Line Filter - Telefunken TK2129ST Service Manual

Item No.
46-10962W-02X PIN BASE *2 TJC2-2A
46-35184W-03X PIN BASE *3 TJC1-3A
66-20516X-0B0 FUSE HOLDER
66-343730-0B0 HOLLOW RIVET 1.6X3.0XL3.2
67-339070-1E7 SPRING CLIP
67-H28649-3A0 HEAT SINK
11-SK2645-0AX TRANSISTOR 2SK2645-01MR (POWER
11-2SD882-0AX TRANSISTOR 2SD882-P (NPN)
26-APK102-ME4 CAP. CER 1000PF 400VAC+/-20% E
26-APK102-ME4 CAP. CER 1000PF 400VAC+/-20% E
10-0FR104-FBX DIODE FR104 (FAST RECTIFIER)
10-0FR104-FBX DIODE FR104 (FAST RECTIFIER)
10-0FR104-FBX DIODE FR104 (FAST RECTIFIER)
36-LIF010-AX0

LINE FILTER

36-TRF020-AX2 TRANSFORMER CONV. BCK-4001-34d
18-KE0105-JN3 RES. H.VOLT. CC 1M OHM 1/2W +/-5%
18-KE0105-JN3 RES. H.VOLT. CC 1M OHM 1/2W +/-5%
27-AQT224-MVH CAP. M.PP 0.22 UF 250VAC 20%
25-BDA471-M1X CAP. ELEC 470 UF 25V +/-20%
25-BDA471-M1X CAP. ELEC 470 UF 25V +/-20%
25-BFB470-M1X CAP. ELEC 47 UF 50V +/-20%
35-139730-00X FERR. BEAD BF60
50-02000D-1VS7 FUSE 250V/2A
22-NTC479-XX0 NTC 4.7 OHM +/-18% NTC4.7D2-14
66-343730-0B0 HOLLOW RIVET 1.6X3.0XL3.2
66-343730-0B0 HOLLOW RIVET 1.6X3.0XL3.2
66-343730-0B0 HOLLOW RIVET 1.6X3.0XL3.2
66-343730-0B0 HOLLOW RIVET 1.6X3.0XL3.2
25-BFB470-M1X CAP. ELEC 47 UF 50V +/-20%
26-AMK221-JZX CAP. CER 220pF 2KV +/-5% SL
26-AMK331-JZX CAP. CER 330 pF 2KV +/-5% SL
26-AMK561-JZX CAP. CER 560 pF 2KVDC +/-5% SL
66-382330-0B7 RIVET 2.0X3.7X3.5
22-PTC200-XX0 POSISTOR 20 OHM (25-34)
08-D276SX-RCN ASS'Y - REAR CABINET
54-114000-00X FELT TAPE (150mmX19mmX0.3mm)
55-D189RC-1CN REAR CABINET
58-D106SI-3UI INLAY SIDE AV
58-D192RI-8UI INLAY REAR AV
58-D276MP-JKT PLATE MODEL NO.
59-130460-00X RUBBER PAD (25mmX7mm)
Description Quantity Req. Designator
1 P801 FOR DEGAUSSING COIL
1 P802 FOR POWER CORD
2 FOR F801
2 FOR C827
1 FOR Q801
1 FOR Q801
1 Q801
1 Q805
1 C835
1 C835A
1 D831
1 D830
1 D806
1 T801
1 T802
1 R807
1 R802
1 C802
1 C842
1 FOR Q805(C) & GND
1 C816
1 FOR Q801 "S"
1 F801
1 R801B
3 FOR RT801
6 FOR T802
2 FOR D824
2 FOR L804
1 C847A [(+) TO C846A]
1 C839
1 C830
1 C819
2 FOR P801
1 RT801
1
7 STICK ON REAR CAB.
1
1
1
1
2 STICK ON R. CAB.(FOOTING)
13
Remarks
