SDBC-DK3 UG
3. System Introduction: IA MSC-DBSB8 ICD Connector
Figure 3. Debug Connector (Emulator and Programmer Interface)
6
Table 1. Debug Connector
Pin #
Description
1
VDD (3.3 V)
2
GND
3
GND
4
P2.7
5
RESET
6
P2.7
7
RST/C2CK
8
—
9
GND
10
—
Rev. 0.3
