Telefunken TK2129ST Service Manual page 12

Item No.
25-343260-M1X CAR. ELEC
25-BJG221-M1X CAP. ELEC 220 UF 160V +/-20%
26-AIC221-KBX CAP. CER 220 PF 500V +/-10% B
26-AIC221-KBX CAP. CER 220 PF 500V +/-10% B
26-AIM103-KBX CAP. CER 0.01UF 500V +/-10% B
26-AIM103-KBX CAP. CER 0.01UF 500V +/-10% B
26-AQK472-ZFX CAP. CER 4700PF 250VAC+80-20%F
26-AQK472-ZFX CAP. CER 4700PF 250VAC+80-20%F
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F
26-EBP220-JZX CAP. CER 22PF 50V +/-5% SL TU
26-EBP561-JCX CAP. CER 560PF 50V +/-5% CH
27-MBC224-J0X CAP. M.P.E 0.22UF 63V +/-5%
27-MHM104-K0X CAP. METAL P.E. 0.1UF 400V 10%
27-MQW683-M0X CAP.M.PE 0.068UF 250VAC +/-20%
27-PBC102-J0X CAP. P.E 0.001UF 63V +/-5%
27-PBC103-J0X CAP. P.E. 0.01UF 63V +/-5%
27-PBC103-J0X CAP. P.E. 0.01UF 63V +/-5%
27-PBC222-J0X CAP. P.E 0.0022UF 63V +/-5%
34-R101K2-1BX COIL CHOKE 100 UH +/-10%
35-139730-00X FERR. BEAD BF60
35-139730-00X FERR. BEAD BF60
35-139730-00X FERR. BEAD BF60
35-237250-00X FERR. BEAD HF70 4.5X5.0
36-LIF001-XX0 LINE FILTER LCL1602
41-AJ0125-BEE WIRE BARE JUMPER 12.5MM
41-WJ0050-B00 WIRE BARE JUMPER 5MM
41-WJ0050-B00 WIRE BARE JUMPER 5MM
41-WJ0050-B00 WIRE BARE JUMPER 5MM
41-WJ0050-B00 WIRE BARE JUMPER 5MM
41-WJ0050-B00 WIRE BARE JUMPER 5MM
41-WJ0050-B00 WIRE BARE JUMPER 5MM
41-WJ0050-B00 WIRE BARE JUMPER 5MM
41-WJ0050-B00 WIRE BARE JUMPER 5MM
41-WJ0075-B00 WIRE BARE JUMPER 7.5MM
41-WJ0075-B00 WIRE BARE JUMPER 7.5MM
41-WJ0075-B00 WIRE BARE JUMPER 7.5MM
41-WJ0150-B00 WIRE BARE JUMPER 15MM
41-WJ0150-B00 WIRE BARE JUMPER 15MM
41-WJ0175-B00 WIRE BARE JUMPER 17.5MM
Description Quantity Req. Designator
1 C845
1 C827
1 C840
1 C843
1 C826
1 C808
1 C804
1 C805
1 C844
1 C846
1 C841
1 C810
1 C808A
1 C814
1 C803
1 C818
1 C815
1 C817
1 C812
1 C811
1 L804
2 FOR L801
2 FOR D831 (L810 & L811)
2 FOR D830 (L808 & L809)
2 FOR D824 (L806 & L807)
1 T803
1 L801 FOR FERR. BEAD BF60 X2
1 J810
1 J811
1 J812
1 J813
1 J814
1 J815
1 J816
1 J817
1 J803
1 J805
1 J806
1 J801
1 J804
1 J802B
12
Remarks
