Resistance Yes 20.00 kΩ
Yes 100.0 kΩ
[1] Accuracy: ±( [ % of reading] + [number of least significant digits] ). Accuracy is specified for 1 year after calibration, at
18 °C to 28 °C (64 °F to 82 °F) with relative humidity to 90 %. AC measurements are accoupled, RMS responding.
[2] Add 3 % without an external ground connection. External ground connection required for user wearing insulated gloves,
standing on an insulated ladder, or otherwise insulated from earth ground.
[3] FieldSense is specified from 16 V to 100 % of range.
Fork opening 17.8 mm
Temperature
Operating -10 °C to +50 °C (+14 °F to +122 °F)
Storage -30 °C to +60 °C (-22 °F to +140 °F)
Altitude
Operating 2000 m
Storage 10 000 m
Relative Humidity 0 % to 90 %, 5 °C to 30 °C (41 °F to 86 °F)
0 % to 75 %, 30°C to 40 °C (86 °F to 104 °F)
0 % to 45 %, 40°C to 50 °C (104 °F to 122 °F)
Battery Type and Life 2x AA (IEC LR6) 360 hr continuous, typical is 200 hr using the FieldSense function
Temperature coefficient 0.1 x (specified accuracy) / °C for <18°C or >28 °C (<64.4 °F or >82.4 °F)
Replacement Parts
Test Lead Assembly (T5-RLS) Replace
only with Fluke double-insulated leads
()
TP1 Probe Set, Flat-Blade
Battery Door
Battery Door Screw
Use only specified replacement parts
Lead Replacement
.
Resolution Accuracy
[1]
±(3 % + 3 counts)
1 V
45 Hz to 66 Hz [2] [3]
±(3 % + 3 counts)
0.1 A
45 Hz to 66 Hz
1 Hz ±(1 % + 2 counts)
[3]
Accessories
● HT6 ●
±(1.5 % + 2 counts)
1 V
45 Hz to 66 Hz
● HT6 Belt Holster
1 V ±(1 % + 2 counts)
● TPAK Hanger
1 Ω
● PRV240FS
0.01 kΩ ±(1 % + 2 counts)
● AC285 SureGrip™ Alligator Clips
0.1 kΩ
● AC220 SureGrip™ Alligator Clips
Contact Fluke
USA:
USA: 1-800-44-FLUKE (1-800-443-5853)
Canada: 1-800-36-FLUKE (1-800-363-5853)
Europe: +31 402-675-200
Japan: +81-3-6714-3114
Singapore: +65-6799-5566-5655
China: +86-400-921-08365
Anywhere in the world: +1-425-446-5500
PN 4462973
PN 648128
PN 4944370
PN 1618579
