Redundant Power Supply Sequencer Module (RPSSM)
Specifications
Redundant Power Supply Sequencer Module
Power Supplies (1 or 2 on the RPSSM)
Field Supply Power
P-10
Input Range:
Temperature Range:
Relative Humidity:
Vibration:
RFI Susceptibility
Watchdog MOSFET
Input Range
Output Voltage
Output Current
Efficiency
Fusing
VINF Input Range
Fusing
Installation and Use
22.2 to 30V DC (24V input supply, nominal)
Shutdown occurs at 22.2 nominal for 24V
input supply systems, respectively.
Operating: -40 to 85 o C
Storage: -40 to 85 o C
15 to 95% non-condensing
1G for 10-150 Hz
0.5 G for 150 Hz to 2000 Hz
3V/m 80 MHz to 1000 MHz per EN50082-2
1A
20 to 30Vdc (24V input supply, nominal)
5V ± 2%, 3.3V ± 2%
1A @ 3.3V, 2A @5V
80% at full load
7x2 mm fuse 3A fast acting
20V to 30V
5x20 mm fuse 10A slow blow
Revised Nov-2010
