Telefunken TK2129ST Service Manual page 11

Item No.
25-BFB479-M1X CAP. ELEC 4.7 UF 50V +/-20%
25-BFB479-M1X CAP. ELEC 4.7 UF 50V +/-20%
25-BFB479-M1X CAP. ELEC 4.7 UF 50V +/-20%
08-0D276X-PWY ASS'Y - POWER PARTS
10-0001H8-FBX DIODE 1H8 (FAST RECOVERY)
10-00RU3C-F0X DIODE RU3C (FAST RECTIFIER)
10-0RL255-EBX DIODE RL255 (POWER RECTIFIER)
10-0RL255-EBX DIODE RL255 (POWER RECTIFIER)
10-0RL255-EBX DIODE RL255 (POWER RECTIFIER)
10-0RL255-EBX DIODE RL255 (POWER RECTIFIER)
10-1N4148-ABX DIODE 1N4148 (SWITCHING)
10-1N4148-ABX DIODE 1N4148 (SWITCHING)
10-1N4148-ABX DIODE 1N4148 (SWITCHING)
10-79C8V2-DBX DIODE ZENER 8V2 1/2W 5%
11-SC1815-YBX TRANSISTOR 2SC1815Y
13-TDA168-46P IC TDA16846 (SMPS)
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5%
18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5%
18-CB0182-JNX RES. C.F. 1.8K OHM 1/6W +/-5%
18-CB0222-JNX RES. C.F. 2.2k OHM 1/6W +/-5%
18-CB0470-JNX RES. C.F. 47 OHM 1/6W +/-5%
18-CB0472-JNX RES. C.F. 4.7k OHM 1/6W +/-5%
18-CB0563-JNX RES. C.F. 56K OHM 1/6W +/-5%
18-CB0563-JNX RES. C.F. 56K OHM 1/6W +/-5%
18-CB0752-JNX RES. C.F. 7.5K OHM 1/6W +/-5%
18-CB0823-JNX RES. C.F. 82K OHM 1/6W +/-5%
18-CD0101-JNX RES. C.F. 100 OHM 1/4W +/-5%
18-CD0153-JNX RES. C.F. 15K OHM 1/4W +/-5%
18-CD0470-JNX RES. C.F. 47 OHM 1/4W +/-5%
18-CE0102-JNX RES. C.F. 1k OHM 1/2W +/-5%
18-EF0228-JGX RES. FUS. 0.22 0HM 1W +/-5%
18-EF0228-JGX RES. FUS. 0.22 0HM 1W +/-5%
18-FE0120-JNX RES. M.0. 12 OHM 1/2W +/-5%
18-FG0121-JHX RES. M.O. 120 OHM 2W +/-5%
18-FG0153-JHX RES. M.O. 15k OHM 2W +/-5%
18-FG0563-JHX RES. M.O. 56K OHM 2W +/-5%
18-KE0475-JNX RES. H. VOLT. CC 4.7M OHM 1/2W
18-KE0475-JNX RES. H. VOLT. CC 4.7M OHM 1/2W
18-KE0475-JNX RES. H. VOLT. CC 4.7M OHM 1/2W
20-TR502H-5CX TRIMMER B5K HORIZ TYPE
25-315130-M1X CAP. ELEC 330UF 400V +/-20%
Description Quantity Req. Designator
1 C704
1 C713
1 C714
1
1 D810
1 D824
1 D801
1 D802
1 D803
1 D804
1 D832
1 D807
1 D805
1 D833
1 Q806
1 IC801
1 R829
1 R828
1 R804
1 R827
1 R826A
1 R826
1 R812
1 R806
1 R810
1 R803
1 R808
1 R811
1 R808A
1 R808B
1 R831
1 R832
1 R825
1 R854A
1 R824
1 R809
1 R805
1 R835
1 R835A
1 VR801
1 C809
11
Remarks
