USB-2404-60 User's Guide
Installing the software
Refer to the Quick Start Guide for instructions on installing the software on the Measurement Computing Data
Acquisition Software CD. This booklet is available in PDF at
Quick-Start.pdf.
Installing the hardware
Install the MCC DAQ software before you install your board
The driver needed to run your board is installed with the MCC DAQ software. Therefore, you need to install the
MCC DAQ software before you install your board. Refer to the Quick Start Guide for instructions on installing
the software.
Be sure you are using the latest system software
Before you install your USB-2404-60, run Windows Update to update your operating system with the latest
USB drivers.
To connect the USB-2404-60 to your system, turn your computer on, and connect the USB cable to a USB port
on your computer or to an external USB hub that is connected to your computer. The USB cable provides power
and communication to the USB-2404-60.
When you connect the USB-2404-60 for the first time, a series of
(Windows XP) or dialogs (other Windows versions) open as the USB-2404-60 is detected by your computer.
When the last balloon or dialog closes, the installation is complete. The LED on the USB-2404-60 blinks
steadily to indicate that the device is initialized and receiving power.
Caution! Do not disconnect any device from the USB bus while the computer is communicating with the
USB-2404-60, or you may lose data and/or your ability to communicate with the device.
Allow the USB-2404-60 to operate for at least 30 minutes before using the device. This warm up time is
required to achieve the specified rated accuracy of measurements.
Calibrating the USB-2404-60
The USB-2404-60 is shipped fully calibrated. Calibration coefficients are stored in EEPROM. Return the device
to Measurement Computing Corporation when calibration is required. The normal calibration interval is once
per year.
www.mccdaq.com/PDFmanuals/DAQ-Software-
Found New Hardware
9
Installing the USB-2404-60
popup balloons
