ETC Source Four jr Zoom Assembly Manual page 12

Shutter assembly
Reference
number
1
2
3
4
5
6
12
3
Part Description
number
7062A2002 Shutter blade assembly
7062A3016 Plate, divider
7062A3010 Plate, gate (middle)
7062A3030 Plate, divider with dimples
7062A3031 Plate, support, spring (see figure 12)
HW754 Spring, shutter (see figure 12)
1
2
4
Quantity
required
4
1
1
1
1
4
Electronic Theatre Controls, Inc.
