5.3.4

Reset Switch

Caution

5.4 WINDIAG Diagnostic Utility

Revised Nov-2010
Table 5-4. Port 80 Run Time Status Codes
HEX Definition
Code
00 No Application
01 Application Loaded
10 Application Loaded - BPTs Set
11 Application Running
12 Running with BPT
1D Currently Loading the Boot Project
51 System Initialization in Progress
86 Recovery Mode
BA Standby (redundant systems only)
BC Standby (redundant systems only)
BD Standby (redundant systems only)
BF Battery Fail
CA Hot Card Replacement in Progress
CF Invalid Checksum Detected
D0 Diagnostic Mode
D1 Running Diagnostic
DE User Application has failed to start
F0 NPX Error
F1 Waiting for Power-down
FA CPU Bd. Switch SW1-3 Set OFF
Ignore Soft Switch Configuration - Use
factory defaults
FC Waiting for Alt. Watchdog Timer
FD Waiting for Updump
FE FLASH Programming Error
FF Unit Crashed
The reset switch (SW4) is a momentary button that lets you reset (stop
and restart) the ControlWave while you test the unit using WINDIAG
diagnostic software.
Never use the reset switch during normal operation.
WINDIAG is a software-based diagnostic tool you use to test the
performance of I/O modules, CPU memory, communication ports, and
other system components. .
Service & Troubleshooting
ControlWave Instruction Manual (CI-ControlWave)
Notes
Break Point(s) Set
Display Blank
Break Point in Debug
SW3-3 = ON; during
normal runtime operation
you should set SW3-3 to
OFF.
Valid Standby
(can take over)
Connected to Master
Not Connected to
Master
Check S3-4
Unit Stopped
SW1-8 =OFF
Invalid I/O Card
configuration
Unit Stopped
After NMI
Flashes for 1 second
At startup
Unit Stopped
Core Dump in process or
waiting to start
Unit Stopped
5-25
