Telefunken TK2129ST Service Manual page 9

Item No.
08-02109X-CR3 ASS'Y - CRT PARTS
10-1N4148-ABX DIODE 1N4148 (SWITCHING)
10-1N4148-ABX DIODE 1N4148 (SWITCHING)
11-0BF422-0BX TRANSISTOR BF422 (NPN)
11-0BF422-0BX TRANSISTOR BF422 (NPN)
11-0BF422-0BX TRANSISTOR BF422 (NPN)
11-A562TM-0BX TRANSISTOR 2SA562TM-0
11-SC1815-YBX TRANSISTOR 2SC1815Y
11-SC1815-YBX TRANSISTOR 2SC1815Y
11-SC1815-YBX TRANSISTOR 2SC1815Y
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5%
18-CB0272-JNX RES. C.F. 2.7k OHM 1/6W +/-5%
18-CB0561-JNX RES. C.F. 560 OHM 1/6W +/-5%
18-CB0561-JNX RES. C.F. 560 OHM 1/6W +/-5%
18-CB0561-JNX RES. C.F. 560 OHM 1/6W +/-5%
18-CB0561-JNX RES. C.F. 560 OHM 1/6W +/-5%
18-CB0561-JNX RES. C.F. 560 OHM 1/6W +/-5%
18-CB0561-JNX RES. C.F. 560 OHM 1/6W +/-5%
18-CB0681-JNX RES. C.F. 680 OHM 1/6W +/-5%
18-CB0681-JNX RES. C.F. 680 OHM 1/6W +/-5%
18-CB0681-JNX RES. C.F. 680 OHM 1/6W +/-5%
18-CB0681-JNX RES. C.F. 680 OHM 1/6W +/-5%
18-CB0681-JNX RES. C.F. 680 OHM 1/6W +/-5%
18-FE0272-JNX RES. M.O. 2.7K OHM 1/2W +/-5%
18-FE0272-JNX RES. M.O. 2.7K OHM 1/2W +/-5%
18-FE0272-JNX RES. M.O. 2.7K OHM 1/2W +/-5%
18-FG0153-JHX RES. M.O. 15k OHM 2W +/-5%
18-FG0153-JHX RES. M.O. 15k OHM 2W +/-5%
18-FG0153-JHX RES. M.O. 15k OHM 2W +/-5%
25-BLA100-M1X CAP. ELEC 10 UF 250V +/-20%
26-AMK102-KRX CAP. CER 1000 pF 2KV +/-10% R
26-EBP102-KBX CAP. CER 1000 PF 50V +/-10% B
26-EBP102-KBX CAP. CER 1000 PF 50V +/-10% B
26-EBP471-JCX CAP. CER 470PF 50V +/-5% CH
26-EBP471-JCX CAP. CER 470PF 50V +/-5% CH
26-EBP471-JCX CAP. CER 470PF 50V +/-5% CH
34-R100K2-1BX COIL CHOKE 10 UH +/-10%
35-139730-00X FERR. BEAD BF60
41-WJ0050-B00 WIRE BARE JUMPER 5MM
41-WJ0050-B00 WIRE BARE JUMPER 5MM
41-WJ0050-B00 WIRE BARE JUMPER 5MM
Description Quantity Req. Designator
1
1 D501
1 D502
1 Q501
1 Q503
1 Q505
1 Q507
1 Q502
1 Q504
1 Q506
1 R515
1 R514
1 R501
1 R505
1 R510
1 R503
1 R508
1 R513
1 R502
1 R506
1 R509
1 R511
1 R522
1 R519
1 R520
1 R521
1 R516
1 R517
1 R518
1 C504
1 C505
1 C509
1 C508
1 C501
1 C502
1 C503
1 L502
2 FOR C508 (L505 & L506)
1 L504
1 L501
1 L503
9
Remarks
