Summary of Contents for Telefunken TTV-21N02
- Page 1 51cm COLOUR TELEVISION MODEL TTV-21N02 Description: Manual(3Y11) 48005M TELEFUNKEN Job No. Brand Name: 21N02 Model: P/No. Rev.4 Scale: Engineering Dept: 2004-08-18 Artwork By: Date: Checked By: Date: Approved By: Date:...
- Page 2 SPECIFICATIONS Receiving System : BG Colour System : PAL / NTSC Playback Picture Tube : 51cm (21") diagonal Ext. Antenna : 75 Ohm Coaxial Cable Ext. In/Out Audio/video -in/out Speaker : 2 s peakers Audio Output : Maximum 3W Power Consumption : AC 240V 50Hz, 80W Dimension : 604(W) x513(D) x 462(H)mm...
-
Page 3: Table Of Contents
CONTENTS INTRODUCTION..........................WARNINGS and CAUTIONS ......................3 - 4 CONTROL LOCATION ........................INPUT and OUTPUT ......................... OPERATION INSTRUCTIONS ......................LOCATION OF CONTROL(REMOTE CONTROL UNIT) ..............9-10 BATTERY INSTALLATION......................... SERVICE TIPS .......................... -
Page 4: Introduction
INTRODUCTION Thank you for purchasing this television. To get the most out of this unit please carefully read the instructions and keep them in a safe place for future reference. INSTALLATION Locate your television away from direct sunlight. Viewing in total darkness or with sunlight reflection could cause eyestrain. -
Page 5: Warnings And Cautions
WARNINGS and CAUTIONS Warning High voltages are used in the operation of this television receiver. Do not remove the cabinet back from your set. Refer servicing to qualified service personnel. Warning To prevent fire or electrical shock hazard , do not expose the television receiver to rain or moisture. - Page 6 WARNINGS and CAUTIONS Caution Never stand on, lean on or push suddenly the television or its stand .You should pay special attention to children. Serious injury may result if it should fall. Caution Do not place your television on an unstable cart , stand , shelf or table .Serious injury to an individual , and damage to the television, may result if it should fall.
-
Page 7: Control Location
CONTROL LOCATION 1. Main Switch 2. Remote Sensor £¦Power Indicator 3. Program Down /Up Button 4. Volume Down/Up Button 5. Menu Button 6. AV/TV 7. Speakers 8. Side AV in (Option) 9. AC Power Cord 10. Audio/Video - In/Out 11. Antenna Input Socket (75 ohm) DTM2 DTM2 DTM5... -
Page 8: Input And Output
INPUT AND OUTPUT TERMINALS VIDEO AND AUDIO INPUT/OUTPUT TERMINALS 1. Video / Audio input for playback for VCR. 2. Video / Audio output for TV program. *Please keep AC cord unplugged when connecting TV system. AV OUT AV IN 2 VIDEO AUDIO LEFT... -
Page 9: Operation Instructions
OPERATION INSTRUCTIONS Turn the TV set on at the main switch, the power indicator will light up. In Standby " " Mode to turn the TV on, p ress the program up or down button on the TV set, or press the On/Off button on the Remote Control. The picture will appear after a few seconds . -
Page 10: Operation Instructions
OPERATION INSTRUCTIONS System menu 1. COL.SYS SYSTEM You can change present color system in this item. COL.SYS AUTO 2. SIF.SYS SIF.SYS 6.0M You can change present sound system in this item. Time menu 1. CLOCK You can adjust the current time by this item. Press the VOL+button to set TIME _ _:_ _:_ _ CLOCK... -
Page 11: Location Of Control(Remote Control Unit)
LOCATION OF CONTROL (REMOTE HANDSET UNIT) STAND BY BUTTON ( Press this button to turn the TV on/off. Press any Number Button or Program Up/Down Button, picture and sound will come on within a few seconds. MUTE BUTTON ( Press once to mute the sound, press again to return to previously set sound level. - Page 12 LOCATION OF CONTROL (REMOTE HANDSET UNIT) VOLUME UP/DOWN BUTTONS (VOL+/-) Press Volume Up/Down Buttons to adjust sound level. PERSONAL PRESETS BUTTON (P.P.) You can select DYNAMIC, MILD, COLORFUL, STANDARD and CUSTOM by pressing this button. RECALL BUTTON ( Press this button sequentially to recall the program number, colour system and sound system on the screen.
-
Page 13: Battery Installation
BATTERY INSTALLATION (REMOTE CONTROL UNIT) 1. Remove the battery cover. 2. Insert the 2 UM4-AAA 1.5V batteries making sure the polarity (+ or -) of the batteries matches the polarity marks inside the unit. 3. Replace the battery cover. Replace with new batteries when the TV set begins to show the following symptoms: Operation is unsteady or erratic. -
Page 14: Service Tips
SERVICE TIPS BEFORE CALLING FOR SERVICE, HAVE YOU CHECKED ( ) THE FOLLOWING CHART ON SYMPTOMS AND SOLUTIONS? Symptoms No picture, no sound Poor sound, picture OK Poor picture, sound OK Weak picture Blurred picture Double image Lines in picture Distorted picture Weak reception on some channels Horizontal bars...
