- Page 1 BLACK JACK BLACK JACK ™ ™ 42 42 - - INCH BRUSHLESS 8S CATAMARAN INCH BRUSHLESS 8S CATAMARAN PRB08043 Instruction Manual • Bedienungsanleitung • Manuel de l’utilisateur • Manuale dell’utente...
-
Page 2: Safety Precautions And Warnings
NOTICE All instructions, warranties and other collateral documents are subject to change at the sole discretion of Horizon Hobby, LLC. For up-to-date product literature, visit horizonhobby.com or towerhobbies.com and click on the support or resources tab for this product. MEANING OF SPECIAL LANGUAGE The following terms are used throughout the product literature to indicate various levels of potential harm when operating this product: WARNING: Procedures, which if not properly followed, create the probability of property damage, collateral damage, and serious... -
Page 3: Table Of Contents
General Precautions Wet Conditions Maintenance • Read the WET CONDITIONS MAINTENANCE procedures • Drain any water that has collected in the hull by removing and make sure that you have all the tools you will need to the drain plug or canopy and tilting the boat in the properly maintain your boat. -
Page 4: Box Contents
Box Contents • Pro Boat ® Blackjack™ 42 inch Brushless RTR Catamaran • Spektrum DX3 SMART DSMR ® 3CH Transmitter (SPMR2340) • Spektrum SR6110AT 6CH AVC/Telemetry Receiver (SPMSR6110AT) • Spektrum Firma™ 160A SMART Brushless Marine ESC (SPMXSE1160M) • Spektrum 18kg WP 1/5th Scale Servo (SPSM603) •... -
Page 5: Antenna Tube Installation
Antenna Tube Installation Install the receiver antenna in the tube as shown. Do not bend the end of antenna over the antenna tube and place the cap over it or damage may result. The antenna does not have to be outside of the tube to operate properly. Keep the end of the antenna above the boat’s waterline to get the best transmitter reception. -
Page 6: Low Voltage Cutoff (Lvc)
Low Voltage Cutoff (LVC) The factory default setting for the LVC in the ESC included with The average run time—using the recommended batteries your boat is set at 3.2V per cell. Discharging a Li-Po battery (SPMX50004S100H5)—is between 7–10 minutes at non-stop, below 3V per cell may damage your battery. -
Page 7: Testing Your Boat In The Water
Testing Your Boat in the Water 1. Carefully place the boat in the water. 2. If the boat does not go straight, adjust the ST Trim dial on the transmitter. 3. Return the boat to shore when it begins to slow or when LVC activates. -
Page 8: After Boating And Maintenance
After Boating and Maintenance • After each use, remove the drain plug and hold the boat NOTICE: When you are finished boating, never leave the upright to drain all water from inside the hull. boat in direct sunlight or in a hot, enclosed area such as a car. -
Page 9: Esc And Transmitter Calibration
If using a SMART ESC and SMART battery, the transmitter SMART Battery Level indicator will show the vehicle battery level within 10 seconds of powering on and binding. Bind Power Using An AVC ® (Active Vehicle Control) Receiver With the DX3 Transmitter If using an AVC receiver, such as the SR6100AT, follow bind and calibration instructions as indicated in the receiver manual. -
Page 10: Motor Care
Motor Care • Prolong motor life by preventing overheating conditions. • Lubrication is important to prevent motor damage. If your Undue motor wear results from frequent turns, stops motor gets wet, lubricate the busings supporting the motor and starts, pushing objects, boating in rough water or shaft with light duty machine oil. -
Page 11: Prop Angle Adjustment
Prop Angle Adjustment Raising the prop strut increases speed, but also decreases steering response and increases cavitation. Lowering the drive strut increases steering response, but also increases steering sensitivity and decreases speed. 1. Loosen 2 bolts and 2 nuts from the drive strut on the rear of the boat. -
Page 12: Troubleshooting Guide
Troubleshooting Guide Problem Possible Cause Solution Boat will not respond to throttle but responds to other Throttle channel is reversed Reverse throttle channel on transmitter controls Damaged propeller, shaft or motor Replace damaged parts Extra noise or extra vibration Propeller is out of balance Balance or replace propeller Boat battery charge is low Completely recharge battery... -
Page 13: Limited Warranty
Limited Warranty What this Warranty Covers—Horizon Hobby, LLC, (Horizon) questions or assistance, please visit our website at www.hori- warrants to the original purchaser that the product purchased (the zonhobby.com, submit a Product Support Inquiry, or call the toll “Product”) will be free from defects in materials and workman- free telephone number referenced in the Warranty and Service ship for a period of 2 years from the date of purchase. -
Page 14: Warranty And Service Contact Information
Warranty and Service Contact Information* Country of Horizon Hobby Contact Information Address Purchase Horizon Service Center servicecenter.horizonhobby.com/RequestForm/ (Repairs and Repair Requests) productsupport@horizonhobby.com Horizon Product Support United 2904 Research Rd. (Product Technical Assistance) States of Champaign, Illinois, 877-504-0233 America 61822 USA websales@horizonhobby.com Sales 800-338-4639... -
Page 15: Compliance Information For The European Union
Compliance Information for the European Union EU Manufacturer of Record: EU Compliance Statement: Horizon Hobby, LLC Hereby, Horizon Hobby, LLC declares that the 2904 Research Road device is in compliance with the following: EU RED Champaign, IL 61822 USA 2014/53/EU; RoHS 2 Directive 2011/65/EU; RoHS 3 EU Importer of Record: Directive - Amending 2011/65/EU Annex II 2015/863. -
Page 16: Replacement Parts
Replacement Parts / Ersatzteile / Pièces de rechange / Pezzi di ricambio Part # English Deutsch Français Italiano PRB281116 Canopy Kabinendach Verrière Capottina PRB281117 Hull with Inserts Rumpf mit Einsätzen Coque avec inserts Scafo con inserti Pro Boat Waterproof Pro Boat wasserdichte Boîtier de récepteur étanche Scatola ricevitore a prova PRB281118... - Page 17 60364.1 Upated: 02/2021 ©2021 Horizon Hobby LLC. Pro Boat, the Pro Boat logo, Blackjack, Firma, DX3, DSMR, IC5, and the Horizon Hobby logo are trademarks or registered trademarks of Horizon Hobby, LLC. The Spektrum trademark is used with permission of Bachmann Industries, Inc.
