Telefunken TK2129ST Service Manual page 27

Item No.
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F
34-A189J0-1IX COIL CHOKE 1.8 UH +/-5%
18-CB0221-JNX RES. C.F. 220 OHM 1/6W +/-5%
25-GFB478-K1X CAP. ELEC 0.47 UF 50V 10%CEC-K
10-CW574C-DJX DIODE CW574CD
18-FH0472-JLX RES. M.O. 4.7K OHM 3W +/-5%
18-FH0822-JLX RES. M.O. 8.2K OHM 3W +/-5%
46-33079W-03X PIN BASE *3 TJC3-3A
46-33079W-04X PIN BASE *4 TJC3-4A
48-TAC002-XX0 TACT SWITCH
08-D276SX-PAN ASS'Y - PACKING
49-267710-BAT BATT. R6P AA SUM3 5#
74-022032-6WE POLYBAG (23cmX34cmX0.06mm)
74-120120-80HAA POLYBAG W/SUFFOCATION WARNING
75-D276LL-CC0 POLYFOAM "LL"
75-D276LR-CC0 POLYFOAM "LR"
75-D276UL-CC0 POLYFOAM "UL"
75-D276UR-CC0 POLYFOAM "UR"
76-A21276-1AT CARTON BOX
62-377580-0HD SAFEGUARDING COVER PP-H1500 (HB)
74-010050-40C POLYBAG FOR POWER (10CMX50CM)
08-021189-FRY ASS'Y - F/R PACKING
74-100100-8CD POLYBAG (100CMX100CM)
74-279070-50C EPE BOARD (580mmX440mmX5mm)
74-279080-50C EPE BOARD (900mmx300mmx5mm)
76-001497-0AF CARTON BOX LWH 640X460X360MM
76-00D189-0AF CARTON BOX
76-00D189-0AR CARTON BOX
76-346740-01A CARTON SHEET LWH 440X620X3MM
77-100100-6WC BUBBLE BAG (100cmX100cm)
08-HS45E0-PAY ASS'Y - PACKING OF IR HANDSET
76-002091-0AT CARTON BOX LWH 624X384X556MM
76-326350-01A CARTON SHEET 61X37X0.3CM
08-HS45E0-M23A ASS'Y - REMOTE HANDSET
11-0BC337-0BX TRANSISTOR (NPN) BC337-40
13-M34282-M2B IC M34282MX
14-IRE05B-XX0 IR EMITTING DIODE TSAL6200
18-CB0221-JNX RES. C.F. 220 OHM 1/6W +/-5%
18-CB0109-JNX RES. C.F. 1 OHM 1/6W +/-5%
Description Quantity Req. Designator
1 C215
1 C216
1 C616
1 L106
1 R287
1 C213
1 D101
1 R402
1 R101
1 P005
1 . P004 ( P2 TO P5)
1 S008
1
0
1
1
0
0
0
0
0
2
1
1
2 FOR F/R CABINET
0.25 FOR FRONT CABINET
0.6666 FOR REAR CABINET
0.0285 FOR OTHER
0.25 FOR FRONT CABINET
0.3333 FOR REAR CABINET
0.0428 FOR OTHER
0.5 FOR FRONT CABINET
1
0.0025
0.06
1
1 Q1501
1 IC1501
1 D1501
1 R1501
1 R1502
27
Remarks
