ETC Source Four jr Zoom Assembly Manual page 14

4
5
8
15
19
Final assembly
Reference
number
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
14
20
9
17
18
1
23
24
4
9
Part Description
number
7062A3002 Barrel, left casting
7062A3004 Barrel, right casting
7062A2008 Lamp burner assembly
HW8201 Knob, 10-32X.50LG male stud, black
7061A3005 Retainer, gel clip
7062A4010 Reflector, jr, glass
7062A3007 Spring, round
HW750 Spring, gel retainer
See page 8 Lens holder assembly
7062A3009 Yoke, jr
HW8144 Handle, yoke knob, 3092, 5/16-18, female
HW5193 Bolt, hex 5/16-18 x 1.0" black oxide (yoke)
HW5125 Bolt, carriage 5/16-18
HW5126 Washer, flat, 5/16, black oxide (yoke)
HW391 Screw, PHMS, 8-32 X 3/4 LG.
See page 10 Shutter assembly
7062A3013 Spring, reflector support
HW8200 Retainer, push on
7062A3014 Light baffle strip
7062A3015 Cover, iris slot
HW372 Screw, PhPHMS, 8-32 X 1/4 black oxide
HW369 Screw, PhPHMS, 8-32 X 5/8 black oxide
HW4117 Nylon, washer flat, #10
HW779 Spring compression
21
12
13
7
6
16
22
10
14
11
3
2
Quantity
required
1
1
1
1 or 2
1
1
1
1
1 or 2
1
1
2
1
3
1
1
2
2
1
1
2
6
1 or 2
1 or 2
Electronic Theatre Controls, Inc.
