Summary of Contents for BLAUBERG Kamin 125
- Page 1 CHIMNEY CENTRIFUGAL FAN KAMIN OPERATION MANUAL...
-
Page 2: Table Of Contents
Kamin www.blaubergventilatoren.de CONTENT Introduction General Safety rules Storage and transportation rules Manufacturer's warranty Fan design Delivery set Modifi cations and options Technical data Operating logic Mounting and operation guidelines Mounting sequence Installation and connection to power mains Maintenance Warranty card... -
Page 3: Introduction
+5°C up to +40°C. Store the fan in an environment with minimized risk of mechanical damages, The centrifugal chimney fan BLAUBERG Kamin is not a ready for use product. temperature and humidity fl uctuations. Store the fan inside a room or under It is a component unit designed for integration into hot air distribution. -
Page 4: Fan Design
Kamin www.blaubergventilatoren.de FAN DESIGN DELIVERY SET fan - 1 item; intake operation manual. spigot exhaust spigot casing impeller temperature controller Fig. 1 MODIFICATIONS AND OPTIONS fi lter intake spigot element AF (special accessory, not included into delivery set). AF is a special removable fi lter-box for transported air purifi cation, Filter class G3. -
Page 5: Technical Data
Kamin www.blaubergventilatoren.de TECHNICAL DATA Table 1. Technical data Parameters Kamin 125 Kamin 140 Kamin 150 Kamin 160 Voltage, 50 Hz [V] 1~230 1~230 1~230 1~230 Power [W] Current [A] 0.81 0.82 0.84 0.86 Max. air fl ow [m RPM [min... - Page 6 Kamin www.blaubergventilatoren.de Table 2. Overall dimensions Dimensions [mm] Weight Type [kg] Kamin 125 Kamin 140 Kamin 150 Kamin 160 Kamin-ER 125 Kamin-ER 140 Kamin-ER 150 Kamin-ER 150 max Kamin-ER 160 Fig. 6 Dimensions [mm] Extra Weight Type option [kg] Kamin 125...
-
Page 7: Operating Logic
Kamin www.blaubergventilatoren.de OPERATING LOGIC Designation Description Max. transported air temperature Temperature controller with the set temperature point Fig 9 Kamin fan operation Fan runs The fan starts when air temperature in the fi replace hood reaches the set point and distributes warm air from the chimney to other rooms. Fan does not run The fan is turned off when air temperature drops down below the set point. - Page 8 Kamin www.blaubergventilatoren.de Designation Description Max. transported air temperature Temperature controller with the set temperature point Fan runs Fan does not run Fig. 12 Operating logic of Kamin fan with KF mixing chamber Temperature control damper is closed Temperature control damper is opened Gravity damper is opened Gravity damper is closed...
-
Page 9: Mounting And Operation Guidelines
Kamin www.blaubergventilatoren.de The fan is designed for top or horizontal mounting depending on the model. MOUNTING AND OPERATION GUIDELINES Install the fan on the even surface. The fan mounting options are stated in fi g. 15-18. The air motion direction in the heating / ventilation system must match the Provide free air circulation to cool down the fan motor. -
Page 10: Installation And Connection To Power Mains
Kamin www.blaubergventilatoren.de The house cabling system must be equipped with an automatic switch at 230 INSTALLATION AND CONNECTION TO POWER MAINS V / 50 Hz external input. Connect the fan to power mains through the automatic switch. The automatic switch trip current must be in compliance with the fan current consumption (refer Table 1). - Page 11 Kamin www.blaubergventilatoren.de Table 3. Troubleshooting Problem Possible reasons Troubleshooting Check power supply with a multimeter at the terminal block. Disconnect the fan from power mains. Wrong electrical connection. Check electrical connection reliability in the terminal block, automatic No power supply to the fan terminal block. switch, power socket.
-
Page 12: Warranty Card
WARRANTY CARD BLAUBERG KAMIN MANUFACTURE DATE SELLER SALES DATE REPRESENTATIVE IN EU Blauberg Ventilatoren GmbH Aidenbachstr. 52a, D-81379 München, Germany www.blaubergventilatoren.de Kamin / v.3 (5) / EN...
