DSC HD-HD 4K A Setup Guide
The Extron DSC HD-HD 4K A is a high performance, HDCP 1.4 and 2.2 compliant scaler capable of processing HDMI resolutions
up to 4K @ 30 Hz with full 4:4:4 signal processing and 4K @ 60 Hz with 4:2:0. It features HDMI 1.4 and 2.0 connections that
support data rates up to 8.91 Gbps. This setup guide provides step-by-step instructions for an experienced user to set up and
configure the DSC HD-HD 4K A. It also describes basic operations using
Simple Instruction Set (SIS

Installation

ATTENTION:
• Installation and service must be performed by authorized personnel only.
• L'installation et l'entretien doivent être effectués par le personnel autorisé uniquement.
NOTE:
For full installation, configuration, menus, connector wiring, and operation details, see the DSC HD-HD 4K A Series
User Guide, available at www.extron.com.

Rear Panel Features

A A B B
100-240VAC ~ 0.7 A MAX
INPUT
HDMI
50-60 Hz
AC power connector
A
HDMI input connector
B
HDMI output connector
C
DSC HD-HD 4K A Rear Panel
Figure 1.

Setup Overview

Disconnect power — Turn off or disconnect all equipment power sources.
1.
Mount the unit (optional) — Mount the DSC HD-HD 4K HD A either in a rack using shelf mounting bracket kits (available
2.
at www.extron.com) or under furniture using furniture mounting brackets (see the instructions provided with the kit).
Alternatively, attach the four provided rubber feet at the corners of the unit and place it on a table top.
Connect the HDMI video input and output — Connect an HDMI video source to the HDMI input connector (
3.
display to the HDMI output (
Connect an audio input device (optional) — Connect
4.
an analog audio source to the 5-pole captive screw Audio
In connector ( ) to embed balanced or unbalanced
D
analog audio in the HDMI output signal.
Connect an audio output device (optional) —
5.
Connect an audio output device to the 5-pole captive
screw Audio Out connector (
Connect a control device — For remote control,
6.
connect a computer or control system to any of these ports:
• Remote RS-232 — This 3-pole captive screw RS-232 connector (
commands. RS-232 protocol for this port is 9600 baud, 1 stop bit, no parity, 8 data bits, and no flow control.
• USB — This front panel USB mini-B port (See
control via SIS commands or the Extron PCS Configuration software.
• LAN — This RJ-45 Ethernet jack (
commands, PCS, or the device internal web page.
) commands.
™
C C
OUTPUT
HDMI
Analog audio input connector
D
Analog audio output connector
E
Ethernet LAN connector
F
) connector. Secure each HDMI device to the connector with a provided LockIt
C
) for analog audio output.
E
figure
) connects the unit to a network, enabling you to configure the DSC via SIS
F
front panel controls, the
D D E E F F G G H H I I
AUDIO IN
LAN REMOTE
L R
L R
RS -232
RESET
Tx Rx G
AUDIO OUT
Tip
Ring
Sleeves
Tip
Ring
Balanced Stereo Input
Tip
Ring
Sleeves
Tip
Ring
Balanced Audio Output
G ) enables serial control via SIS
2,
B , on the next page) enables configuration and
OSD menu system, and
Remote RS-232 connector
G
Reset LED
H
Reset button
I
bracket.
®
Tip
Sleeve
Tip
Sleeve
Unbalanced Stereo Input Do not tin the wires!
No Ground Here
Tip
Sleeves
Tip
No Ground Here
Unbalanced Audio Output Do not tin the wires!
) and a
B
inch (5 mm) MAX.
inch (5 mm) MAX.
RS-232
Tx Rx G
1
