ETC Source Four jr Zoom Assembly Manual page 8

Lens holder assembly
Reference
number
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
8
Part Description
number
7062A3005 Lens holder, 26°
7062A3017 Lens holder, 36°
7062A3018 Lens holder, 50°
7062A3019 Lens holder, Zoom, forward
7062A3020 Lens holder, Zoom, back
7062A4001 Lens, 26°, "black dot"
7062A4002 Lens, 36°, "white dot"
7062A4003 Lens, 50°, "yellow dot"
7062A4008 Lens, Zoom, forward
7062A4009 Lens, Zoom, back, black
7062A3027 Lens cover, Zoom, front, 25º-50º
7062A3026 Lens cover, Zoom, rear, 25º-50º
(mounted on rear side of lens holder)
7062A3029 Plate, secondary aperature
HW124 Scre 4-40 x 1/4 SPHMS, black Oxide
HW196 Nut 4-40 Keps
HW1127 Spacer
7060A4010 Bushing gate
fixed lens
rear lens
front lens
HW8209 Tinnerman clip
HW4117 Nylon washer, flat, #10
HW779 Spring, compression
HW8201 Lens knob, 10-32 x .50 LG male stud, black
Zoom
Fixed field angle
7062A2001 Lens holder assembly, 26° (black)
7062A2003 Lens holder assembly, 36° (white)
7062A2004 Lens holder assembly, 50° (yellow)
7062A2005 Lens holder assembly, Zoom, forward
7062A2006 Lens holder assembly, Zoom, back
Quantity
required
1
1
1
1
1
1
1
1
1
1
1
1
1
2
4
2
4
4
4
3
1 or 2
1 or 2
2
1
1
1
1
1
1
