- Page 1 ShockWave 26 ® 26 - INCH BRUSHLESS RTR DEEP–V BOAT PRB08014 Owners Manual • Bedienungsanleitung Manuel de l'utilisateur • Manuale dell'utente Batteries and charger sold separately...
-
Page 2: Table Of Contents
NOTICE All instructions, warranties and other collateral documents are subject to change at the sole discretion of Horizon Hobby, LLC. For up-to-date product literature, visit http://www.horizonhobby.com and click on the support tab for this product. Meaning of Special Language The following terms are used throughout the product literature to indicate various levels of potential harm when operating this product: WARNING: Procedures, which if not properly followed, create the probability of property damage, collateral damage, and serious injury OR create a high probability of superficial injury. -
Page 3: Water-Resistant Boat With Waterproof Electronics
Water-Resistant Boat with Waterproof Electronics Your new Horizon Hobby boat has been designed and built with a combination of waterproof and water-resistant components to allow you to operate the product in calm, fresh water conditions. While the entire boat is highly water-resistant, it is not completely waterproof and your boat should NOT be treated like a submarine. -
Page 4: Box Contents
Box Contents ® ® • Pro Boat ShockWave 26-Inch Brushless Deep-V Boat A battery (sold separately) is required to ® • Spektrum STX2 2CH 2.4GHz FHSS Transmitter (SPMSTX200) ™ operate the boat. The ESC will operate ® with 2–3 Cell (7.4V–11.1V) Li-Po or 6–9 Cell • Spektrum STX2 2CH 2.4GHz FHSS Receiver (SPMSRX200) -
Page 5: Transmitter Controls
Transmitter Controls 1. Steering Wheel Controls direction (left/right) of the model 2. Throttle Trigger Controls speed and direction (forward/brake/ reverse) of the model 3. ON/OFF Switch Turns the power ON/OFF 4. Throttle Limiting Switch Adjusts the throttle limit from 50%, 75%, and 100% 5. -
Page 6: Installing The Battery Pack
Installing the Battery Pack 1. Loosen the 2 screws on the rear of the canopy. 3. Install the battery in the compartment. Secure it with the hook and loop straps. If running your boat in 2. Carefully lift the rear of the canopy and pull back to rougher water conditions, the use of Waterproof Hook disengage the 2 front pins from the hull. -
Page 7: Binding
Binding 5. Turn the Steering Wheel to Full Right. Power ON the transmitter while holding the Steering Wheel The STX2 ® transmitter and SPMSRX200 receiver are to the Right. bound at the factory. If you need to rebind, follow the 6. -
Page 8: Control Check
Control Check IMPORTANT: Perform a control check at the beginning of each boating session, after repair or after installation of new batteries. Ensure the receiver antenna is extended properly and all batteries are fully charged. 1. Power ON the transmitter and the boat. Do not install the boat canopy. -
Page 9: Boating Tips
Boating Tips If the propeller and rudder are blocked with debris or When running your boat for the first time, we vegetation, remove the boat from the water and remove recommend calm wind and water conditions so that you the debris before continuing operation. can learn how the boat responds to your control. -
Page 10: After Boating And Maintenance
After Boating and Maintenance • Drain water from inside the hull using the drain plug • Fully dry the inside and outside of the boat, including NOTICE: When you are finished boating, never leave the the water cooling lines and jacket around the motor boat in direct sunlight or in a hot, enclosed area such as • Remove the hatch before storing your boat a car. -
Page 11: Drivetrain Lubrication
Drivetrain Lubrication NOTICE: Running the boat in saltwater could cause some Always replace the drivetrain parts when they are parts to corrode. If you run the boat in saltwater, rinse it damaged or show visible wear or injury and damage thoroughly in freshwater after each use and lubricate the may result. -
Page 12: Esc Programming
ESC Programing 1. Pull and hold the Throttle Trigger to full throttle and 4. After selecting a programmable item, you will hear turn the ESC on. several tones in a loop indicating Programmable Values. Pull Throttle Trigger to full throttle to select 2. -
Page 13: Troubleshooting Guide
Troubleshooting Guide Problem Possible Cause Solution Boat will not respond to throttle but responds Throttle channel is reversed Reverse throttle channel on transmitter to other controls Damaged propeller, shaft or motor Replace damaged parts Extra noise or extra vibration Propeller is out of balance Balance or replace propeller Boat battery charge is low Completely recharge battery... -
Page 14: Limited Warranty
Limited Warranty your questions and service you in the event that you may need any assistance. For questions or assistance, please visit our website at www.horizonhobby.com, submit a Product Support What this Warranty Covers Inquiry, or call the toll free telephone number referenced in the Horizon Hobby, LLC, (Horizon) warrants to the original Warranty and Service Contact Information section to speak with purchaser that the product purchased (the “Product”) will be... -
Page 15: Warranty And Service Contact Information
Warranty and Service Contact Information Country of Horizon Hobby Contact Information Address Purchase Horizon Service Center servicecenter.horizonhobby. (Repairs and Repair Requests) com/RequestForm/ productsupport@ United States of 4105 Fieldstone Rd Horizon Product Support horizonhobby.com America Champaign, Illinois, 61822 USA (Product Technical Assistance) 877-504-0233 websales@horizonhobby.com Sales... -
Page 16: Replacement Parts
Replacement Parts / Ersatzteile / Pièces de rechange / Pezzi di ricambio Part # English Deutsch Français Italiano Hull and Decals: Shockwave 26 V3: Rumpf Scafo e adesivi: PRB281012 Coque avec décoration Shockwave 26 V3 u. Dekorbogen Shockwave 26 V3 Shockwave 26 V3: Canopy and Decals: Capottina e adesivi:... - Page 17 Notes ® ShockWave...
- Page 18 ©2017 Horizon Hobby, LLC. Pro Boat, the Pro Boat logo, ShockWave, Dynamite, Reaction, Prophet, EC3, EC5, STX2 and the Horizon Hobby logo are trademarks or registered trademarks of Horizon Hobby, LLC. The Spektrum trademark is used with permission of Bachmann Industries, Inc. PRB08014...
