ETC Source Four jr Zoom Assembly Manual page 4

24
1
13
4
Lamp socket assembly
Reference
number
1
2
3
4
5
6
7
8
9-11
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
4
23
14
5
18
17
3
16
15
Part Description
number
7060A3055 Housing, socket, casting, painted
7060A3057 Socket, light baffle casting, painted
7060A4007 Knob, X-Y, lamp set
7060A4008-02 Knob, Z, lamp set w/female insert
7060A4011 Bushing, cup
7060A3011 Hub, index, casting
7060A3012 Spring, lamp retainer
HW748 Spring, compression
M718 Complete TP22 450 degree-C CLCM assembly
W330-03 TP22 CLCM assembly, mica
W330-04 TP22 CLCM 16-gauge, 1/4" semi-striped, Ni-gold contacts,
600V, 450˚C
W330-02 TP22 CLCM assembly, ceramic
HW534 Nut, hex, 1/4-20, black zinc
7060A3025 Screw, 1/4-20 knurled head
HW746 Retaining ring, flat, Southco
HW5123 Nut, hex, 9/16-18, black zinc
HW747 Washer, wave
7060A3056 Clamp, strain relief, painted
HW3103 Screw, 8-32 x 5/8 PhFHMS, black zinc
HW5122 Bolt, 1/4-20 x 1.75, full thread, black zinc
HW2125 Screw, self tap, 6-32 x 1/4, black zinc
7060B7003 48" W420 wire, 16 gauge, 200° C/300V, green
UL 1180/CSA AWM with lug J490T installed
W689 36" sleeve, fiberglass
HW749 Spring, ground
7060B7007 4" W420 wire, 16 gauge, 200° C/300V, green,
UL 1180/CSA AWM with two J490T lugs installed
7060A3085 Lamp retainer wire
HW8203 Tinnerman clip
19
10
9
7
8
6
22
25
20
2
21
11
12
Quantity
required
1
1
1
1
1
1
1
1
1
(1)
(2)
(1)
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
Electronic Theatre Controls, Inc.
26
