Telefunken TK2129ST Service Manual page 28

Item No.
26-EBP151-JCX CAP. CER 150 pF 50VDC +/-5%
26-EBP151-JCX CAP. CER 150 pF 50VDC +/-5%
40-2111SW-RMA P.C.B. REMOTE HANDSET BD
41-WJ0060-B00 WIRE BARE JUMPER 6mm
41-WJ0100-B00 WIRE BARE JUMPER 10MM
45-COS455-KY0 CERAMIC RESONATOR 455KHZ
49-HS45E0-00X RUBBER PAD KEYS
54-302000-00X FELT TAPE 15 X 4 CM
55-HS45EB-0HA LOWER CASE - REMOTE HANDSET
55-HS45ED-0HA DOOR BATT. - REMOTE HANDSET
55-HS45ET-1HA CASE UPPER - REMOTE HANDSET
56-HS45EK-1HAAA KEY KNOB (OVAL) LEFT
56-HS45EK-1HAAB KEY KNOB (OVAL) RIGHT
56-HS45EK-2HAAA KEY KNOB (OVAL) UPPER
56-HS45EK-2HAAB KEY KNOB (OVAL) LOWER
58-HS45E2-8UI INLAY REMOTE HANDSET
74-009022-60C POLYBAG HANDSET (9CMX22CM)
25-HBB470-M1X CAP. ELEC 47UF 10V +/-20%
67-X26968-0E2 BATT. TERMINAL (+/-)
67-X29681-1E2 BATTERY CONTACT SPRING (-)
67-X29682-0E2 BATTERY CONTACT SPRING (+)
08-D276SX-FBY ASS'Y - FRONT CTL BD
48-TAC001-XX0 TACT SWITCH
48-TAC001-XX0 TACT SWITCH
48-TAC001-XX0 TACT SWITCH
48-TAC001-XX0 TACT SWITCH
48-TAC001-XX0 TACT SWITCH
48-TAC001-XX0 TACT SWITCH
18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5%
18-CB0622-JNX RES. C.F. 6.2k OHM 1/6W +/-5%
18-CB0432-JNX RES. C.F. 4.3K OHM 1/6W +/-5%
18-CB0272-JNX RES. C.F. 2.7k OHM 1/6W +/-5%
18-CB0182-JNX RES. C.F. 1.8K OHM 1/6W +/-5%
46-35002H-03X HS 3P24 820 TJC3-3Y/JC25-3Y
08-0D276X-IRY ASS'Y - IR BD
11-IRR001-3X0 IR RECEIVER MODULE HK381A
62-346080-0HA LED HOLDER
46-30966H-04X HS 2468 #24 160 TJC3-4Y/SCN-4Y
18-CB0470-JNX RES. C.F. 47 OHM 1/6W +/-5%
41-WJ0060-B00 WIRE BARE JUMPER 6mm
41-WJ0060-B00 WIRE BARE JUMPER 6mm
Description Quantity Req. Designator
1 C1501
1 C1502
1
1 J1501
1 J1502
1 X1501
1
1
1
1
1
1
1
1
1
1
1
1 C1503
1
1
1
1
1 S1201
1 S1202
1 S1203
1 S1204
1 S1205
1 S1206
1 R1205
1 R1204
1 R1203
1 R1202
1 R1201
1 P1201 TO MAIN BD. P005
1
1 IR001
1
1 P005
1 R026
1 J011
1 J012
28
Remarks
