Telefunken TK2129ST Service Manual page 14

Item No.
62-314340-0UN FBT SUPPORTER HIPS-KINGFA 113 (VO)
62-378080-1UN TRACK
62-389620-0UD POWER LINE BLOCK
63-B40200-AB3 S/T SCREW B 4 X 20 AB
63-F30100-BT3 S/T SCREW F 3 X 10 BT (BLACK)
63-W30100-AB4 S/T SCREW W 3 X 10 AB
63-W30100-AB4 S/T SCREW W 3 X 10 AB
63-W35120-AB4 S/T SCREW W 3.5 X 12 AB
08-0D276X-AVY ASS'Y - SIDE AV BD
46-30790H-06X HS 6P24 400 TJC3-6Y/SCN-6Y
47-RCA002-XX0 RCA SOCKET AV-8.4-6 (WHITE)
47-RCA003-XX0 RCA SOCKET AV-8.4-6 (YELLOW)
47-RCA017-XX0 RCA JACK RED (RCA-101P) (THREE FEET)
63-W30080-AB4 S/T SCREW W 3 X 8 AB
40-2513MT-SIE P.C.B. SIDE AV
41-WJ0060-B00 WIRE BARE JUMPER 6mm
41-WJ0060-B00 WIRE BARE JUMPER 6mm
08-D276SX-FCN ASS'Y - FRONT CABINET
02-GND021-XX0 ASS"Y - CRT GND WIRE&HOUSE
36-DEG210-BX3 DEGAUSSING COIL 2500mm
44-21OFLS-SG2A CRT A51JSY63X13(CR)ORG (AFSA)
42-51208D-XX1 SPEAKER 8 OHM 5W (52MMX120MM)
42-51208D-XX1 SPEAKER 8 OHM 5W (52MMX120MM)
46-27250H-02X HS 2P24 450/5 F/W TJC3-02H
46-27688H-04X HS 4P A/B 400/13 RBGW TJC1/4Y
46-37144H-02X HS 2P 2468#22 450mm S11-2Y/7mm
54-113970-0U0 PVC TUBE #5 L=ROLL
54-205140-000 SPACER CRT MOUNTING T=2MM
54-314740-0X0 CRT FIBRE SHEET (22mmX22mmX0.8mm)
55-D276FC-0CN FRONT CABINET
56-C276FB-0HA PUSH BUTTON
56-C276LS-0HC LENS
56-D276PK-0HA POWER KNOB
59-130460-00X RUBBER PAD (25mmX7mm)
62-10654X-00F UNI-TIE (2.5mmX95mm)
62-377180-0HA CONECTOR
62-345690-1UN ASSISTANT RAIL HIPS-KINGFA 113 (VO)
63-B30080-AB4 S/T SCREW B 3 X 8 AB
63-H60300-AB4 S/T SCREW H 6 X 30 AB
63-S30100-AB4 S/T SCREW S 3 X 10 AB
63-W30100-AB4 S/T SCREW W 3 X 10 AB
Description Quantity Req. Designator
1
1 FOR M.BD TRACK(R.CAB.)
1
6 MTG FRONT & REAR CAB.
2 MTG RCA JACK & REAR CAB.
2 MTG SIDE AV BD & R. CAB.
2 MTG SUPPORTER & REAR CABINET
2 MTG M.BD TRACK & REAR CABINET
1
1 P003C TO M.BD P904
1 P941L
1 P941V
1 P941R
2 MTG SIDE AV BD & F.CAB
1
1 J980
1 J981
1
1
1
1
1 W601
1 W602
1 P602H FOR M. BD P602
1 P401H FOR D.Y COIL
1 P601H FOR M. BD P601
0.32 FOR SPK WIRE
4 MTG CRT & F.CAB
4 MTG CRT & F.CAB
1
1
1
1
2 FOR FRONT CAB.(FOOTING)
10
1
1 FOR M.BD TRACK(F.CAB.)
3 MTG KEY BD & PUSH BUTTON
4 MTG CRT & FRONT CAB.
1 MTG RECEIVER BD & F. CAB.
2 MTG M.BD TRACK & F. CAB.
14
Remarks
