ControlWave Instruction Manual (CI-ControlWave)

Module /

Board
SCB CR4 – ENET Port 2
SCB CR4 – ENET Port 2
SCB CR4 – ENET Port 2
SCB CR4 – ENET Port 2
SCB CR5 – ENET Port 3
SCB CR5 – ENET Port 3
SCB CR5 – ENET Port 3
SCB CR5 – ENET Port 3
CPU

PORT 80 DISPLAY

AI AI Board Status
AI Range (16 LEDs – one per
point)
AI Range (16 LEDs – one per
point)
AO AO Board status fail
AO AO Board status pass
DI DI Board status
DI DI board inputs (32 LEDs – 1
per point)
DO DO Board status
DO DO board outputs (32 LEDs –
1 per point)
UDI UDI Board Status Fail
UDI UDI Board Status Pass
UDI UDI Input (12 LEDs – 1 per
5-14
LED Name LED Color
Red/Green ON RED = Data Collision (Left – see Figure 5-
11.)
Red/Green ON GREEN = Receiving data (Left – see
Figure 5-11.)
Red/Green ON RED = Transmitting data (Right – see
Figure 5-11.)
Red/Green ON GREEN = Link O.K. (Right – see Figure 5-
11.)
Red/Green ON RED = Data Collision (Left – see Figure 5-
11.)
Red/Green ON GREEN = Receiving data (Left – see
Figure 5-11.)
Red/Green ON RED = Transmitting data (Right – see
Figure 5-11.)
Red/Green ON GREEN = Link O.K. (Right – see Figure 5-
11.)
Red LEDs LED Matrix displays status codes. See Figure
5-11. See Table 5-3 & 5-4.
Red/Green ON RED = Fail state/ board not recognized
ON GREEN = Normal state. See Figure 5-12
Red LED ON = AI over-range or AI under-range
condition. See Figure 5-12
Green LED ON = AI in range. See Figure 5-12
Red LED ON = AO board fail state / board not
recognized. See Figure 5-13.
Green LED ON = AO board normal or O.K. state.
Figure 5-13.
Red/Green ON RED = DI board fail state; board not
recognized.
ON GREEN = DI board normal state. See
Figure 5-14.
Red LED ON = Input is present.
LED OFF = Input is not present. See Figure 5-
14.
Red/Green ON RED = DO board fail state; board not
recognized.
ON GREEN = DO board normal state. See
Figure 5-15.
Red LED ON = Output is ON. See Figure 5-15.
Red LED ON = UDI board fail state/board not
recognized. See Figure 5-16.
Green LED ON = UDI board normal or O.K. state.
See Figure 5-16.
Red LED ON = UDI input activity.
Service & Troubleshooting
Function and Location
Revised Nov-2010
