Telefunken TK2129ST Service Manual page 25

Item No.
66-343730-0B0 HOLLOW RIVET 1.6X3.0XL3.2
67-H10918-4M2 HEAT SINK
67-H30752-1A0 HEAT SINK
67-H30752-4A0 HEAT SINK (A=75MM)
67-H30752-5A0 HEAT SINK
41-WJ0075-B00 WIRE BARE JUMPER 7.5MM
18-CB0101-JNX RES. C.F. 100 OHM 1/6W +/-5%
18-CB0101-JNX RES. C.F. 100 OHM 1/6W +/-5%
10-1N4148-ABX DIODE 1N4148 (SWITCHING)
10-0FR104-FBX DIODE FR104 (FAST RECTIFIER)
10-0FR104-FBX DIODE FR104 (FAST RECTIFIER)
10-0FR104-FBX DIODE FR104 (FAST RECTIFIER)
36-HDR001-AX1 TRANSFOR HOR. DRIVE (MAGNETIC CORE)
67-H10918-4M2 HEAT SINK
64-P30060-104 M/C SCREW 3 X 6 (ZINC)
25-BCA102-M1X CAP. ELEC 1000 UF 16V +/-20%
25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20%
25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20%
25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20%
25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20%
25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20%
25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20%
25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20%
25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20%
25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20%
25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20%
25-BCB101-M1X CAP. ELEC 100 UF 16V +/-20%
25-BCB101-M1X CAP. ELEC 100 UF 16V +/-20%
25-BCB101-M1X CAP. ELEC 100 UF 16V +/-20%
25-BCB101-M1X CAP. ELEC 100 UF 16V +/-20%
25-BCB101-M1X CAP. ELEC 100 UF 16V +/-20%
25-BCB220-M1X CAP. ELEC 22 UF 16V +/-20%
25-BCB220-M1X CAP. ELEC 22 UF 16V +/-20%
25-BCB221-M1X CAP. ELEC 220 UF 16V +/-20%
25-BCB221-M1X CAP. ELEC 220 UF 16V +/-20%
25-BCB470-M1X CAP. ELEC 47 UF 16V +/-20%
25-BCB470-M1X CAP. ELEC 47 UF 16V +/-20%
25-BCB470-M1X CAP. ELEC 47 UF 16V +/-20%
25-BCB470-M1X CAP. ELEC 47 UF 16V +/-20%
25-BCB470-M1X CAP. ELEC 47 UF 16V +/-20%
25-BCB471-M1X CAP. ELEC 470 UF 16V +/-20%
Description Quantity Req. Designator
2 FOR C827
1 FOR IC401
1 FOR IC301
1 FOR IC603
1 FOR Q402
1 J051
1 R105
1 R106
1 J063 (-) TO R825
1 D401
1 D402
1 D403
1 T401
1 FOR IC402
1 FOR IC402
1 C416
1 C904
1 C905
1 C907
1 C908
1 C041
1 C217
1 C236
1 C245
1 C246
1 C615
1 C901
1 C101
1 C225
1 C624
1 C030
1 C912
1 C921
1 C224
1 C103
1 C028
1 C202
1 C241
1 C423
1 C285
1 C418
25
Remarks
